FREE STANDING RANGE
GAS AND ELECTRIC
APPLIANCES
CU 36P OE/ISPH
MOD: Oven Gas Range – Oven Dual Fuel Range
MOD.: Oven Gas Range
Oven Dual Fuel Range
INSTRUCTION GUIDE, INSTALLATION
AND MAINTENANCE
IMPORTANT: SAVE THESE INSTRUCTIONS.
■ IMPORTANT SAFETY INSTRUCTIONS ■
Read and follow all instructions before using this appliance to prevent
the potential risk of fire, electrical shock, personal injury or damage to the
appliance as a result of improper usage of the appliance. Use appliance only
for its intended purpose as described in this manual. The Installer must leave
these instructions with the appliance and to the consumer to retain them for
future reference.
WARNING: If the information in this manual is not followed exactly, a
fire or explosion may result causing property damage, personal injury
or death.
Do not store or use gasoline or other flammable vapors and liquids in
the vicinity of this appliance.
WHAT TO DO IF YOU SMELL GAS:
- Do not to light any appliance.
- Do not touch any electrical switch.
- Do not use any phone in your building.
- Immediately call your gas supplier from a neighbour's phone. Follow
the gas supplier's instructions.
- If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer,
service agency or the gas supplier.
1
9880023200-CU 36P NEUTRO 120312
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Smalvic CU 36P OE/ISPH
-
Page 1: Important Safety Instructions
FREE STANDING RANGE GAS AND ELECTRIC APPLIANCES CU 36P OE/ISPH MOD: Oven Gas Range – Oven Dual Fuel Range MOD.: Oven Gas Range Oven Dual Fuel Range INSTRUCTION GUIDE, INSTALLATION AND MAINTENANCE IMPORTANT: SAVE THESE INSTRUCTIONS. ■ IMPORTANT SAFETY INSTRUCTIONS ■... -
Page 2: Important Safeguards
WARNING: To avoid risk of property damage, personal injury or death; follow information in this manual exactly to prevent a fire or explosion. DO NOT store or use gasoline or other flammable vapors and liquids in the vicinity of this or any appliance. To ensure proper and safe operation: Appliance must be properly installed and grounded by a qualified installer. - Page 3 User servicing. Do not repair or replace any part of the appliance unless specifically recommended in the manual. All other servicing should be referred to a qualified technician. Storage in or on appliance. Flammable materials should not be stored in an oven or near surface units.
- Page 4 Do not touch surface units or areas near units as well as oven gas burner or interior oven surface. Surface units and oven gas burners may be hot even though they have no flame. Areas near surface units and interior oven surfaces may become hot enough to cause burns.
- Page 5 In case of power failure, hold a lit match to the desired burner head. Push in and turn the knob counter clockwise to the LIGHT-HIGH setting. After the burner lights, turn the knob to the desired flame size. Caution: When lighting the burner, be sure all of the controls are in the OFF position.
- Page 6 TO CHANGE TIME OF DAY Press the button for 4 seconds until the hours display will flash. Change the hours only by using the “+” or “-” button. The minutes and hidden seconds will not be affected. TO SET TIMER FUNCTION This function will be activated with “+”...
- Page 7 ■ SELECTOR SWITCH ON GAS OVEN RANGE MOD: Oven Gas Range This control allows you to turn on the Oven Internal Light or Oven Forced Air Convection Fan for cooking or defrosting purposes. See fig. 07. LIGHT OVEN; Use this setting to turn on Oven light, light also remains on in all other modes.
- Page 8 Displays: 4-digit 7-segment display for time of day and switching times. “Dialogue” display to identify condition of timer. Setting: Select a function by pressing the function button and set the required time with buttons. +/- Buttons: Pressing the button increases the time set, pressing decreases it.
- Page 9 Minute Minder: Select button and set required time with button. As the time set elapses the bell symbol is displayed. After the time set has elapsed, the audible signal sounds. Audible Signal: The audible signal (1 Hz interval) sounds at the end of a minute minder cycle or of a cooking program for a period of 7 minutes.
