Summary of Contents for AVIN AA-BE46

Page 1 Operating Manual...
Page 3 Thank you for choosing this Thank you for choosing this Thank you for choosing this unit as your navigator. unit as your navigator unit as your navigator Please read through these instructions so you will know how to operate Please read through these instructions so you will know how to operate Please read through these instructions so you will know how to operate Please read through these instructions so you will know how to operate Please read through these instructions so you will know how to operate...
Page 5: Table Of Contents
Content Precautions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3 Specifications - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5 1.
Page 6 2-8 GPS Navigation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 31 2-8 GPS Navigation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-8 GPS Navigation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-8 GPS Navigation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...
Page 7 The photos and figures in this manual are for reference only. The photos and figures in this manual are for reference only The photos and figures in this manual are for reference only The photos and figures in this manual are for reference only The photos and figures in this manual are for reference only The screens shown in the examples may differ from actual The screens shown in the examples may dif...
Page 8: Precautions
Operating precautions Please read the following precautions before use, and kindly comply with all of them to operate it in proper ways for the best use of the unit. 1. Be careful when installing third party application as they can cause the system to become unstable.
Page 9: Specifications
Product features Basic Specification: Power ------------------------- DC12V Resistance ------------------- 4 Max Power Output --------- 4X45W Volume Control ------------- 15 dB (Bass 100Hz, Treble 10KHz) DVD Disc Compatible Discs ---------- MPEG4.DVD.Super VCD.MP3.CD-R. CD-RW Picture-CD Video Standard ------------- Auto/NTSC/PAL Installation Angle ----------- 0--+/-30 Video Video Mode ------------------ 4：3 Mailbox Mode/ 4：3 Full screen /16:9 Modes Video Output ---------------- 1.0Vp-p.75ohms...
Page 10 Audio Line-out Max Output ------------------- 2V rms/10k (20Hz-20KHz) SUB-out Max Output ------------------- 2V rms/10k (20Hz-120Hz) Frequency Range ----------------------- 20Hz-20KHz S/N Ratio ---------------------------------- 90dB Dynamic Scope ------------------------- 80dB AM Tuner AM Frequency Range ----------------- 522-1620KHz (Euro/ China) Intermediate Frequency---------------- 450KHz Usable Sensitivity（ FM Tuner FM Frequency Range ------------------ 87.5-108KHz Intermediate Frequency --------------- 10.7KHz...
Page 11: Basic Operations
Basic Operation 1-1. Panel AA-BE46 1-2. Buttons 1-2. Buttons 1. Disc slot 2. Microphone The Microphone is used for Bluetooth Hands-free phone calling / Voice Commands. 3. Reset key Use a tiny pin to press the Reset key inside that hole to reboot the system when the system crashes/freezes unexpectedly.
Page 12 8.MENU： Click it while in any App, turn to the menu page of that App. 9．Home：Press it to return to desktop. 10．“NAVI” can be mapped to your choice of Navigation Apps; 11. Power / Volume (The left turn knob) * Power on: Press the left turn knob to switch on the unit while its connected; * Power off / Reboot: Long press the left turn knob a few seconds, the unit will pop up two options : Power off &...
Page 13: Connector Instruction
1-3. Connectors instruction ① USB/ Microphone External Microphone In USB Port 1 ② GPS Antenna Interface ( with GPS Antenna ) External GPS Antenna ③ Radio Antenna Interface ④ iPOD/USB \\ 09...
Page 14 ⑤ RCA 2xVideo output, 2x Audio output(L/R), 1x Video input, 1x Audio input(L/R) 1x Subwoofer out ⑥ OEM Connector (Plug With OEM harness, plug&play) 10 //...
Page 15: Desktop
1-4. Desktop The main menu interface Click on the Android icon or Back button to enter the Android Home Screen uninstall apps. Move Icons: Hold the icon for 1 second then you can drag it to any position in the main interface HOME key.
Page 16 ① Wallpaper edit, two groups of preset wallpapers: * Live Wallpapers * Wallpapers manager ② Desktop edit mode: * Move the position of the Apps, Press & hold any of the icons, drag it to the place you want, and release it. * Uninstall third party Apps, press &...
Page 17 Screen pages. On any screen touch the top of the screen and slide down to reveal the notification screen. The notification screen will display Volume, WIFI Switch, Brightness, Restart, Standby options. You can download and install apps directly online from the Google Play store or install apps stored on your SD card or USB drives.
Page 18: Features
Features 2-1. Radio MENU: Press it to display the menu bar ① Press Go To to manually input a station frequency. ② Auto Search and scans radio stations, any operation will stop scanning, Radio will play the first station automatically once scanning is finished. ③...
Page 19 Visualizer Click to switch to different visualizer modes. Equalizer / Fade & Balancer 4. Favorite stations: P1- P6: Press any of those icons for 3 seconds, or press the current station and drag it to one of those positions, then the current station will be stored into that position.
