Yoda VG400R User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VoIP Router
User's Guide
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VG400R and is the answer not in the manual?

Questions and answers

Summary of Contents for Yoda VG400R

  • Page 1 VoIP Router User’s Guide...
  • Page 2 Trademarks Contents are subject to revise without prior notice. All trademarks belong to their respective owners. FCC Warning This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS 1. ABOUT THIS GUIDE ............1 1.1 Before Start up ..............1 1.2 Notation Conventions (for console or telnet setting)..2 2. START UP PREPARATION ...........4 3. WAN CONFIGURATION ..........5 3.1 Static IP Address Environment .........5 3.2 Dynamic IP Address Environment .........11 3.2.1 Applying for a host name in the dynamic IP environment ..............12 3.2.2 PPPoE application set up...........13...
  • Page 4 7. CONFIGURATION EXAMPLES (USE CONSOLE OR TELNET COMMANDS) ..........68 7.1 The default dial-plans ............68 7.2 ITG to ITG in the Static IP Address Environment..70 7.3 ITG to ITG in the Dynamic IP Address Environment ..75 7.4 PBX related issues............79 7.4.1 CP Tone Detection ............79 7.4.2 Call Security..............79...

  • Page 5: About This Guide

    1.ABOUT THIS GUIDE This Guide uses VG400R as a general example and contains the following information: Start Up Preparation: This chapter illustrates how to prepare for the Internet Voice Gateway (VG) set up through console interface or network interface. WAN Configuration: You will learn how to set up IP address and related configuration for your VG-400R in WAN side environments such as static IP address, dynamic IP address.

  • Page 6: Notation Conventions (For Console Or Telnet Setting)

    A PC that may run a web browser program such as Netscape, Internet Explorer, etc. A 10/100 BaseTX Cat. 5 Ethernet LAN cable with RJ-45 connector. A console cable, where you may find it in the ITG package (for 4/8xxR). And later on, you are required to get familiar with your environment, your TCP/IP network and your phone systems.
  • Page 7 “string” A non-quoted set of characters. Do not use quotation marks around the string or the string will include the quotation marks. <key> A key on the VT-100 terminal or terminal emulator. For example <Enter> denotes the Enter key.

  • Page 8: Start Up Preparation

    2.START UP PREPARATION This chapter shows you how to prepare for the VG-400R set up for your network and/or Internet. We will focus on the web browser usage. Since the VG-400R comes with two default IP addresses, one is for LAN side that is “192.168.0.1” and the other is for WAN side that is “172.16.0.1”.

  • Page 9: Wan Configuration

    3.WAN CONFIGURATION We will show you the basic steps for a typical VG-400R connection in various environments. It includes static IP address environment and dynamic IP address environment. 3.1 Static IP Address Environment There are several typical static IP address environment where the following procedure may apply, such as popular broadband application with ADSL or Cable network.
  • Page 10 Enter eitg in “User Name” field and 123 in “Password” field Then select “OK”, VG-400R will show the “Main Menu” as follows:...
  • Page 11 Click “NAT” for all the WAN/LAN related settings, and VG-400R will display the following:...
  • Page 12 Click “WAN” for WAN Configuration Menu, and VG-400R will display the following screen:...
  • Page 13 Click “Fixed IP” to enter all fix IP related information:...
  • Page 14 Fill in “IP address”, “Subnet Mask”, and “Gateway (Router) IP address” associated with this VG-400R. Fill in “Primary DNS server” and/or “Secondary DNS server” with IP address that ISP has provided. Fill in “IP TOS” parameter for ‘Precedence’, ‘Delay’, ‘Throughput’ and ‘Reliability’ if your ISP provided. The ranges of these parameters are: Precedence: Routine(Low),...

  • Page 15: Dynamic Ip Address Environment

    Reboot the VG-400R when the above information is stored successfully. 3.2 Dynamic IP Address Environment In this section we will show you how to obtain a valid host name in the dynamic IP address environment first, followed by the way to set up a typical VG-400R connection in the dynamic IP address environment via built-in PPPoE, DHCP, and DDNS clients.

