3) Refer to SECTION 3 for valve lash inspection and
adjustment procedures.
4) Install engine valve cover and tighten bolts to
specifications.

CAMSHAFT TIMING BELT REPLACEMENT

Refer to SECTION 3 for camshaft timing belt removal
and installation procedures.

ENGINE OIL FILTER CHANGE

1) Loosen oil filter using an oil filter wrench.
NOTE:
Before installing new oil filter, apply a thin coat of
engine oil to the "O" ring filter seal.
2) Screw new oil filter on by hand until the filter "O" ring
contacts the mounting surface.
!
CAUTION
To tighten the oil filter properly, it is important to
accurately identfy the position at which the filter
"O" ring first contacts the mounting surface.
3) Tighten the filter 3/4 turn from the point of contact with
the mounting surface using an oil filter wrench.
!
CAUTION
To prevent oil leakage, make sure that the oil fil-
ter is tight, but do not overtighten it.
4) After installing oil filter, start engine and check oil filter
for leakage.

ENGINE OIL CHANGE

Before draining engine oil, check engine for oil leakage.
If any evidence of leakage is found, make sure to correct
defective part before proceeding to the following work.
1) Drain engine oil by removing drain plug.
2) After draining oil, wipe drain plug and around drain
plug hole clean. Reinstall drain plug, and tighten
securely.
Drain Plug
N–m
Torque Specifi- Torq e Specifi
30–40
cations
3) Replenish oil until oil level is brought to FULL level
mark on dipstick (about 2.9 liter or 6,1/5.1 US/Imp pt.).
The filter inlet is located above the engine valve cover.
4) Start the engine and run it for 3 minutes to bring it up
to operating temperature. Stop the engine and wait
kg–m lb–ft.
3.0–4.0 22–28.5
