- Page 1 Room Control Module (2000i-RCM) Installation Guide for the Rear Projection SMART Board™ 2000i-DV/DVX/DVS Interactive Whiteboard 99-00488-00 Rev B0...
- Page 2 © 2004 SMART Technologies Inc. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language in any form by any means without the prior written consent of SMART. Information in this manual is subject to change without notice and does not represent a commitment on the part of SMART.
-
Page 3: Table Of Contents
Contents Installing the Room Control Module ....................1 About the Custom Straight-Through I²C MOD6 Cables ....................1 To install the Room Control Module .........................2 Connecting to a Third-Party Room-Control System ......................7 Customer Support ..........................8 General Inquiries ................................8 Returning Defective Merchandise ...........................8 99-00488-00 Rev B0 Contents... - Page 4 Contents 99-00488-00 Rev B0...
-
Page 5: Installing The Room Control Module
When used on its own, you can’t use a third-party room control system to access the Control Panel features on the 2000i. For that, you need the SMART Room Control Module. You can then use the Control Panel or a third-party room-control system to change the standby state, source, display and volume settings for the 2000i. -
Page 6: To Install The Room Control Module
To install the Room Control Module CAUTION You should wear the supplied antistatic wrist strap throughout the installation process. This wrist strap protects electronic components from damage due to electrostatic discharge. Secure the adhesive end of the strap to your wrist and wrap the copper tape at the other end around any grounded object. - Page 7 While propping up the electronics tray with one hand (so it doesn’t fall suddenly), remove the two button head screws on either side of the tray using the 5/32" hex key (included in the accessory kit for the 2000i). Put the screws in a safe place, as you’ll use them to secure the electronics tray at the end of the installation procedure.
- Page 8 Detach the Audio Amplifier board from the electronics tray without disconnecting any attached cables: Using a Phillips No. 2 screwdriver, remove the four screws and washers that secure the board to the tray. Keep these screws and washers handy, as you’ll reattach the board later.
- Page 9 Connect the supplied 6" (15.2 cm) I²C MOD6 cable to either jack on the Room Control Module. Room Control Module I²C MOD6 Cable Connecting the Supplied MOD6 Cable 10. Install the Room Control Module on the studs in the bottom of the electronics tray. Using the Phillips No. 2 screwdriver, secure the Room Control Module in place with the screws and washers supplied in the kit.
-
Page 10: Connecting To A Third-Party Room-Control System
If you have an X-Port 20 switch installed, connect the I²C MOD6 cable from the Room Control Module to an I²C MOD6 connector on the X-Port 20 switch. Refer to the X-Port 20 Switch Installation Guide for the Rear Projection SMART Board 2000i-DV/DVX Interactive Whiteboard or the X-Port 20 Serial/Video Switch Installation Guide for the Rear Projection SMART Board 2000i-DVS Interactive Whiteboard for detailed instructions. - Page 11 Connect the DB9F end of a DB9F/custom cable to the Control port on the back of the 2000i. This cable isn’t supplied by SMART Technologies. Usually, your third-party room control vendor would supply this cable. Control Port DB9F End of...
-
Page 12: Customer Support
Contacting SMART Technical Support SMART’s Technical Support team welcomes your call. However, you may first want to contact your local reseller if you experience any difficulties with your SMART product, as they may be able to solve the problem without delay.