-
Page 10: Convection Roast
ROAST Use this setting for standard roasting. The bottom and top elements heat up the air. BAKE Use this setting for bottom baking. This intensive heat is best for cooking less tender meats. CONVECTION ROAST Use this setting for Roasting on one rack. The bottom and top elements heat up. - Page 11 ■ GENERAL NOTES MOD: Oven Gas Range – Oven Dual Fuel Range CAUTION 1) Do not store or use gasoline or other flammable vapours, liquids or items in the vicinity of this or any other appliance. 2) Never use appliance as a space heater to heat or warm a room. 3) Do not obstruct the flow of combustion and ventilation air by blocking the room vents or air intakes.
-
Page 12: Cleaning Safety
Burner operational Notes, fig. 08A: - A properly adjusted burner with clean ports will light within a few seconds. If using natural gas the flame will be blue with a deeper blue inner cone. - If the burner flame is yellow or is noisy the air/gas mixture maybe incorrect. Contact a service technician to adjust. -
Page 13: Abnormal Operation
Although, to determine if a cleaning product is safe, test a small inconspicuous area using a very light pressure to see if the surface may scratch or discolour. This is particularly important for porcelain enamel, highly polished, shiny, painted or plastic surfaces. ABNORMAL OPERATION Any of the following are considered to be abnormal operation and servicing is required. -
Page 14: Replacing The Oven Light
TO REPLACE THE OVEN DOOR 1) Grasp the sides of the door at the center and insert the ends of the hinges and fix hinge slots in the oven front frame. 2) With the door open all the way, pull-out the two Locking Pins (B) from the hinge Locking Holes(A). -
Page 15: Clearance Dimensions
■ INSTALLATION INSTRUCTIONS MOD: Oven Gas Range – Oven Dual Fuel Range SPECIAL WARNING: ONLY QUALIFIED AND AUTHORIZED PERSONNEL MUST INSTALL OR SERVICE THIS RANGE. READ “SAFETY INSTRUCTIONS” IN THIS BOOK BEFORE USING RANGE. IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE, MAINTENANCE OR USE OF RANGE CAN RESULT IN SERIOUS INJURY OR PROPERTY DAMAGE, AND SO THE MANUFACTURER WILL NOT BE RESPONSIBLE. - Page 16 CAUTION: SOME CABINETS AND BUILDING MATERIALS ARE NOT DESIGNED TO WITHSTAND THE HEAT PRODUCED BY THE NORMAL SAFE OPERATION OF A LISTED APPLIANCE. DISCOLORATION OR DAMAGE, SUCH AS DELAMINATION, MAY OCCUR. LOCATING THE RANGE Do not set range over holes in the floor or other locations where it may be subject to strong drafts.
- Page 17 C. Use the bracket as a template and mark the required holes, as shown in figure 14, for the type of construction you will be using. STEP 2 – Anti-Tip Bracket Installation Locate the center of the two holes to be drilled on the wall. Drill a 1/8” pilot hole in the centre of each hole.
-
Page 18: Electrical Supply
■ CONNECTING THE RANGE MOD: Oven Gas Range – Oven Dual Fuel Range ELECTRICAL SUPPLY The appliance, when installed, must be electrically grounded in accordance with local codes or, in absence of local codes, with National Electrical Code, ANSI/NFPA 70 In Canada the appliance must be installed in accordance with the current CSA Standard C22.1 - Canadian Electrical Code part 1. - Page 19 In case of a fixed connection to junction box, a 1/8” open gap two way switch must be used before the Junction Box. Install a suitable flexible cord, through Junction Box on rear of NOTE: appliance, to oven electrical terminal block. Follow fig. 15A and fig. 15B for proper electrical connection of flexible cord to appliance terminal block.
- Page 20 WARNING: DISCONNECT ELECTRICAL SUPPLY BEFORE SERVICING THE APPLIANCE. When the flexible cord has to be changed it is necessary to follow the procedure hereafter described: -Turn off main gas shut-off valve and disconnect electrical supply -Pull out entire range from the counter. -Disconnect gas supply connector from appliance gas manifold -Open up connecting terminal block cover.
