MI DRONES AIR FIGHTER Manual

Advertisement

Quick Links

MAIN PARAMETERS:
Main blade diameter:
Frame length:
Battery:
Total weight:
Gyroscope:
MIAN FEATURES:
1:the 4 motors within the heli give the heli stable flight and enable it to perform the actions
easily
2:with the modularized structure, it's easy to install and convenient to disassemble for repair
3:with the 6 axis gyroscope and position control system automated, the heli can be easily
stopped and accurately aloft
4:once fully charged, the 3.7V220mAh Li-Po battery gives approximately 5-6 minutes flight
1.INTRODUCTION
Thanks for choosing MILLENNIAL product! This is a 4 axle aircraft which is capable of flying
in confined space and outdoor, in order for you to maneuver the R.C. helicopter more
conveniently and easily, please fly it only after this instruction manual is carefully read,
in the meantime, this manual shall be properly kept for future necessary adjustment
and repair work.
Suitable for indoor or outdoor which under Grade 3 winds.
WARNING LABEL LEGEND
WARNING
Mistakes made due to negligence
of these operation instructions may
cause property loss and severe
human injury.
62mm
149mm
3.7V220mAh
34g±2g
Built-in
CAUTION
Mistakes made due to
negligence of operation
instruction may cause
danger.
1
Frame width:
Frame height:
Main motor type:
Charge time:
Flight time:
149mm
38mm
6x15 4pcs
40 min
5-6 min
FORBIDDEN
Please do not fly the R.C.
helicopter under any
specified forbidden
environment.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AIR FIGHTER and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for MI DRONES AIR FIGHTER

  • Page 1 MAIN PARAMETERS: Main blade diameter: Frame width: 149mm 62mm 149mm Frame height: Frame length: 38mm Battery: 3.7V220mAh Main motor type: 6x15 4pcs Total weight: Charge time: 40 min 34g±2g Gyroscope: Built-in Flight time: 5-6 min MIAN FEATURES: 1:the 4 motors within the heli give the heli stable flight and enable it to perform the actions easily 2:with the modularized structure, it’s easy to install and convenient to disassemble for repair 3:with the 6 axis gyroscope and position control system automated, the heli can be easily...
  • Page 2 IMPORTANT NOTES This RC drone is not a toy, though it is just a mini RC 4 axle drone, it still could be dangerous. Please fly the model RC drone according to the manual instruction and its notices. Any modification, maloperation or unfamiliarity to the heli could bring about unexpected danger or accident, please be prudent.
  • Page 3 LI-Po battery is comparatively more dangerous than other batteries. Please make sure below instruction is carefully read and rigorously followed prior to using them. ATTOP shall not be responsible for any damages caused by improper operation of the battery. The battery can only be charged by authentic MILLENNIAL charger, otherwise it may lead to fire or explosion.
  • Page 4 5.Installation and attention of USB charger 1.Suitable for (3.7V) Li-polymer battery pack. 3.Operation steps 3.Charging statuses corresponding to LED LED status operation Charging status Step Connect the USB cable to LED is in red Power on the computer LED red light is off Charging Step 1 + connect the battery pin to USB cable...
  • Page 5 6.NOMENCLATURE “ V ” “ S ” battle switch speed switch power switch 40%/70%/100% ascend/descend L/R turning Flips button battery power case indicator light FORBIDDEN Forward/Backward L/R sideward fly D O n o t d i s a s s e m b l e (Power indicator light is red;...
  • Page 6 AUTO FREQUENCY ADJUSTING Pull the left stick to lower left corner and right stick to lower right corner simultaneously. After 3 seconds.LED light on the UFO head will flash, meansthe adjusting is complete.you can control the quadcopter now. MODE MODE ILLUSTRATION ILLUSTRATION move left...
  • Page 7 10.TROUBLE SHOOTING DURING FLIGHT ISSUES CAUSE SUGGESTIONS After the battery is inserted Frequency adjusting between Readjust frequency for remote in the heli, indicator light remote and receiver not and receiver.(please refer to P.6 on receiver keeps flashing, successful for details) no response to operations 1.check if the power for 1.open the transmitter and make...
  • Page 8 11.PARTS LIST NAME NAME NAME Airframe Upper Receiving housing housing board Main Main Rotor A axle motor Gear Main Motor cover gear seat Lower Transparent Battery housing parts door Li-battery Rotor B Materials, specifications for the parts and packing indicated in the instruction manual are only for reference, MILLENNIAL will not be responsible for their changes in future nor could we notify consumers.

Table of Contents