Page 20: Disc
2-2. Disc Disc symbol Disc format DVD Video DVD-R*1/DVD-R DL*1/DVD-RW*1 (Video mode/VR mode) DVD+R*1/DVD+R DL*1/DVD+RW*1 Video CD (Ver. 1.0/1.1/2.0) Audio CD CD-ROM*2/CD-R*2/CD-RW*2 *1 Audio files can also be stored. *2 Video files can also be stored. The following media files are also supported: MP3, WMA, AAC, WAV, Xvid, WMV, MPEG1/2/4, AVC, AVI, AFS Insert the Disc (label side up) and playback will start automatically.
Page 21: Cd Mode
1. CD mode ① Random play, press to switch on random play mode, press again to switch off. ② Repeat mode: Rep, Single repeat, no repeat ③ Previous & Next: Touch to skip a track. ④ Play & Pause ⑤ Track list: click the desired track number to play. \\ 17...
Page 22: Vcd Mode
2. VCD mode ① Menu: Repetition setup (A-B interval repeat), Chapter to jump Setting: Manual adjust display Eject ② PBC Menu: Click it, the PBC Menu appears. ③ Previous & Next: Touch to skip a chapter/track/scene. Touch and hold momentarily to reverse/fast-forward the video; and then repeatedly to switch the speed (×...
Page 23: Dvd Mode
3. DVD Mode ① Menu: Chapter to jump Click to return to the DVD to the main menu Setting: Manual adjust display Eject ② Subtitle Switching ③ Previous & Next: Touch to skip a chapter/track/scene file. Touch and hold momentarily to reverse/fast-forward the video; and then repeatedly to switch the speed (×...
Page 24: Usb/Sdhc
2-3. USB / SDHC Supported audio formats: MP3, APE, M4A, WAV, AMR, AWB, ACC, FLAC MID MIDI, XMF, RTTTL, RTX, OTA, WMA, RA, MKA, M3U,PLS. Supported Video formats: MPEG1/2/4, DivX, XviD, MP4, MOV, M4V, 3GP, 3GPP, 3G2, 3GPP2, AVI, DIVX, WMV, ASF, FLV, RM, MKV. Supported picture formats: JPEG, JPG, GIF, PNG, BMP, WBMP.
Page 25: Usb /Sd Photo
④ Random play * Random on: Plays all files in current list in random order * Random off: Returns to normal play mode ⑤ Visualizer * Touch the icon, the normal playback screen will change to playback screen with Visualizer ⑥...
Page 26: Usb /Sd Video
Photo viewing. ① Touch to set the current picture as wallpaper. ② Touch to skip a photo file ③ Touch to play photos in that folder automatically ④ Rotates photo clockwise. 3. USB / SD Video Touch “ Video” option, the unit will display all the folders where video files are stored, click one of those folders to open it, scroll up and down to select the desired video, double click to play.
Page 27: File Manager
2-4. File Manager 1. Viewing files ① click File Manager on desktop. ② Select the memory type, press the USB flash memory or SD Card accordingly to view the file folders there. ③ Click the folder to view the subfiles. 2.
Page 28: Bluetooth
2-5. Bluetooth Bluetooth allows this unit to be detected and connected by the other Bluetooth devices ( cellphone, tablet, etc), hands-free calling and Bluetooth audio steaming. Basic procedure of the bluetooth function Pairing & connecting When connecting Bluetooth devices for the first time, mutual registration is required. This registration (pairing) is required only for the first time, as this unit and the other devices will recognize each other automatically next time.
Page 29: Hands-Free Calling
Notes 1. While already connected to a Bluetooth device, this unit cannot be detected from another device. To enable detection, disconnect the current connection. 2. It may take time to search or connect. 3. Depending on the device, the connection confirmation display may appear before inputting the pair code.
Page 30: Receiving Calls
* By Call records or Contacts If you allow the system to sync with the cell phone’s contacts and records, you can make the call out by those two lists. -Call records Call records: Missed call , Incoming call , Outgoing call The unit will store the last 20 calls in each list, allowing you to select one quickly from the lists.
Page 31: Bluetooth Audio Stream
③ Operations during a call * To adjust the caller’s voice volume, turn the Volume knob. * To transfer the current call to the cell phone, touch , to transfer back to the unit touch again. * To mute the microphone, touch * To end a call, touch Note: * The ringtone and the speaker's voice are output only from the front speakers.
Page 32: Ipod
2-6. iPod This unit allows you to connect iPod devices via supplied specific USB cable, latest software before use. Made for – iPod touch (1st-4th Generation) – iPod classic – iPod Nano (1st-6th generation) – iPhone 4/4S – iPhone 3G/3GS –...
