Fine Offset Electronics WH1285 Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

WIRELESS WEATHER STATION
MODEL NO.: WH1285 / WH1286
1. INTRODUCTION...............................................................................2
.......................................... .................................... ........2
2. INSTALLATION.......................................................................... .......3
2.1
2.2
2.2.1
Base Station...........................................................................5
2.2.2
Remote Sensor........................................................................5
3. OVERVIEW.......................................................................................6
3.1
3.2
3.3
3.4
3.5
3.6
4 PROGRAM MODE............................................................................10
4.4 Channel Mode...............................................................................11
5. TROUBLESHOOTING.....................................................................12
6. SPECIFICATION.............................................................................13
This Operation Manual is part of this product and should be kept in a safe place for future
reference. It contains important notes on setup and operation.
*NOTE: This is a combined operation manual for WH1285 and WH1286. WH1285 can
receive and display the DCF radio controlled time and date (RCC function). WH1286
maintain all the functions of WH1285 but without RCC function.
INSTRUCTION MANUAL
................................................................. ........2
.................................................................3
....................................................................................5
-LCD............................................. ................................6
..................................................................8
.................................................... ........9
...................................................................... ..............9
............................................................................9
.............................................................................. 10
..................................................................................11
...............................................................................11
.............................. .........................9
- 1 -
Page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WH1285 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fine Offset Electronics WH1285

Summary of Contents for Fine Offset Electronics WH1285

  • Page 1: Table Of Contents

    This Operation Manual is part of this product and should be kept in a safe place for future reference. It contains important notes on setup and operation. *NOTE: This is a combined operation manual for WH1285 and WH1286. WH1285 can receive and display the DCF radio controlled time and date (RCC function). WH1286 maintain all the functions of WH1285 but without RCC function.

  • Page 2: Introduction

    2) Wireless outdoor and indoor humidity 3) Digital barometer (mmHg, hPa/mb, inHg) 4) Memory max/min (for temperature, humidity and air pressure) 5) Radio controlled time and date with manual setting (WH1285 only). 6) Daylight saving time manual setting on/off 7) Comfort index...

  • Page 3: Installation

    12) Can receive up to 3 sensors 13) Wall hanging or free standing 14) Included one transmitter 15) Synchronized instant reception 16) Low battery indicator on the receiver 2. Installation 2.1 Installing the Batteries Note: Please note the polarity when inserting/replacing batteries in the unit, failure to do so may result in permanent damage.
  • Page 4 reception. The receiver will start RCC time reception period for 10 minutes maximum, and no weather data will be received during this period of time. If RCC signal can’t be synchronized with the base station within 1 minute, the signal search will be cancelled and will automatically resume every hour on the hour until the signal is successfully captured.

  • Page 5: Mounting

    Note: Please participate in the preservation of the environment by properly disposing of all used-up batteries and accumulators at designated disposal points. Never dispose of batteries in a fire as this may cause explosion, risk of fire or leakage of dangerous chemicals and fumes 2.2 Mounting 2.2.1 Base Station With one foldable legs at the back of the unit, the base station can be placed onto...

  • Page 6: Overview

    The temperature sensor is "weather resistant", but not "water proof". To ensure an extended life of your sensor, mount it in a semi-covered place out of the elements. An ideal location for the sensors is under the eaves. Avoid mounting remote sensor in direct sunlight.
  • Page 7 1. DCF tower icon for time reception 12. temperatuer unit 2. time 13. date/day of week 3. ice alert 14. alarm icon 4. weather forecast icon 15. alarm time 5. pressure display unit 16. MIN/MAX icon 6. pressure 17. differential barometer 7.

  • Page 8: Weather Forecasting

    3.2 Weather forecasting Wind If the air pressure decrease >=3mmHg/hPa within 3 hours, the wind icon will be displayed. For every sudden or significant change in the air pressure, the weather icons will update accordingly to represent the change in weather. If the icons do not change, then it means either the air pressure has not changed or the change has been too slow for the wireless weather station to register.

  • Page 9: Pressure Tendency Indicator

    3.3 Pressure tendency indicator The tendency indicators arrow is located beside the air pressure value to show the air pressure tendency and provide a forecast of the weather to be expected by the decreasing or increasing air pressure. The upward arrow means that the air pressure is increasing and the weather is expected to become better.

  • Page 10: Program Mode

    RH 45%~65% RH >65% comfort 4. Program Mode The base station has four keys for easy operation: SET key, ALARM key, MIN/MAX/- key, CH/+ key. 4.1 Setting Mode - While in normal mode, press the SET key shortly to shift the display of Time and Year.

  • Page 11: Alarm Mode

    14. Air pressure display units in hPa, mmHg or inHg 15. Air pressure value setting from 800hPa to 1100hPa. 16. Pressure threshold setting (default 2hPa, see 3.4) 17. Storm threshold setting (default 4hPa, see 3.5) 18. Weather forecast icon setting. - After the final mode, the manual setting returns to the normal display mode.

  • Page 12: Troubleshooting

    5. Troubleshooting Q 1. No signal from remote sensor A There can be many reasons for this, the following steps should help you troubleshoot this problem. 1.1 Make sure that the batteries in the remote sensor are not depleted. 1.2 Reduce the distance between transmitter and receiver 1.3 Remove the batteries from the base station and the remote sensor and reset the weather station in the right order as described in section 2 of this manual.

  • Page 13: Specification

    6. Specifications Outdoor data Transmission distance in open field : 80meter max. Frequency 433MHz Temperature range : -40℃ to +60℃ (show --- if outside range) Resolution 0.1℃ Measuring interval remote sensor 60 sec Humidity 20-99% Resolution Indoor data Measuring interval of temperature 60 sec Measuring interval of Pressure 10 minutes...

This manual is also suitable for:

Wh1286
