Kontron AG does not accept any liability for any printing errors or other inaccuracies in the manual unless it can be proven that Kontron AG is aware of such errors or inaccuracies or that Kontron AG is unaware of these as a result of gross negligence and Kontron AG has failed to eliminate these errors or inaccuracies for this reason.
About This Manual 01/ About This Manual The KT-RT-I5 User’s Manual provides instruction for qualified personnel to follow when setting up a new KT-RT-I5 device. This document is intended for use by qualified personnel to compliment the training and expertise, not to replace it.
The KT-RT-I5 is designed and manufactured according to strict controls and following the stated safety regulations. The following list identifies incorrect operating uses of the KT-RT-I5. Incorrect use of the KT-RT-I5 can lead to hardware damage, safety issues and possible risk to personnel health: The KT-RT-I5 is under operation by untrained personnel;...
02.05. Environmental Ambient Temperature The KT-RT-I5 operates on the basis of a passive cooling concept which internal waste heat is released via the housing surface and requires fresh airflow in the environment. Operating the KT-RT-I5 with no fresh cooling air may cause overheating and damage to the device.
The operator is solely responsible for this type of operation. Radio Frequency Limited Locations Considering the radio frequency limitation in hospitals and aircraft, the KT-RT-I5 can only be installed with permission. Industrial computers may affect the function of implanted medical devices such as pacemakers and may cause malfunction.
This device complies with the IEC 60950-1:2005+A1. 02.09. Lithium Battery Safety Statement Lithium battery inside. Danger of explosion if battery is incorrectly replaced. Replace only with same or equivalent type recommended by battery manufacturer. KT-RT-I5 User’s Manual Version 1.0 www.kontron.com...
® 03.01. About This Guide The KT-RT-I5 User Manual provides instruction for qualified personnel to use as a guide for setup of the device. This document is not intended to replace the training and expertise of the end-user. 03.02. Unpacking the Device Before you begin the installation or configuration process make sure to inspect all components and accessories.
Page 11
BIOS On/Off for I/Os Data Collection Front: 2.0 Mega-Pixels camera Camera Rear: 5.0 Mega-Pixels camera with LED auxiliary light and Auto-focus GNSS Optional Barcode Reader Optional Magnetic Stripe Reader Optional Smart Card Reader Optional KT-RT-I5 User’s Manual Version 1.0 www.kontron.com...
-20°C (-4°F) to 60°C (140°F) Range Storage Temperature -30°C (-22°F) to 70°C (158°F) Range Humidity 5-95% without condensation 03.04. KT-RT-I5 Configuration Options The following options are available for the KT-RT-I5: NFC module Barcode reader Smart card reader High capacity battery ...
Introduction 03.05. Parts List The KT-RT-I5 is shipped with the following items. All other accessories are sold and ordered separately. For help, contact your local Kontron sales representative. See “Contacting Kontron” on page 54. KT-RT-I5 Power Adapter Digitizer 2-Point Carrying Handle...
See “Side View” on page 13 for further information. Easy to grip rubber bumpers enable the rugged tablet to withstand Rubber bumpers shocks and drop for use in demanding environments. Bottom view See “Bottom View” on page 12 for further information. KT-RT-I5 User’s Manual Version 1.0 www.kontron.com...
8 home key. ® Volume + Volume increase. Volume - Volume decrease. Power key Turns the KT-RT-I5 on or off. Power LED The power LED lights when the device is on. F2 key Programmable function key. F1 key Programmable function key.
Table 5. Bottom View Item Description Docking connector 12 pin connector for docking onto a station. Kensington lock Lock the KT-RT-I5 to a stationary object for security. Pass-through Dual pass-through for WLAN, GNSS and WWAN. KT-RT-I5 User’s Manual Version 1.0 www.kontron.com...
Connect USB devices to the KT-RT-I5. Audio jack Connect a 3.5 mm jack for a headphone or external speakers. Ethernet Connect the KT-RT-I5 to an Ethernet (RJ-45) cable. DC-IN jack Insert power connector to charge battery. RS-232 Connect the KT-RT-I5 to a serial device.
Place digitizer here. 03.07. Identifying the Digitizer You can use the digitizer to control your KT-RT-I5 as with a mouse or keyboard. The digitizer is not waterproof. Take care not to soak it or dip it in water. Click Button Figure 6.
The mouse icon returns to the left button highlighted in red so subsequent taps are treated as left clicks. A digitizer replacement kit is available. To prevent damage or malfunction, always dry the touch screen when wet. KT-RT-I5 User’s Manual Version 1.0 www.kontron.com...
Getting Started 04/ Getting Started This section provides an outline of the steps necessary to setup a new KT-RT-I5. A detailed guide follows the listed items, see as follows. For additional technical assistance, contact your Kontron representative. See “Contacting Kontron”...
Getting Started 04.02. Charging the Battery When you use the AC adapter to connect your KT-RT-I5 to a power outlet, the standard and external (optional) battery will automatically begin to recharge. While the battery is charging, the power LED will be active. When the battery is fully charged, the power LED is lit a solid green.