- Page 21 Natural gas supply line must have a natural service regulator. Inlet pressure to this appliance should be reduced to a maximum of 7 inches water column. Liquefied Petroleum L.P. / Propane gas supply line must have a L.P. gas pressure regulator. Inlet pressure to this appliance should be reduced to a maximum of 14 inches water column.
-
Page 22: Gas Conversion
CAUTION: NEVER CHECK FOR LEAKS WITH A FLAME. WHEN LEAK CHECK IS COMPLETE, WIPE OFF ALL RESIDUE. i) Remove shipping polystyrene from ALL rangetop burners. This is to hold the burners in place on the burner base for shipping purposes only. This should be done last CHECKING PRESSURE OF HOUSE PIPING SYSTEM 1) The appliance and its individual shutoff valve must be disconnected from... - Page 23 In case of yellow flame on oven gas burner ( as well as of MOD: VEFSGGL65) distinct blue flame but lifting, call the technical assistance centre for further control and fix to solve the problem. ■ APPLIANCE PRESSURE REGULATOR CONVERSION MOD: Oven Gas Range –...
-
Page 24: Dimensions Of The Appliances
■ RANGETOP AND OVEN BURNER TECHNICAL DATA MOD: Oven Gas Range – Oven Dual Fuel Range (NATURAL GAS) MAX POWER BTU/HR Injector Valve burner adjusting screw BURNER Natural HIGH SIMMER HIGH by-pass SIMMER by-pass U-POWER 18500 1.80 0.81 1.00 – close 0.66 –... - Page 25 FIGURES ■ MOD: Oven Gas Range – Oven Dual Fuel Range MOD: Oven Gas Range – Oven Dual Fuel Range Fig. n° 01 Fig. n° 02 MOD: Oven Gas Range Fig. n° 03 MOD: Oven Gas Range Fig. n° 04 MOD: Oven Gas Range MOD: Oven Dual Fuel Range MOD: Oven Dual Fuel Range...
- Page 26 Fig. n° 08 Fig. n° 09A Fig. n° 09B Fig. n° 10 9880023200-CU 36P NEUTRO 120312...
- Page 27 Fig. n° 11 Fig. n° 12 9880023200-CU 36P NEUTRO 120312...
- Page 28 Fig. n° 13 One bracket either location Fig. n° 14 9880023200-CU 36P NEUTRO 120312...
- Page 29 Fig. 14A Fig. n° 15A Fig. n° 15B TERMINAL BLOCK CONNCTION FOR CANADA TERMINAL BLOCK CONNCTION FOR US 120/240V AC 60 Hz 120/208V AC 60 Hz MOD: Oven Dual Fuel Range MOD: Oven Dual Fuel Range MOD: Oven Gas Range Fig.
- Page 30 Fig. n° 16 Fig. n° 18A MOD: Oven Gas Range – Oven Dual Fuel Range Fig. n° 17A Fig. n° 18B MOD: Oven Gas Range Fig. n° 17B 9880023200-CU 36P NEUTRO 120312...
-
Page 31: Control Panel Features
■ CONTROL PANEL FEATURES Fig. n° 19 Control Panel on range model: Oven Dual Fuel Range Control Panel on range model: Oven Gas Range 9880023200-CU 36P NEUTRO 120312... - Page 32 BACKGUARD FIXING PROCEDURE ■ MOD: Oven Gas Range – Oven Dual Fuel Range First, unpack Backguard from Range packaging. Second, STEP 1: holding backguard in the upright position, insert slotted pin into the external cut, as shown in the figure. Third, STEP 2: holding backguard in the upright position, slide it forward till the vertical back lower flange is touching the back...
- Page 33 WIRING DIAGRAM FOR RANGE WITH GAS OVEN MOD: Oven Gas Range WIRING DIAGRAM FOR RANGE WITH ELECTRIC OVEN MOD: Oven Dual Fuel Range 9880023200-CU 36P NEUTRO 120312...