Page 33: Playback Operation
Playback operation 1. During the playback, touch to pause, touch to resume. 2. Touch to skip a track file. Random play mode. 4. Touch to switch repeat mode. EQ & Fade/Balance settings. 6. Touch , the Visualizer appears, touch to switch different Visualizer mode. To disconnect the iPod Stop playback, then disconnect.
Page 34: Auxiliary Equipment
2-7. Auxiliary Input 1. Auxiliary audio/video Input This unit allows you to connect auxiliary equipments such as MP3/ MP4,Cell phone and external TV box, etc. * Settings ①. Touch HOME, then click AUX, the AUX IN playback display appears. ②. Playback operation is controlled via the external auxiliary device itself. * Adjusting the volume level Be sure to adjust the volume for each connected device before playback, turn volume to proper level.
Page 35: Gps Navigation
Note: When backing up your car, be sure to look back, use the rear view mirrors, and watch your surrounding carefully for your safety. Do not depend on the rear view camera exclusively. 2-8. GPS 1.Navigation Software Installation Copy the application program with suffix name “APK” to SD card or U disk.: Click into the document management interface to find SD card or U disk directory and select “APK”...
Page 36: Obd2
2-9. OBD2 The system allows you to connect to an external Bluetooth OBD2 adapter. Under Bluetooth settings menu you can scan / search for your OBD2 device. Connecting process (We use TORQUE for example below) : 1. Plug the external OBD2 Bluetooth adapter into the vehicle OBD2 connector. option to start scanning.
Page 37 5. Open the TORQUE app, click menu then touch settings, then click OBD2 adapter settings, select Bluetooth as the connection type, and click the Bluetooth device which is connecting with the unit. 6. If the connection is made successfully the OBD indicator on the top bar will turn green.
Page 38: The Browser
2-10. The Browser You can surf the web by pressing anywhere on the address bar or search bar. The on screen keyboard will popup allowing you to enter your search term or web address. Pressing the Star icon will save and bookmark the current page. Pressing the Tabs will allow you to switch between the open pages.
Page 39: The Use Of Touch Screen
2-11. The use of touch screen You can use your fingers to move icons, press buttons, select menu options, and type on the on screen keyboard. Moving Objects: Click and hold an icon or file without lifting your finger off the screen move the selected item to your target location.
Page 40: Settings
3. Settings 3-1 Wireless & Network Turn Wifi On or Off. When Wifi is on the unit will scan for nearby WiFi hotspot and display them in a list. Click on your wireless network and enter the password if required. Once the device is connected to the wireless network, the WiFi icon will appear in the status bar showing the signal strength.
Page 41: Equipment
Set up the VPN, Portable hotspot, and Mobile networks. 3-2 Devices Set Subwoofer Crossover, Reversing Mute On/Off, Reversing Volume Adjustment \\ 37...
Page 42 Set brightness level, change wallpaper setting, and screen saver settings. Displays the amount of used and unused storage space for Internal Storage, SD Cards, and USB Drives. 38 //...
Page 43: Persona
1. To safely remove any SD cards or USB flash drives from the unit unmounting the cards or drives then you can safely remove the SD cards or USB flash drives from the unit. If you eject the SD Cards or unplug the USB Flash drives without unmounting first might result in corrupted files or other system instability.
Page 44 Set Viewing level, Viewing Level password, Password display, Third-party applications, Credential Storage Language selection, Spell Checker, choose your favorite keyboard, set up Voice Search, Text-to-speech output, and Pointer speed. 40 //...
Page 45 Data backup or restore, restore factory Settings settings, and user installed apps will be lost. You should backup any data or apps you would like to save before doing a Factory data reset. \\ 41...
Page 46: Individual Account
3-4 Add Account You can add Google account, E-mail account. 3-5 System 42 //...
Page 47 When software updates are available you can easily update your unit via sdcard. To update the system’s software you will need to copy the provided “update” folder containing the new software update files to the root of your sdcard. Insert the sdcard into the NAVI slot. Go to the system settings menu - select “About System”...
Page 48 You can use the Internet to provide time or time zone, or manually set the date and time, select time zone, and time and date display format. Note: Most Android apps require the date and time to be set correctly for the apps to work.
Page 49: Troubleshooting
4. Troubleshooting Symptom Cause and Action Check power cable connection are secured. Check if power fuse Power-on fail are still good. Replace power fuse if broken TFT display distorted or Press Reset key on the panel once not responsive Fail to receive radio Check if the radio antenna is connected securely and has not station become loose...
Page 50: Standard Unit And Accessories List
5. Standard Unit and Accessories List 1x Head Unit 1x Power Cable 1x RCA Cable 1x iPod Cable 1x CANBUS 1x USB Extension Cable 1x Radio Antenna Connector 1x GPS Antenna 1x Operating Manual 46 //...