04.03. Powering the Device On and Off Powering On the Device Only power on the KT-RT-I5 after connecting all of the peripherals and cabling. Press and hold the power button until the screen lights. The device runs through the start up sequence and powers up.
Check with your network or cellular service provider for availability and cost rates. Power off the KT-RT-I5. See “Powering Off the Device” on page 19. Open the left I/O compartment cover. See “Opening the I/O Compartment Cover” on page Locate the micro SIM slot in the left I/O parts.
Getting Started 04.05. Removing the Micro SIM Card Power off the KT-RT-I5. See “Powering Off the Device” on page 19. Open the left I/O compartment cover. See “Opening the I/O Compartment Cover” on page Locate the micro SIM slot in the left I/O parts.
Insert the microSD card and press it in until an audible click sounds. Figure 19. Installing the MicroSD Card Close the left I/O compartment cover. See “Closing the I/O Compartment Cover” on page KT-RT-I5 User’s Manual Version 1.0 www.kontron.com...
Press the microSD card in and release it. The card springs out. Grasp the microSD card and remove it from the slot. Figure 21. Removing the MicroSD Card Close the left I/O compartment cover. See “Closing the I/O Compartment Cover” on page KT-RT-I5 User’s Manual Version 1.0 www.kontron.com...
04.09. Removing the Protective Film from the Display The front display of the KT-RT-I5 is protected during transport by a transparent film. This film should remain on the front display during assembly to avoid damage to the front display surface.
Figure 23. Side View: Locating the I/O Compartment Cover Unlock the latch. (Only available for the left I/O compartment cover) Figure 24. Unlocking the Latch Pull out the I/O compartment cover. Figure 25. Openin the I/O Compartment Cover KT-RT-I5 User’s Manual Version 1.0 www.kontron.com...
Figure 27. Installing the I/O Compartment Cover Lock the latch. (Only available for the left I/O compartment cover) Figure 28. Locking the Latch The I/O compartment cover must be inserted correctly to prevent internal damage to the device. KT-RT-I5 User’s Manual Version 1.0 www.kontron.com...
Connect USB Cabling The KT-RT-I5 have one USB port for connecting USB devices, such as a digital camera, scanner, printer, modem, and mouse. The USB port support USB 2.0 or USB 3.0 devices. Open the left I/O compartment cover. See “Opening the I/O Compartment Cover” on page Connect to USB device via USB cable.
Page 32
Connect to HDMI devices via micro HDMI cable. Open the left I/O compartment cover. See “Opening the I/O Compartment Cover” on page Connect micro HDMI cable to micro HDMI port on the KT-RT-I5. Figure 32. Connect Micro HDMI Cabling KT-RT-I5 User’s Manual Version 1.0...
Figure 33. Connect RS-232 Cabling 05.04. Handstrap, Carrying Handle and Shoulder Strap The KT-RT-I5 is equipped with a handstrap, a carrying handle and a shoulder strap for convenience and choice. Select the accessory that is right for your needs. The handstrap can be installed with either the shoulder strap or the carrying handle. However, the handle and shoulder strap can not be installed together due to space constraints.
Page 34
Make sure the D-rings are tightly secured before installing the handstrap. Figure 35. Installing the D-rings Connect the handstrap on the D-rings. When the handstrap is installed, the digitizer can be placed under the strap. Figure 36. Connecting the Handstrap KT-RT-I5 User’s Manual Version 1.0 www.kontron.com...
Page 35
Removing the Handstrap Unlock the handstrap from the D-rings. Figure 37. Removing the Handstrap Remove the D-rings. Figure 38. Removing the D-rings Secure the bumper and the KT-RT-I5 with screws. Figure 39. Securing the Screws KT-RT-I5 User’s Manual Version 1.0 www.kontron.com...
Page 36
Press in the clips to release them from the metal loop. Remove the clips. Metal Loop Figure 41. Removing the Carrying Handle Connecting the Shoulder Strap Attach the clips to the metal loop on the bumper. Metal Loop Figure 42. Connecting the Shoulder Strap KT-RT-I5 User’s Manual Version 1.0 www.kontron.com...
See “First Time Use” on page 17. Place the device display side down on a clean work surface. Locate the battery. Locking Switch Release Button Battery Figure 44. Rear View: Locating the Battery KT-RT-I5 User’s Manual Version 1.0 www.kontron.com...
Make sure the latch is securely locked to prevent the battery from falling. 05.06. Removing the Standard Battery Place the device display side down on a clean work surface. Locate the battery. Locking Switch Release Button Battery Figure 47. Rear View: Locating the Battery KT-RT-I5 User’s Manual Version 1.0 www.kontron.com...
Figure 49. Removing the Battery 05.07. Connecting to a Wireless Network Before you can make use of the KT-RT-I5 wireless functions, you need to connect to a network. The following is a set of procedures for connecting to a wireless network.
Page 40
If a password is required, type the password in the Enter the network security key field. Alternatively, you can also push the WPS button on your router to begin the security handshake. Tap Next to finish the connection process. You have successfully connected to a wireless network. KT-RT-I5 User’s Manual Version 1.0 www.kontron.com...