  • Page 16: Applying For A Host Name In The Dynamic Ip Environment

    3.2.1 Applying for a host name in the dynamic IP environment First, it is required to apply for a DDNS host name from http://www.dyndns.org for the VG-400R. (For example, the name you may obtain is mary01.dyndns.org for the VG-400R.) mary01.dyndns.org is applied for the ITG. If you have already obtained a valid host name with your user name and password from the dynamic DNS server such as www.dyndns.org, you may skip the following and go to...

  • Page 17: Pppoe Application Set Up

    11) Click “Add Host” if another host name is needed and go to Step 10, otherwise the host name application is done. The DDNS configuration please refers Chapter 5.7 for detailed. Hint 3.2.2 PPPoE application set up In this section we’d like to introduce steps to setup the PPPoE application for dynamic IP address environment.
  • Page 18 Click “NAT” for all the WAN/LAN related settings, and VG-400R will display as follows:...
  • Page 19 Click “WAN” for WAN Configuration Menu, and VG-400R will display the following screen:...
  • Page 20 Click “PPPoE” and prepare to key in all PPPoE related information:...
  • Page 21 Select “ON” for PPPoE, key in “User name” and “Password” that ISP has provided. “Service name” may be entered if your ISP has also provided it. Click “OK” to store all the above information.

  • Page 22: Dhcp Application Set Up

    Reboot the VG-400R when all the above settings are stored successfully. 3.2.3 DHCP application set up In this section we’d like to show you how to configure the DHCP Client application for dynamic IP address environment. Use Browser to get into the “Main Menu”:...
  • Page 23 Click “NAT” for all the WAN/LAN related settings, and VG-400R will display the following screen:...
  • Page 24 Click “WAN” for WAN Configuration Menu, and VG-400R will display the following screen:...
  • Page 25 Click “DHCP Client” for DHCP Client Settings, and VG-400R will display the following screen:...
  • Page 26 At “DHCP Client” field, select “on” for enable DHCP client. Key in “Router name” and “Domain name” if ISP required. At “Use local MAC addr.” field, select “Yes”, if ISP requires Local MAC addr. for link authentication, and fill in the following “Local MAC addr.
  • Page 27 Reboot the VG-400R when all the above settings are stored successfully.

  • Page 28: Lan Configuration

    4.LAN CONFIGURATION We will show you the basic steps for configuring a typical VG-400R in the LAN environment. 4.1 LAN Interface Configuration Run Web Browser such as Netscape or Internet Explorer. the address field to 192.168.0.1 then hit the enter key. VG-400R will respond with the following page.
  • Page 29 follows. Click “NAT” for all the WAN/LAN related settings, and VG-400R will display the following screen:...
  • Page 30 Click “LAN” for LAN Configuration Menu...
  • Page 31 Specify the LAN Port IP Address, and Subnet Mask. About DHCP Server setting, you can specify the number of DHCP clients, the range is ‘1’ to ‘253’ and ‘0’ will disable DHCP Server. Fill in the “Client start address” to specify the start IP address if DHCP Server is enable.
  • Page 32 Reboot the system if all the above settings are saved.

  • Page 33: Advanced Features

    5.ADVANCED FEATURES This chapter shows you the advanced features of VG-400R and helps you to configure your ITG step-by-step for LAN access management. 5.1 Access to Advanced Features Menu Use Browser to get into the “Main Menu”: Click “NAT” for all the WAN/LAN related settings, and VG-400R will display the following screen:...
  • Page 34 Click “Advanced Features” for the Advance Features Menu, and start the Advanced Features setting.

