1. Picasso Tablet
2. Pen
3. Pen Refill x 2
4. Tweezers
5. Pen Stand
• Dimension: 390mm * 263 mm *14mm
• Weight: 1078 g
• Active area: 10" * 6"
• Resolution:
- Windows 7, Vista, or XP with tablet driver installed: 4000 LPI
- Windows 7, Vista, or XP without tablet driver installed: 2000 LPI
• Report rate: 200 +/- 3 Reports/Second
• Pen pressure: 1024 levels
• Function Mode: Scroll, Zoom, Direction, Auxiliary (From left to
right). Under these 4 keys, there is one LED for each button.
Package Content
Windows
Specification
1
3
2
4
5
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for Penpower Picasso
- Page 1 Package Content Windows 1. Picasso Tablet 2. Pen 3. Pen Refill x 2 4. Tweezers 5. Pen Stand Specification • Dimension: 390mm * 263 mm *14mm • Weight: 1078 g • Active area: 10" * 6" • Resolution: - Windows 7, Vista, or XP with tablet driver installed: 4000 LPI - Windows 7, Vista, or XP without tablet driver installed: 2000 LPI •...
-
Page 2: Hardware Introduction
Hardware Introduction Macro-Key Mode Buttons Circular Circular Touch Pad Touch Pad Express Express The Picasso Tablet is a multi-functional USB HID digitizer. It integrates the digitizer, ten key switches, four mode buttoms and two circular touch pads into a device. - Page 3 The circular touch pad provides the following functions: the mouse's scroll function, volume control function, zoom-in/out function, keyboard four directions key function, and keyboard Page up/down/Home/End key function. Macro-Key There are ten software-shot-cuts named "Macro Keys" on the upper area. You can easily modify or change its setting by using the "MacroKey Manager"...
- Page 4 2. When Multimedia button is pressed, the touch pad becomes a zoom-in/out function. And when the Auxiliary button is also pressed, touch-pad becomes a volume-control function. 3. When Direction button is pushed, touch-pad become as a four direction keys. And when Auxiliary key is also pushed, circular touch-pad becomes a Page up/Page down/Home/ End function.
- Page 5 1. The Picasso tablet driver disk is integrated with Macro Key Manager. 2. If you use Windows 7 or Vista, Picasso tablet can be used by plug-and-play without installing any special driver and work well with Microsoft applications such as PowerPoint, Excel, Word, Windows Journal, OneNote and Paint.
- Page 6 Setting After installation, you can change the settings of MacroKey Manager by right clicking the icon on the bottom of Window Tool Bar. Then MacroKey Manager menu will appeare. Tablet Preferecnes Setting: Pen ◎...
- Page 7 We suggest you move the slider to “Soft.” Current Pressure: You can see the current pen pressure at this bar when you press the pen against the Picasso tablet. Pen Buttons setting: You can change the function of each button on the pen.
- Page 8 Tablet Preferecnes Setting: Mapping ◎ This feature allows you to ‘map’ your tablet to your monitor(s). You may allow the tablet to fit the size of you monitor by clicking “Full Area” or to a particular monitor, and you may also map it to a portion of your monitor.
- Page 9 Tablet Preferecnes Setting: Express Keys ◎ This menu is to configure the 10 “ExpressKeys” on both sides of the Muse tablet. MacroKey Response Time setting: ◎ You can set timer for how long MacroKey function will work. There are 5 different choices; 0, 0.5, 1, 2 and 3 seconds.The timing you choose will determine how long you must hold pen on MacroKey before it activates.You can choose to get the pointing sound or not while the pen tip is pointing on the Tablet.
- Page 10 MacroKey Manager Setting ◎ In Macrokey manage, you can easily modify or change its setting as the shortcut keys to, for example, specific websites.
- Page 11 Step 1: Insert the driver disk into your compute's CD-ROM drive. Step 2: Click the Pen Pad Tablet Driver icon and follow the installation steps to install Picasso Tablet driver. Step 3: Click Tablet Preference or MacroKey Manager icon to...
- Page 12 Setting Open Tablet Preferences or Setting window or Macrokey Setting window from Applications\Penpower Picasso\... Tablet Preferecnes Setting: Pen ◎ Tilt Sensitivity: You can customize how far you may tilt the pen so that it will still be recognized by the tablet. We suggest you move the slider to “High”.
- Page 13 Current Pressure: You can see the current pen pressure at this bar when you press the pen against the Picasso tablet. Pen Buttons setting: You can change the function of each button on the pen. Tip Double Click Distance: This slider determines how long the distance between double clicks is.
- Page 14 This feature allows you to ‘map’ your tablet to your monitor(s). You may allow the tablet to fit the size of you monitor by clicking “Full Area” , or to a particular monitor, and you may also map it to a portion of your monitor.
- Page 15 MacroKey Manager Setting ◎ In Macrokey manage, you can easily modify or change its setting as the shortcut keys to, for example, specific websites.
- Page 16 How to Replace the Pen Refill Step 1 Pull out the used pen nib with the Tweezers provided. Step 2 Insert the Pen Refill to the pen. Step 3 P r e s s f i r m l y o n a h a r d surface for 5 seconds till the Pen Refill is locked.