You need to run the BIOS Setup utility when: Restoring to BIOS settings to factory default Modifying specific hardware settings Modifying specific settings to optimize system performance Installing Windows 7 operating system KT-RT-I5 User’s Manual Version 1.0 www.kontron.com...
To run the BIOS Setup Utility, use the following procedures: Perform one of the following: If the KT-RT-I5 is powered off Press the Power button to start up the device. The power LED lights. Quickly press and hold the Windows Home key until the BIOS Post screen displays.
Page 43
Due to the device’s fast boot up and boot down time, there is only a small time frame of a few seconds between the release of the Power button and the opportunity to press the Windows Home key. The App Menu displays. Figure 51. BIOS Setup Utility: App Menu Screen KT-RT-I5 User’s Manual Version 1.0 www.kontron.com...
Navigate to APP Menu > Main > Boot Features. Locate the CSM Support setting and tap the drop-down menu to display the options. Tap Yes to enable CSM support. Figure 52. Main > Boot Features KT-RT-I5 User’s Manual Version 1.0 www.kontron.com...
Page 45
Access the BIOS Setup Utility, see “Accessing the BIOS Setup Utility” on page 38. Navigate to APP Menu > Main > Boot Features. Locate the Legacy Boot setting and tap on the menu to select On enable legacy boot. Figure 53. Main > Boot Features KT-RT-I5 User’s Manual Version 1.0 www.kontron.com...
Page 46
Navigate to APP Menu > Exit and tap Exit Saving Changes. Figure 54. Exit the BIOS Utility A prompt display, tap Yes to save the configuration. The BIOS settings are configured and the Windows 7 operating system can be installed. KT-RT-I5 User’s Manual Version 1.0 www.kontron.com...
Tap the Enter icon next to Setup the Supervisor Password to access the virtual keyboard. Figure 55. Security > Account’s Password Status Tap the password to use for the Supervisor profile and tap Enter. Figure 56. Set Supervisor Password KT-RT-I5 User’s Manual Version 1.0 www.kontron.com...
Page 48
A supervisor password can not be reset. In the event that you forget the supervisory password, you will need to reflash the BIOS to enter the BIOS menus. Refer to “Updating BIOS” on page 45 to reflash the BIOS. KT-RT-I5 User’s Manual Version 1.0 www.kontron.com...
Contact your technical sales or technical representative to obtain the correct BIOS file. Copy the BIOS file on to the USB device. Connect the USB device to one of the device’s USB ports and power on the KT-RT-I5. A USB keyboard is required for entering command.
Page 50
Using BIOS Setup Utility Tap Change PC settings. Figure 59. Change PC Settings From the PC settings menu, tap Update and recovery to continue. Figure 60. Update and Recovery KT-RT-I5 User’s Manual Version 1.0 www.kontron.com...
Page 51
Using BIOS Setup Utility From the Update and recovery screen, tap Recovery. The Advanced startup option displays. Figure 61. Recovery Under Advanced startup, tap Restart now. Figure 62. Restart Now KT-RT-I5 User’s Manual Version 1.0 www.kontron.com...
Page 52
Figure 63. Use a Device 11. From the Use a device menu, tap Internal Shell to open the command screen. Make sure connect the KT-RT-I5 to the AC adapter to prevent a sudden loss of power. Figure 64. Internal Shell KT-RT-I5 User’s Manual Version 1.0...
Page 53
The BIOS is now updated. Updating EC Connect the KT-RT-I5 to the AC adapter to prevent a sudden loss of power. Updating EC requires the use of the Internal Shell Command menu, refer to steps 1 to 12 of “Updating BIOS”.
KT-RT-Control menus. Important: Do not terminate or remove the KT-RT-Control program manually or the ambient light sensor and the function buttons will be malfunction. Download the latest information and documentation through the Kontron official site: http://www.kontron.com Figure 66. KT-RT-Control Overview...
Page 55
Display Switch Choose a display mode when connect to another output device. Switch the usage of internal antenna or external antenna on vehicle Pass-through Switch docking. Button Setting Pre-defined functions settings. Supports function button customizing. KT-RT-I5 User’s Manual Version 1.0 www.kontron.com...
If you send the computer in for service, it is your responsibility to save the computer data and configuration. Kontron is responsible only for ensuring that the hardware matches the original configuration when repairing or replacing the computer.
The computer appears to be locked up and you cannot enter data. Restart the computer. 08.03. Call Product Support Simple instructions please contact the dealer, contact Kontron representative, or leave a message visit the Kontron website at www.kontron.com. To better assist you have the following information ready: Configuration number ...
Maintenance 09/ Maintenance 09.01. Cleaning the Device Danger to electric shock when cleaning or maintaining the KT-RT-I5. To avoid electric shock, turn the KT-RT-I5 off and disconnect it from the power supply before cleaning or maintaining it. Housing The housing of the KT-RT-I5 is best cleaned with a damp cloth.
Page 59
