RECORDER GEAR PC550 User Manual

1080p wide angle portable wifi security camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER
MANUAL
www.recordergear.com
RecorderGear™ and respective logos are trademarks of
Teton Webstores LLC ©2016 ALL RIGHTS RESERVED

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PC550 and is the answer not in the manual?

Questions and answers

Related Manuals for RECORDER GEAR PC550

Summary of Contents for RECORDER GEAR PC550

  • Page 1 USER MANUAL www.recordergear.com RecorderGear™ and respective logos are trademarks of Teton Webstores LLC ©2016 ALL RIGHTS RESERVED...
  • Page 2 A - Power/Confirm Button G - Indicator Light B - Mode H - USB Charge/Data Port C - Infrared Switch I - TF Card Jack D - WIFI Switch J - HDMI Port E - Pickup Hole K - Lens F - Infrared Light MID: C11 1 Year Warranty...

  • Page 3: Getting Started

    * See Step1 B. Make sure you have an SD card inserted into the PC550. We recommend using a CLASS 10 or higher SD card or the PC550 may malfunction. C. Download the iOS/Android App; the PC550 works with a mobile App named “FinalCam”.
  • Page 4 Charging Before using the PC550 for the first time, we recommend giving it a full charge for 4-6 hours ( it has an internal rechargeable battery A. To charge, connect the PC550 to the USB port of any computer or to a USB wall charger using the included USB cable.

  • Page 5: Video Recording

    Power ON/OFF Power On: Press the power button (button A) once. The PC550 will turn on and enter into video recording standby mode. Power Off: Any time during operation, press and hold the power button (button A) for 5 seconds to turn off.

  • Page 6: Taking Photos

    App). The default video recording resolution of the PC550 is 1080P. C. To stop recording, press the power button once. The PC550 will return to standby mode and save the file. Taking Photos This mode enables you to take still photos.

  • Page 7: Recording Audio

    (Button B) once. The blue indicator light turns red. Press the mode button (Button B) a second time and the red indictor light turns green to show the PC550 is now in the audio recording mode. C. Press the power button (Button A) once to start recording audio.

  • Page 8: Motion Activated Recording

    Press the mode button (button B) 3 times again and the red indicator light turns red and blue. C. The PC550 is now to the motion activated standby mode. Press the power button (button A) once to begin recording, it will only record when it detects motion.

  • Page 9: Wifi Connection

    WiFi Connection The PC550 has the ability to output a Wi-Fi signal. You can connect an iOS/Android device to it. Once connected, you can use the FinalCam app to change settings and view/ download video. A. Power on the PC550; it enters (video recording) standby mode.

  • Page 10: Infrared Light

    Infrared Light The infrared light enables the PC550 to record in the dark and in low light conditions. A. Power on the PC550; it enters (video recording) standby mode. B. To activate; press the infrared button, the blue indicator light turns red and flashes 3 times;...
  • Page 11 FinalCam iOS/Android The PC550 supports an iOS/Android App called “Finalcam”. To download the app, Go to the App Store for IOS devices or to the Play Store for Android devices. Make sure your iOS/Android device is connected to the PC550 Wi-Fi network before starting.
  • Page 12 The time/date will sync with your ios/android devices time/date. 3. WDR: Touch to turn ON/OFF Wide Dynamic Range. 4. Pictures resolution ratios: (4032X3024) (3648X2736) (3264X2448) (2592X1944) (2048X1536) 2MHD (1920X1080) (640X480) 5. Video stream resolution/ratio: This will change how the live video stream displays in the app.
  • Page 13 Adjust the volume during playback. 11. Settings: Enters the settings menu shown below; Camera Name ( WiFi network name of the PC550 Camera Passwords ( Set new password for PC550 WiFi network – default password is “12345678” Auto Recording (...
  • Page 14 Recording file inverval: determine video file length G-sensor setting ( No function performed Factory Reset ( Resets the PC550 back to default settings 12. Download: Use this option to access downloaded files. 13. Video recording file: Use this to enter the interface of downloaded files.
  • Page 15 Playback App Display 1. The playing progress of the current video 2. Brightness: adjust display brightness 3. Play the previous file 4. Start/pause the current video playing 5. Play the next file 6. Volume control, open and adjust the volume of video during playing 7.
  • Page 16 Recordings on Computer A. To access your saved recordings, power on the PC550. While it is in the standby mode and the memory card still inside of it, connect the USB cable between the device and a computer. It will mount on your PC/MAC as a USB removable drive.

  • Page 17: Detailed Specs

    D. The power button (button A) acts as the play/pause button. E. While playing files, the mode button (button B) acts as the stop button. F. Press the mode button (button B) again to switch to video recording mode. Detailed Specs Items Relevant Parameters Video Recording...