  • Page 35: Dmz Configuration

    5.2 DMZ Configuration This option allows one computer on your LAN to be exposed to all users on the Internet. Get into “Advanced Features” Click “DMZ” and prepare to key in all related information:...
  • Page 36 Switch “DMZ” field to ‘on’. Enter the destination device’s IP address in “NAT DMZ host” field. Click “OK” to store all above data.
  • Page 37 Reboot the system to make these changes effective.

  • Page 38: Virtual Servers Configuration

    5.3 Virtual Servers Configuration This option allows servers on your LAN to be accessible by Internet users. The NAT router redirects the external port to the internal port. If a web server 192.168.0.20 (port number 80) is behind the NAT router, and Internet user need to access this web server via port 8080, then you should do the following steps: Get into “Advanced Features”...
  • Page 39 Enter 8080 in “External Port #” field. Enter 192.168.0.20 in “Internal IP” field. Enter 80 “Internal Port #” field. Choose the TCP in “Protocol” field. Tick the “Active” field to enable Virtual Server function. Click “OK” to store all above data.
  • Page 40 Reboot the system to make these changes effective.

  • Page 41: Port Forwarding Configuration

    5.4 Port Forwarding Configuration This option also allows servers on your LAN to be accessible by Internet users. The NAT router directly forwards the external ports to the internal ports. If a server 192.168.0.30 (port 1040 to port 1060 ) is behind a NAT router, and could be accessed by Internet user via TCP port 1040 to port 1060, then the following steps should be taken:...
  • Page 42 Enter 192.168.0.30 in “Internal IP” field. Enter 1040 in “Port number from” field. Enter 1060 in “Port number to” field. Choose TCP in “Protocol” field. Tick “enable” field to enable Port Forwarding function. Click “OK” to store all above data.
  • Page 43 Reboot the system to make these changes effective.

  • Page 44: Special Applications Configuration

    5.5 Special Applications Configuration This option allows certain Internet applications, which use non-standard TCP/UDP ports to pass through the NAT router. If a PC 192.168.0.20 is behind the NAT router, it will use TCP port 1400 to port 1404 as source port to access an Internet server, and the Internet server will respond to the PC with UDP packets of port number 1300 as destination port, then the following steps should be taken:...
  • Page 45 Enter 1300 in “In Port no. from” field. Enter 1300 in “In Port no. to” field. Choose UDP in “In Protocol” field. Enter 1400 in “Out Port no. from” field. Enter 1404 in “Out Port no. to” field. Choose TCP in “Out Protocol” field. Enter the description in “Description”...
  • Page 46 Reboot the system to make these changes effective.

  • Page 47: Access Control Configuration

    5.6 Access Control Configuration This option allows you separate hosts in LAN into groups and define WAN access policy for each LAN group. Each Workgroup has its own packet filter table, which defines how to block the PC or LAN devices. For example a PC 192.168.0.10 belongs to Workgroup 1, and the number of Workgroup 1 is not allow to access any HTTP server in the Internet, then the following steps should be taken:...
  • Page 48 Use Workgroup and Packet Filter Table settings to control the user’s access authority.

  • Page 49: Workgroup Access Configuration

    5.6.1 Workgroup Access Configuration The Workgroup option allows you to separates host in the LAN into workgroups, each workgroup is associated with a unique packet filter table. Click “Workgroup” and prepare to define the workgroup.
  • Page 50 Enter 1 in “Select a Workgroup number” field. Enter Operation in “Description” Choose ”add” and “IP” in “addr type” field Enter 192.168.0.10 “Address” field. Click “OK” to store all above data.

  • Page 51: Packet Filter Table Configuration

    5.6.2 Packet Filter Table Configuration This option allows you to define packet filter policies for each. Click “Packet Filter Table” and prepare to key in all related information:...
  • Page 52 Enter 1 in “Select a Workgroup number” field. Choose ”add” and “TCP” that you want to block. Enter the starting block port number 80 in “Port range from” field. Enter the ending block port number 80 in “Port range to” field. Click “OK”...

