CardAccess inhome IGA10A Installation Manual

For monitoring and controlling garage doors and enabling automation events

Advertisement

Quick Links

Garage Automation Package
For Monitoring and Controlling Garage Doors and Enabling Automation Events
The information contained in this document represents current information and views of Card Access, Inc. as of the date of
publication. Card Access cannot guarantee the accuracy of any information presented after the date of this document's publication.
COPYRIGHT ©2007 Card Access, Inc. All rights reserved. Any previously copyrighted contents contained herein remain the
property of the respective creators.
Card Access, InHome, Wires Not Included, and The Wire Stops Here are trademarks of Card Access, Inc.
Control4 is a registered trademark and 4Sight is a trademark of Control4 Inc.
ZigBee is a trademark of the ZigBee Alliance.
GE is a trademark of General Electric Company.
CEDIA is a trademark of the Custom Electronic Design & Installation Association.
Other marks may be the property of their respective owners.
_________________________________________________________________________________________________________________________
Card Access
InHome
Garage Automation Package Installation Guide / Wiring Diagram
Monitor and Control Garage Doors, and Enable Automation Events in the Control4-Automated Homes
InHome
Model Number: IGA10A
Installation Guide / Wiring Diagram
®
In Control4
Home Automation Projects
Page 1 of 8
Card Access, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the inhome IGA10A and is the answer not in the manual?

Questions and answers

Summary of Contents for CardAccess inhome IGA10A

  • Page 1 InHome ™ Garage Automation Package Model Number: IGA10A Installation Guide / Wiring Diagram For Monitoring and Controlling Garage Doors and Enabling Automation Events ® In Control4 Home Automation Projects The information contained in this document represents current information and views of Card Access, Inc. as of the date of publication.
  • Page 2 Card Access ™ InHome Garage Automation Package Installation Guide / Wiring Diagram ® Monitor and Control Garage Doors, and Enable Automation Events in the Control4 Automated Home Package Contents ™ ™ The Card Access InHome Garage Automation Package (model number IGA10A) is an “all-in-one” solution including ®...
  • Page 3 The Card Access InHome Wireless Contact Relay remotely opens and closes up to two garage doors. Both the InHome Wireless Contact Relay and Contact Switch are Control4 Certified and use ZigBee™ (IEEE 802.15.4) wireless technology to eliminate the need for running control wires back to the Control4 Home Theater/Media/HC Series Controllers. The two GE 2317A-L Rail-Mounted Magnetic Door Contacts are designed specifically for panel or sectional style overhead doors.
  • Page 4 Easy Installation The InHome Garage Automation Package is designed for quick installation with high reliability. The Card Access InHome Wireless Contact Switch and Relay installs quickly. The two innovative rail-mounted GE garage door contacts install vertically on the door channel (eliminating messy floor mounted contacts and cracked cement) and are both connected to the InHome Wireless Contact Switch.
  • Page 5 Figure 2 – Garage Magnetic Door Contact / External Thermistor to InHome Wireless Contact Switch Wiring Diagram 1. Add a room to the Composer Project and name it something obviously associated with the garage (like ‘Garage’). 2. Add one InHome Wireless Contact Switch to the Garage room in the Composer Project and create the proper bindings for two garage doors (please refer to the InHome Wireless Contact Switch Installation Guide included with this Package and your Control4/Composer documentation for additional installation details).
  • Page 6 6. (Optional) If you wish to use the External Thermistor (included in this package) to measure and create automation events based on the outdoor temperature, perform the following steps: a. Locate the External Thermistor on an outside garage wall within 10 feet of the InHome Wireless Contact Switch.
  • Page 7 3. For each of the garage door motor drives, connect the garage door motor drives using standard AWG 18-28 wiring to the InHome Wireless Contact Relay’s Tray Assembly using Pins 1 and 2 for garage door motor drive 1 and Pins 3 and 4 for garage door motor drive 2. (To determine which motor drive terminals should be used, simply duplicate the wiring scheme from the motor drives to the existing garage door buttons already installed in the garage area).
  • Page 8 To notify Card Access of any breach of the foregoing limited warranty and to obtain warranty service, contact Card Access Customer Support by e-mail to inhomesupport@cardaccess-inc.com or by calling 801-748-4900, extension 15, to obtain a Return Materials Authorization (“RMA”) number and instructions for returning your defective product to Card Access.
