Glass Chimney Hood
Installation & User Instructions
Important
–
Please read these instructions fully before installing or using
These instructions contain important information which will help you get the best from your
appliance and ensure safe and correct installation, use and maintenance.
If you need help or have damaged or missing parts, call the
–
Please keep for future reference
Customer Helpline: 0845 600 4632
489/5778
489/5785
Issue 2 – 23/04/2010
Advertisement
Table of Contents
Summary of Contents for Argos SY-3388A-P-C-600
- Page 1 Glass Chimney Hood Installation & User Instructions – Please keep for future reference 489/5778 489/5785 Important – Please read these instructions fully before installing or using These instructions contain important information which will help you get the best from your appliance and ensure safe and correct installation, use and maintenance.
-
Page 2: Table Of Contents
Contents Safety Information Parts Guide to Wall Mounting and fixings Installation Vent outside Vent inside Electrical Connection User Instructions Care and Maintenance General Light bulb replacement Trouble Shooting Product codes Technical Specifications SY-3388A-P-C-600 Disposal information SY-3388A-P-C-900 Guarantee... -
Page 3: Safety Information
Safety Information Important – Please read these instructions fully before installation Before use During use The installation of this appliance is best carried out This appliance is not intended for use by persons by 2 people. (including children) with reduced physical, sensory or mental capabilities, or lack of experience and Any installation work must be carried out by a knowledge, unless they have been given... -
Page 4: Parts
5. Filter Accessories included Instructions x 1 Glass x 1 Chimney x 1 Exhaust Pipe x 1 (Fitted on SY-3388A-P-C-600) One-way-valve x 1 Wall Bracket x 1 Plate I x 1 Plate II x 1 Screw x 7 Wall plug x 9... -
Page 6: Installation
Installation Vent outside Caution: 2 people are required to unpack and handle the appliance, it is recommended that gloves are worn. Caution: The wall must be strong enough to take the weight of the hood. Wall plugs are provided to secure the hood to most types of walls. -
Page 7: Installation
Installation Vent outside 3. Drill 2 holes to accommodate plate II. Screw and tighten the bracket onto the wall with the screws (4mm x 38 mm) and wall plugs provided. The distance between the wall bracket and plate II is suggested to be maximum 90cm. Remark: Plate II is used to fix the chimney at the end of installation. - Page 8 Installation Vent outside 7. Adjust the height of the chimney approximately in according to your required height. Then, install plate I on the chimney with two screws (4mm x 8mm). The procedure is as below. a) Put the inner chimney into outer chimney. Then pulling out the inner chimney upwards.
-
Page 9: Vent Inside
Installation Vent inside If you do not have an outlet to the outside, exhaust pipe is not required and the installation is similar to the one shown in section “VENT OUTSIDE”. Activated carbon filter (purchase separately) can be used to trap odors. Contact the helpline for details. -
Page 10: Electrical Connection
Installation Electrical connection Plug replacement (UK & Ireland only) Any electrical work that is required to Should you need to replace the plug; the wires in install this appliance MUST be carried out by a the power cable are coloured in the following way: qualified electrician. -
Page 11: User Instructions
User Instructions Using your appliance Switch off button Press this button to stop the motor operation. Low Speed button Press this button to operate at low speed. Medium Speed button Press this button to operate at medium speed. High Speed button Press this button to operate at high speed. -
Page 12: Care And Maintenance
Care and Maintenance General Important: Always unplug the appliance from the power socket during cleaning and maintenance. Never use any sharp instruments or abrasive substances, soap, household cleaner, detergent or wax polish for cleaning. Regular Cleaning Use a soft cloth moistened with hand-warm mildly soapy water or household cleaning detergent. Never use metal pads, chemical, abrasive material or stiff brush to clean the unit. -
Page 13: Trouble Shooting
Trouble Shooting In the unlikely event of difficulties with your appliance please follow the trouble shooting guide below. If the problem persists, contact the retailer if the machine is still under guarantee. If the machine is out of guarantee, contact an approved service agent on 0845 600 4632. Problem Possible cause Solution... -
Page 14: Technical Specifications
Technical Specifications SY-3388A-P-C-600 Model SY-3388A-P-C-900 SY-3388A-P-C-600 – 60CM Product width SY-3388A-P-C-900 – 90CM Fan speed level Maximum extraction 700 m Lamps Halogen 20W X 2 Washable grease filters 5 layers Adjustable chimney We apologise for any inconvenience caused by any minor inconsistencies in these instructions, which may occur as a result of product improvements and development. -
Page 15: Guarantee
Guarantee PRODUCT GUARANTEE This product is guaranteed against manufacturing defects for a period of Year This product is guaranteed for twelve months from the date of original purchase. Any defect that arises due to faulty materials or workmanship will either be replaced, refunded or repaired free of charge where possible during this period by the dealer from whom you purchased the unit.
