Age: 14+
BLACK FALCON SPY DRONE W/CAM USER MANUAL

Attention:

1. Read instructions thoroughly before first use and keep them in a safe place for future
reference.
2. Inspect all Drone components before each use and DO NOT operate if any of the
components are damaged.
3. This RC Drone is not suitable for use by children under 14 years of age.
4. The use of included Protection Cover is recommended for added safety and protection
of operator, surrounding persons, property, environment, and animals in the event of
collision.
5. Keep the Drone in sight at all times when operating it to avoid injury or damage to
people, animals, or property.
6. The use of the Drone in some areas may be prohibited. Check whether the use of the
Drone is permitted before using it.
7. The propellers on this item are designed to break away from the Drone upon impact
with a hard surface so they do not break or cause damage. Simply follow the instructions
on page 8 to replace the propeller. We have included extra replacement propellers to use
if one is damaged or lost.
8. DO NOT use the Drone in rain, wind, snow, fog, etc., or if visual conditions are less than
ideal.
If you need assistance please call Tech Services at 310-222-8682, Ext. 147.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BLACK FALCON and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Jobar BLACK FALCON

  • Page 1 Age: 14+ BLACK FALCON SPY DRONE W/CAM USER MANUAL Attention: 1. Read instructions thoroughly before first use and keep them in a safe place for future reference. 2. Inspect all Drone components before each use and DO NOT operate if any of the components are damaged.
  • Page 2 ALL PARTS INCLUDED: Note: The 2 red blades are not identical, Black blade B nor are the 2 black blades. Each is marked A or B on the back. In order for the drone Black blade A to take off successfully, all 4 blades must be installed in the correct position.
  • Page 3 CHARGE THE BATTERY NOTE: Non-compliance with the instructions below could result in fire, electric shock or explo- sion. Follow all directions exactly. Unplug the wire and connect the battery with the USB charger, then plug the charger into a computer USB port or other USB power outlet. Do not remove the battery from the Drone body and do not leave the Drone unattended while charging.
  • Page 4 10. Do not use the LiPo battery if the plastic cover has been torn or compromised in any way. Do not remove the LiPo battery. Do not expose the LiPo battery to excessive physical shock. Never use a swollen battery or a leaky battery, or one which is damaged or giving off a unusual odor. 11.
  • Page 5 Push up the left throttle stick,and the spinning speed of the main blades will Ascending increase.The Drone begins to ascend. Pull down the left throttle stick,and the spinning speed of the main blades will Descending increase.The Drone begins to descend. Turn right Push the left throttle stick to the left, and the Drone will turn to left.
  • Page 6 When the Drone flies sideways (towards the left) in the process of hovering, please continuously press the right sideway trimmer until it recovers. When the Drone flies sideways (towards the right) in the process of hovering, please continuously press the left sideway trimmer until it recovers.
  • Page 7 2. You should ensure that no-one is standing within 1 meter (1 yard) from the Drone when in operation and that at all times you keep a sufficient distance between the blades and any person, animal or property. 3. Do not use the Drone in wet conditions nor land it on a wet surface 4.
  • Page 8 1.The rotation of the main blades 1.Push the left throttle stick up are too slow Ascending failure 2.The Drone battery is exhausted 2.Recharge the Drone battery Landing too The left throttle stick is pulled Pull down the left throttle stick slowly down too fast to perform a smooth landing Soon...
