WOLFF PerfectSun 26T User Manual

DANGER Ultraviolet radiation. Follow instructions. Avoid overexposure. As with
natural sunlight, overexposure can cause eye and skin injury and
allergic reactions. Repeated exposure may cause premature aging of the skin and skin cancer.
WEAR PROTECTIVE EYEWEAR; FAILURE TO MAY RESULT IN SEVERE BURNS OR
LONGTERM INJURY TO THE EYES. Medications or cosmetics may increase your sensitivity
to the ultraviolet radiation. Consult physician before using sunlamp if you are using medications
or have a history of skin problems or believe yourself especially sensitive to sunlight. If you do
not tan in the sun, you are unlikely to tan from the use of this product. Children, the elderly, or
fair skinned people who always burn easily and either never tan or tan minimally should not use
this equipment.
To use, lie down on bench and pull canopy down as far as adjustment will allow maintaining
at least 2 inches (5.1 centimeters) between your body and canopy clear plastic panel, other-
wise overexposure may occur. Do not use without clear plastic panels in place. Untanned per-
sons should not tan on consecutive days during their first week of tanning. Never tan more than
once a day. Tanning normally appears after the first few sessions and maximizes after approxi-
mately four weeks. Tan once or twice per week thereafter to maintain appearance. Persons
already having a base tan may begin at advanced levels corresponding to the extent of their base
tan.
Skin Type:
I Sensitive Skin (Burns easily and severely and does not tan.)
II Light Skin (Burns easily and severely and tans minimally.)
III Normal Skin (Burns moderately and tans average.)
IV Dark Skin (Burns minimally, tans easily and above average.)
RECOMMENDED EXPOSURE TIMES IN MINUTES
Level 1/Week 1
Skin Type: 1st-3rd Sessions
I Sensitive
II Light 2
III Normal 3
IV Dark 4
MAXIMUM EXPOSURE TIME IS 11 MINUTES
New lamps emit approximately 10% more ultraviolet radiation during the first 50 hours of
Operation. Recommended tanning times should therefore be reduced by approximately 10%
during that period.
WARNING: • Read these instructions before using this sunlamp product. • All persons in the
room should wear protective eyewear when lamps are on. Recommended eyewear: provided
eyeshields or equivalent eyewear as defined under 21 CFR 1040.20. Other types of eyewear
may not provide adequate protection. Failure to use protective eyewear may result in severe
burns or other eye injury. If discomfort develops, discontinue use and consult a physician.
ONLY THE FOLLOWING LAMPS HAVE BEEN CERTIFIED FOR USE IN THE 26T:
PS MAX Wolff® Model PSM71-T12-100W BI-PIN
DARK TAN™ Wolff® Model DT71-T12-100W BI-PIN
PS EXTREME Wolff® Model PSE71-T12-100W BI-PIN
DARK TAN™ PLUS Wolff® Model DTP71-T12-100W BI-PIN
Turbo Sun® S Wolff® Model F8-T5-10W
DISCONNECT POWER CORD BEFORE ATTEMPTING TO CLEAN, RELAMP, OR
ENGAGE IN THE MAINTENANCE OF THIS PRODUCT.
THIS EQUIPMENT MUST BE EARTH GROUNDED.
This product is in conformity with performance standards
for sun lamp products under 21 CFR PART 1040.20 and
ANSI/UL Standard 482.
88465
Level 2 Level 3 Level 4 Level 5
NOT RECOMMENDED FOR TANNING
4 6 8
5 8 11
6 9 11
-or-
( below)
( below)
-or-
( below)
( below)
(Turbo Face Lamp)
Shock hazard.
Disconnect power before servicing or removing any protec-
tive covers.
Do not operate this device near water or while you are wet.
Some medications may increase your sensitivity to ultraviolet light. It
is recommended that you consult a physician before using this
sunbed if taking any medication or if you suspect that your skin might
be especially sensitive to sunlight.
Wear protective eyewear.
Failure to may result in severe burns or longterm injury to the eyes.
Use of a voltage source above 230V AC may prevent proper operation
of the sunbed and could cause damage and void the warranty.
Air from the room is used to cool the sunbed. Maximum ambient room
temperature should be 80°F. Place your sunbed no closer than 6" from
any wall. Make sure nothing obstructs the airflow into the sunbed's
endcaps or out of the fan openings. A poorly ventilated room may
cause the unit to become hot and cause discomfort to the user.
11

Electrical Requirements

11
11
Your sunbed operates from a 220V AC source. The 26T requires a NEMA
6-20R electrical outlet (below) on a dedicated circuit capable of pro-
viding 20 Amp service, installed in the room in which you will use the
unit. We recommend installation by a professional electrician. The out-
let must be earth grounded.

Unpacking and Inspection

The canopy box contains the canopy and a pair of gas springs. The
bench box contains the bench, assembly hardware, stand legs and skirt.
Inspect the items and make sure they are free from any visible damage.
Report the extent of any damage to the transportation company.
Hardware Inventory
Allen-head Bolt 5/16" x 1"
Quantity 2
5/16" Metal Washer
Quantity 2
Bushing
Quantity 2
Allen-head Bolt 5/16" x 1 1/2"
Quantity 2
Nylon Washer
Quantity 2
DANGER
DANGER
WARNING
CAUTION
20 AMP NEMA #6-20R
RECEPTACLE
(These items and a small pillow)
Hex (Allen) Wrench
Quantity 1
Safety Goggles
Quantity 1
28717-01B - Page 1
Hinge Brackets
(1) left, (1) right