  • Page 53: Dynamic Dns Configuration

    5.7 Dynamic DNS Configuration The Dynamic Domain Name Server allows Internet Users to connect to your Virtual Servers using a URL rather an IP address. Get into “Advanced Features” Click “Dynamic DNS” and prepare to key in all DDNS related information:...
  • Page 54 Choose “ON” for enable DDNS in Dyn-DNS field. Key in “Server Name”, “Host Name”, “User Name”, and “User Password” provided by your Dynamic DNS service provider. Click “OK” to store all the above information.
  • Page 55 Click “Store” to store information in the Flash memory.
  • Page 56 Reboot the VG-400R when all the above settings are stored successfully.

  • Page 57: Dial Plan Set Up

    6.DIAL PLAN SET UP This chapter shows you the basic concept and steps to help you configure your ITG through the LAN port. It includes the VG-400R voice port and Dial Plan. 6.1 Concepts 6.1.1 The Voice Port There are two types of voice port, FXO (Foreign eXchange Office) and FXS (Foreign eXchange Station).

  • Page 58: The Dial Plan

    The FXO port cannot connect to a device such as telephone or fax machine since they do not provide Hint any phone number / extension and cannot generate any ring signal. If you connect those to the FXO port, you may hear nothing once you pick up the handset.
  • Page 59 Destination 1) Phone Number The “Phone number” associated with the VG-400R is a set of digits. You may look at that as an area code associated with your phone number. This number will only map to one Hunt Group in this example. You may reference to Section 7 for more details regarding configuration and Dial Plan examples.

  • Page 60: Web Browser Configuration

    The “Destination ID” here is an interpreter between Hunt Group and physical Destination. Hunt Groups may map to the same destination ID. The destination is either a local physical port or a remote IP address that ITG should make a call to. Each Destination ID maps to a physical destination.
  • Page 61 Click “VOIP” for all the telephony related settings, and VG-400R will display as follows:...
  • Page 62 You are advised to set up your Dial Plan associated with the VG-400R first before dialing any number and making a VoIP phone call. Click ”Dial Plan”, it will display as follows:...
  • Page 63 Click “Phone/Hunt Group/Destination Settings” and prepare to enter phone numbers, and VG-400R prompts the following:...
  • Page 64 Choose “Add”, “Telephone”, and “Select”, and VG-400R will display the following screen:...
  • Page 65 Fill in the information associated with “Telephone Number”, “Hunt Group ID”, “Min. Digits”, “Max Digits”, and “Strip Length”. Make sure the above data is correct then click “Complete”. Telephone Number – A set of digits. You may look at that as an area code associated with the remote Gateway.
  • Page 66 Strip Length – The number of digits needed to be strip off from the beginning of the dialing digits. Append prefix – The digits needed to be appended in front of the dialing digits after it is stripped for the strip length. The newly added telephone number will be displayed for confirmation as follows: Choose “Add”...
  • Page 67 Enter the information related to “Hunt Group ID” and “Destination ID”, then click “Complete”. The newly added Hunt Group ID and Destination ID will be displayed for confirmation as follows.
  • Page 68 Hunt Group ID – An interpreter between a Hunt Group and a Destination. Destination ID – The destination is either a physical port or a remote IP address that VG-400R should make a call to. Each Destination ID maps to a physical destination. There are two types of physical destination.
  • Page 69 Now choose “Add” and “Remote_Destination_IP” for setting up the Destination IP address. Click “Select”, and the VG-400R prompts as follows:...
  • Page 70 The information associated with “Destination ID” and “IP Address” of the remote Gateway should be filled in. Click “Complete”. The newly added remote IP address will be displayed for confirmation as follows:...
  • Page 71 Now you may test the phone connected to the remote Gateway (211.20.86.4) with phone number “88635xxx” from your local phone.

