TECHNICIAN SPECIFICATION
Headphone
Transducer type............................Dynamic
Operating principle .....................Closed
Frequency response.....................20–20,000Hz
Nominal impedance....................32Ω
Sound pressure level ..................111dB
Power handling capacity .............100 mW
Max. sound pressure level .......... 131 dB
Sound coupling to the ear ..........Supra-aural
Headband pressure ....................2.5N
Wireless technology....................Digital 2.4GHz
Paring type..................................Manually digital
Weight.........................................115g
Charging.....................................USB 2.0
Power..........................................3.7VDC
Current........................................40mA
Battery ........................................300mAh Li-Poly
Transmitting power......................5dbm
Transmitter / Receiver
Transmitter Cable......................... 25cm straight+5cm coil; 5cm straight(WR)
Connector......................................W3(3.5mm) W6(6.35mm) WA(AT pro)
Attaching.......................................Clip on rod or hang on.
Protection level..............................Indoor or outdoor using splash-proof
Control...........................................One touch button; three buttons (WR )
Weight ..........................................33g
Wire-Free
W3 W6 WA WR
Wireless Headphone Kit
*W3 Wireless Headphone Kit as demonstrated
d
.
premium
metal detector
accessories
Advertisement
Related Manuals for Deteknix Wire-Free W3
Summary of Contents for Deteknix Wire-Free W3
- Page 1 premium metal detector Wire-Free accessories TECHNICIAN SPECIFICATION W3 W6 WA WR Headphone Transducer type......Dynamic Wireless Headphone Kit Operating principle .....Closed Frequency response.....20–20,000Hz Nominal impedance....32Ω Sound pressure level ....111dB Power handling capacity .....100 mW Max. sound pressure level ..131 dB Sound coupling to the ear ..Supra-aural Headband pressure ....2.5N Wireless technology....Digital 2.4GHz...
- Page 2 Congratulations on your purchase of this Wire-Free headphone SAFETY INSTRUCTIONS kit. Before using your headphones for the first time, please take • When wearing the headphones, make sure the volume is turned to a moment to carefully read the following information. minimum.
- Page 3 1.2 POWER ON TRANSMITTER 1.1 HEADPHONE ADJUSTMENT Make sure the transmitter is fully charged and press the power Before wearing the Wire-Free lite headphone for the first time button for 1 second. The LED indicator will start to flash.
- Page 4 2.1 TRANSMITTER RECHARGING 1.5 TRANSMITTER ATTCHMENT You can recharge it thru smartphone charger(recommend) We provide two methods to attach the transmitter to your detector. laptop computer USB port, or power bank for emergency. For headphone jack on control box, you can clip it on the rod by elastic Plug the USB side into the port and insert the microUSB head band.
