Summary of Contents for Verterx Standard VXR-9000E
- Page 1 OUNT EPEATER VXR-9000E PERATING ANUAL Vertex Standard LMR, Inc.
- Page 2 Designed to mount in a standard 19-inch rack, the VXR-9000E is crafted using the latest computer-aided design and manufacturing processes, to ensure a high level of reliability to users. Important channel frequency data is stored in EEPROM, and is easily programmable by a Servicing Technician or Dealer using an IBM compatible personal com- puter and the FIF-10A (or FIF-12) + CT-104A USB Programming Interface and CE60 Software.
-
Page 3: Numeric Display
The internal speaker is located here. are explained on the pages to follow. VOL Knob This control knob adjusts the output level of the front speaker and external speaker jack on the back panel. VXR-9000E R OUNT EPEATER PERATING ANUAL... - Page 4 Programming of the callsign is performed by your range of the repeater’s transmitted and received audio VERTEX STANDARD dealer. signal. When you enable this function, the signal-to- noise ratio can be improved by reducing the transmit- ted audio dynamic range. VXR-9000E R OUNT EPEATER PERATING ANUAL...
- Page 5 Press (or Press and hold in for one second) the PF key assigned to “Local PTT” to enable (“On”) or disable (“Off”) operation using a PTT switch connected to the front panel’s Microphone Jack. VXR-9000E R OUNT EPEATER PERATING ANUAL...
- Page 6 Press (or Press and hold in for one second) the PF key signed to “Transmit” to enable (“On”) or disable (“Off”) assigned to “Squelch” to override the Squelch action the transmission of the VXR-9000E. (CTCSS, DCS, and Noise Squelch), so as to hear any sig- nal present on the operating channel.
-
Page 7: Rear Panel
50 Ohms. Warning!: The 50 V RF voltage (@25 W/50 Ω) is applied to the TX RF section of the repeater while transmitting. Do not touch the TX RF section absolutely while transmitting. VXR-9000E R OUNT EPEATER PERATING ANUAL... - Page 8 DB-25 C ONNECTOR Pin 5: TX ATT The VXR-9000E repeater is provided with a 25-pin DB- 25F female connector for interconnections to This output is intended for controlling an external co- accessories.Use a DB-25M 25-pin male connector to con- axial switching relay. It is an open drain output which nect accessories to the repeater.
- Page 9 UTPUT FOR OMMUNICATIONS This pin is an output for high speed receiving data sig- The VXR-9000E provides eight ports nals with the data being extracted immediately after the (PIO) that can be programmed for vari- discriminator (prior to any de-emphasis).
-
Page 10: Installation
Antenna Considerations Equipment Location Repeater operation requires two antennas, one for re- The VXR-9000E must be installed in a 19-inch Mount- ceiving and one for transmitting, so that the receiving ing Rack, which will allow for free air flow around the antenna does not absorb energy from the transmitting heat sink on the rear apron at all times. -
Page 11: Backup Power Supply
NSTALLATION Power Supply Backup Power Supply Operation of the VXR-9000E requires a power source For uninterrupted operation during power failures, a capable of providing at least 8 Amps continuously at 12-volt rechargeable type battery (55-Ah or more rec- 13.6 Volts DC. The FP-1030A (External) and FP-31 (In-... -
Page 12: Supplied Accessories
Knob Cap (RA0506900) ........... 6 FVP-35 Rolling Code Encryption Unit Name Plate (RA0508500) ..........1 USB Programming Interface FIF-10A Operating Manual ............1 FIF-12 USB Programming Interface CT-104A PC Programming Cabel (for FIF-10A and FIF-12) VXR-9000E R OUNT EPEATER PERATING ANUAL... - Page 13 VXR-9000E R OUNT EPEATER PERATING ANUAL...
-
Page 14: Declaration Of Conformity
Declaration of Conformity We, Yaesu UK Ltd. declare under our sole responsibility that the following equipment complies with the essential requirements of the Directive 1999/5/EC. Type of Equipment: Desktop Repeater Brand Name: VERTEX STANDARD Model Number: VXR-9000EV/VXR-9000EU Manufacturer: Vertex Standard Co., Ltd. Address of Manufacturer: 4-8-8 Nakameguro Meguro-Ku, Tokyo 153-8644, Japan Applicable Standards:... - Page 15 Copyright 2013 No portion of this manual may be reproduced without the permission of Vertex Standard LMR, Inc. All rights reserved. Vertex Standard LMR, Inc. Printed in Japan...