  • Page 72: Configuration Examples

    7.CONFIGURATION EXAMPLES (USE CONSOLE OR TELNET COMMANDS) 7.1 The Default Dial-plans Before any configuration set up, your VG-400R should have the following basic default information. Network: : 192.168.0.1 Mask: : 255.255.255.0 Gateway : 0.0.0.0 Dial Plan: Hunt Dest. Dest. Group 0 (local port #1) 1 (local port #2) (X-1)
  • Page 73 You may also check the LED indicators on the VG-400R. When it rings, the related LED should Hint flash. After you pick up the handset, it should remain on and off when the phone is on hook. Now let’s test your ITG that is equipped with FXO interface. Assume you have one extension line associated with your PBX system, say, 316 as the designated extension number, we connect this line to VG-400R port 1 (FXO port), then...

  • Page 74: Itg To Itg In The Static Ip Address Environment

    ‘1’, and ‘100’ rings. VG-400R to VG-400R in the Static IP Address Environment The previous section shows you how to test your VG400R without modifying any settings. This section will show you how to connect two VGs together and make VoIP calls.
  • Page 75 VG B: Console>ping 192.168.0.1 <enter> ; ping VG A Ping (192.168.0.1) 56 data byte 192.168.0.1 is alive After these three steps, both VGs should find each other on the same network. Now let’s set up the remote H.323 gateway for this two VGs. VG A: Console>atpm req <enter>...
  • Page 76 Now, once VG A gets a dialed number “02” it will direct the call to VG B. The same is true for VG B. The dialed number ‘01’ will be mapped to VG A accordingly. VG A (01) VG B (02) Assume both VGs have a FXS port corresponding to port#3 each with a phone set connected to it.
  • Page 77 If you can not hear the ring signal, please do make sure of the following: 1) Both VGs can ping each other Hint 2) Phone sets are connected to the correct ports. In this example, it should be the FXS port. Also the phone number will be “20X”...
  • Page 78 The user at ext. 100 wants to make a call to VG B, 203. What we need to do is to pick up the handset with extension ‘100’ and dial ‘316’. After you hear the dial tone again, dial ’02-203’. Then, the phone attached to VG B should ring.
  • Page 79 The average bandwidth for each channel is from 12kbps to 16kbps by default. In a heavy traffic Warning network, the available bandwidth between two nodes may affect the voice quality. 7.2 VG to VG in the Dynamic IP Address Environment The previous section shows the steps regarding how to set up a typical VG-to-VG connection in the static IP address environment without modifying any settings.
  • Page 80 PPPoE DHCP Internet DDNS ADSL Modem Cable Modem Area code Area code Mary01.dyndns.org Mary02.dyndns.org 61.59.73.172 210.20.96.2 #201 #203 VG configuration (ADSL PPPoE connection) at Site A: PPPoE section: Please fill in username net set pppoe on <enter> net set pppoe user name password <enter> password obtained from your...
  • Page 81 DDNS client section: net set dyndns on <enter> set dyndns add dyndns mary01 my_name my_password <enter> config activate <enter> config store <enter> net reset <enter> Dial plan settings: Create atpm req <enter> atpm aadd 408 3 8 10 3 <enter> address entry for atpm hadd 10 2 10 <enter>...
  • Page 82 DNS server section: DNS server settings net set wan dns 168.95.1.1 <enter> will not take effect net store <enter> till the system reboot is done. config store <enter> DDNS client section net set dyndns on <enter> set dyndns add dyndns mary02 username password <enter>...

  • Page 83: Pbx Related Issues

    7.3 PBX related issues There are some issues related to PBX system. There are: 1) CP (Call Progress) Tone detection, and 2) Call Security. 7.3.1 CP Tone Detection You may encounter a problem when your call goes to PBX via a VoIP connection, such as the caller may already hang up the phone but the PBX port is still active.
  • Page 84 To prevent this from happening, you are advised to do the following: 1) Restrict the right to use associated with the line. For example, if the line goes to an extension number associated with a PBX, ask the PBX manager to restrict this line from dialing to certain numbers.
