SD Digital Video Recorder
Please read this User's Manual carefully to ensure that you can use the device correctly and
safely. The contents of this manual are subject to change without notice.
Page 1 of 22
ŽŠ“ŽªŽ¡ Š˜Ž¡Š£ šŒ
ŽŠ“ŽªŽ¡ Š˜Ž¡Š£ šŒ
ŽŠ“ŽªŽ¡ Š˜Ž¡Š£ šŒ
ŽŠ“ŽªŽ¡ Š˜Ž¡Š£ šŒ
DVR-SD
User's Manual
SeaViewer DVR-SD Manual
02/15/2011
Advertisement
Table of Contents
Summary of Contents for SeaViewer DVR-SD
- Page 1 SD Digital Video Recorder User’s Manual Please read this User’s Manual carefully to ensure that you can use the device correctly and safely. The contents of this manual are subject to change without notice. Page 1 of 22 SeaViewer DVR-SD Manual 02/15/2011...
-
Page 2: Important Notice
9. Use the device only with the accessories coming with it. 10. Avoid dropping the unit. 11. Contact SeaViewer in the USA for repair when needed. Phone 813.242.6160 12. The device can only be installed horizontally. Installing vertically or out of the horizontal plane might cause injury or damage to the device and/or its parts. -
Page 3: Table Of Contents
6.1 Power supply ................16 6.2 Manage the power ..............17 6.3 AV cables................... 19 6.4 Attaching a Camera ..............20 7. Specification ................. 21 8. List of Standard Accessories ............22 Page 3 of 22 SeaViewer DVR-SD Manual 02/15/2011... -
Page 4: Main Features
You can use the following player to play back the record file on a computer. the software provided by us VLC media player version1.0.0 or above Storm player(Version 2009 or above Winamp Version 5.531 or above Page 4 of 22 SeaViewer DVR-SD Manual 02/15/2011... -
Page 5: Overall Description
DVR has Power and is turned ON. On Steady Blinking to turn OFF, hold POWER Button on remote for at least 3 seconds. 3. Alarm light (Red) Description (not used) (not connected) Page 5 of 22 SeaViewer DVR-SD Manual 02/15/2011... - Page 6 Removing SD CARD in this status may cause damage. Flashes SD Card is being accessed (such as Playing or Formatting) Don’t remove the SD CARD in this status. Page 6 of 22 SeaViewer DVR-SD Manual 02/15/2011...
-
Page 7: Remote Control
We use only Channel 1. 6 To delete a character in a text edit field, you can press <Left for at least 3 seconds 7 Press <POWER to turn on/off the recorder; Page 7 of 22 SeaViewer DVR-SD Manual 02/15/2011... -
Page 8: Using The Recorder With The Remote Control
Resolution Maximum bit Minimum bit Audio Capacity rate Bit/s rate Bit/s Bitrate need Bit/s BASIC 2/3 D1 350K 210K 119M/hour NORMAL 1000K 600K 346M/hour GOOD 1200K 720K 540M/hour HIGH 1500K 900K 720M/hour Page 8 of 22 SeaViewer DVR-SD Manual 02/15/2011... -
Page 9: Step 2: Start Recording
Press <STOP> and then <OK> at the prompt to stop recording. If you do not do this, the recorder may continue to record, even if you press the <PLAY> button on the remote to watch another recording on the screen. Page 9 of 22 SeaViewer DVR-SD Manual 02/15/2011... -
Page 10: Step 3: Play Back The Files On Sd Card With Dvr
Press the <PLAY> button on the remote, the recorder will play back the most recent file. Press <Next>/<Previous> to select the next or previous file. The play status is indicated by a green triangle on the top right corner of the screen. Page 10 of 22 SeaViewer DVR-SD Manual 02/15/2011... - Page 11 TIME” in the sub menu. Select the time you want to seek and choose <OK>. The recorder will list the record file around the time you set. Then press <PLAY> to play the file. Page 11 of 22 SeaViewer DVR-SD Manual 02/15/2011...
- Page 12 Page 12 of 22 SeaViewer DVR-SD Manual 02/15/2011...
-
Page 13: Adding Additional Sd Or Sdhc Cards
4. Adding additional SD or SDHC Cards Step 1: Choosing a new SD or SDHC Card The DVR-SD can accept most SD or SDHC Cards up to 64 GB capacity. BUT: Not all brands of SD Cards are the same internal architecture. Some are more compatible than others in different devices. -
Page 14: Using External Devices
FOLLOW THE PROPER REMOVAL PROCEDURE to remove the SD Card before attempting to open or manipulate the files on your device (computer). Page 14 of 22 SeaViewer DVR-SD Manual 02/15/2011... -
Page 15: Viewing The Files On Another Device
5.3 Editing the files on another device Editing the video on a PC may be accomplished with many third-party editing suites using the CODECS listed below (available on the Internet): - ffdshow - K-Lite Codec Pack (Standard installation) Page 15 of 22 SeaViewer DVR-SD Manual 02/15/2011... -
Page 16: Appendix
All the cables for connecting from power to the DVR should be thick enough for current over 5 Amperes. To protect the battery from being damaged of short circuit on the cable, the fuse should be placed very closed to the battery. Page 16 of 22 SeaViewer DVR-SD Manual 02/15/2011... -
Page 17: Manage The Power
2 Turn on/off the recorder automatically 1. Connect the DVR to the battery. Please note that you need to connect the yellow wire (ignition wire) to the “+” pole (+12V or +24V) of the battery. Page 17 of 22 SeaViewer DVR-SD Manual 02/15/2011... - Page 18 2. Select “POWER ON” and “POWER OFF” in the “Power” sub menu and set the time you want to turn on/off the recorder. If you don’t need to turn on/off the recorder automatically, set the “POWER ON” and “POWER OFF” time to 00 00 . Page 18 of 22 SeaViewer DVR-SD Manual 02/15/2011...
-
Page 19: Av Cables
6.3 AV cables AV cables Mark Description Video input Audio input Power output for camera(+12 VDC, Maximum current 1A) Ground Page 19 of 22 SeaViewer DVR-SD Manual 02/15/2011... -
Page 20: Attaching A Camera
Power output for camera(+12 VDC, Maximum current 0.5A) Ground 6.4 Attaching a Camera Connect the camera as the picture shows. The yellow connector is for video and the white connector is for audio. Page 20 of 22 SeaViewer DVR-SD Manual 02/15/2011... -
Page 21: Specification
5 - 0 0 / D Q S R U W 2 3 7 , 2 1 * 3 6 6 X S S R U W H G 2 3 7 , 2 1 Page 21 of 22 SeaViewer DVR-SD Manual 02/15/2011... -
Page 22: List Of Standard Accessories
AV input cable 1 pc for one channel AV output cable 1 pc for one channel Remote 1 pc Power cable 1 pc 8 GB SD Card 1 pc 12-VDC Microphone (unwired) 1 pc Page 22 of 22 SeaViewer DVR-SD Manual 02/15/2011...
