DIGITAL PAPER THIN INDOOR
TV ANTENNA
Amplified Version
Introduction:
This is a specially designed antenna for digital terrestrial TV broadcast reception. It is the best solution for digital home
and portable TV reception. This antenna is White on one side and Black on the other. Includes pre-amplifier with power
supply. Can be table mounted using the provided table stand or window mounted using the included double-sided
adhesive squares. Ultra thin at only ~0.03 inch thickness and lightweight soft design.
Technical Data:
Frequency Range: VHF: 47~230MHz / UHF: 470~862MHz
Receiving Range: UHF / VHF / FM
Gain: 30dB Max
Range: about 40 miles
Dimensions: 12.5 x 13.7 x .03 in
Output Level: 100dB
Impedance: 75Ohm
Noise Figure: 3.5dB
Power Supply: AC/C Adapter (DC12V/50mA)
Cable Downlead: 6 ft
Product Features:
Ultra Thin and Lightweight Soft Design
High Gain and Low Noise In-line Amplifier
Multi-positioning for best possible reception
Excellent reception for Digital, Free View and Analog TV Signals
Compatible with HDTV and other various Digital terrestrial signals (DVB-T, DVB-T2, ISDB-T, DMB-T/H, ATSC)
and DAB/FM radios.
Included in Package:
Before you start your installation, please check the contents.
1. ANI-9025 Antenna (White/Black)
2. Power Adapter
3. Table Stand
4. Doubel-Sided Window Mount Adhesive Squares
MAY 2015
ANI-9025
www.ani-av.com
Instruction Manual
PAGE 1 of 4
Advertisement
Table of Contents
Summary of Contents for ANi-AV ANI-9025
-
Page 1: Technical Data
Compatible with HDTV and other various Digital terrestrial signals (DVB-T, DVB-T2, ISDB-T, DMB-T/H, ATSC) and DAB/FM radios. Included in Package: Before you start your installation, please check the contents. 1. ANI-9025 Antenna (White/Black) 2. Power Adapter 3. Table Stand 4. Doubel-Sided Window Mount Adhesive Squares www.ani-av.com... - Page 2 Instruction Manual ANI-9025 DIGITAL PAPER THIN INDOOR TV ANTENNA Amplified Version Setting and Connections: Connect the antenna coaxial cable to a set-top box or TV with a digital tuner. Connect the DC plug of the AC/DC adapter to the in-line amplifier on the antenna and plug the AC/DC adapter into the AC power socket.
-
Page 3: Important Safety Instructions
Instruction Manual ANI-9025 DIGITAL PAPER THIN INDOOR TV ANTENNA Amplified Version Important Safety Instructions: 1. Read Instructions - All the safety and operating instructions should be read before the product is operated. 2. Retain Instructions - The safety and operating instructions should be retained for future reference. - Page 4 Instruction Manual ANI-9025 DIGITAL PAPER THIN INDOOR TV ANTENNA Amplified Version Important Safety Instructions: 17. Overloading - Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of fire or electric shock.
