SPECIFICATIONS
Main rotor diameter..............................550mm
Tail rotor diameter................................125mm
Length...............................................530mm
Weight
(without receiver & battery)......
CONTENTS
1....................................Assembled helicopter
1 pair..... ............Carbon Fibre main rotor blades
1 ......Twister 6 Ch. FM computer radio - installed
1................Twister 6 Ch. FM receiver - installed
1..............Twister HL400 tail lock gyro - installed
4..........................EnErg S7.5 servos - installed
1...Cyclone Ultra Cobalt brushed motor - installed
1........Twister 20 amp speed controller - installed
1........Twister 11.1V lithium polymer battery pack
1......Twister lithium polymer 12V DC/DC charger
1...................Twister 240V mains power supply
1.....................................Foam blade retainer
8...............................AA size pencell batteries
1................Twister 3D Storm instruction manual
'The Twister CP Gold has been designed as the next step up for pilots who have mastered
co-axial (twin rotor) helicopters, yet is fully aerobatic without having to upgrade'
http://www.jperkinsdistribution.co.uk
IMPORTANT!
!
Radio controlled model!
NOT A TOY!
Twister CP Gold
....390g (11.5oz)
This high performance model
must be assembled and operated
according to the instructions.
FEATURES
•
Factory assembled Completely Ready
To Fly
•
CCPM 120 deg flight control system for
precise performance
•
LBW (Low Battery Warning) system
•
3D flight performance without having to
upgrade
•
High performance Cyclone Ultra Cobalt
low current draw brushed motor
•
Digital proportional FM transmitter with
silky smooth sticks
•
High quality ball bearings
•
High performance, low current draw
belt drive tail system
•
Bell Hiller mixing for quick cyclic
response
•
HL 400 tail lock (heading hold) gyro
•
Super lightweight construction for the
ultimate in performance
http://www.modelengines.com.au
May cause serious injury to persons or
property if not used responsibly.
Unsuitable for children under 14 years.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for AirTek Twister CP Gold
-
Page 1: Specifications
8………………………….AA size pencell batteries ultimate in performance 1…………….Twister 3D Storm instruction manual ‘The Twister CP Gold has been designed as the next step up for pilots who have mastered co-axial (twin rotor) helicopters, yet is fully aerobatic without having to upgrade’ http://www.jperkinsdistribution.co.uk http://www.modelengines.com.au... -
Page 2: Table Of Contents
CRASHES & SPARE PARTS The Twister CP Gold has been designed to be strong and easy to repair, however, should the heli- copter crash, there is a chance that parts will be damaged. In the event of a crash, it is important that the helicopter be thoroughly checked before undertaking further flights to ensure that no danger could be posed to yourself, bystanders or property. -
Page 3: Introduction
INTRODUCTION About the Twister CP Gold New to R/C Helicopter Flying? The Twister CP Gold is designed as the next While the Twister CP Gold is designed as the step up for pilots who have mastered co-axial next step up for pilots from co-axial helicopters, helicopters. -
Page 4: Preparing For Flight
Twister CP Gold PREPARING FOR FLIGHT 3. CONNECT BATTERY TO THE CHARGER UNPACK YOUR TWISTER CP GOLD. • • Plug the white 4 pin connector on the flight Carefully remove the model and other items from the packaging. battery into the socket on the right side of •... -
Page 5: Lithium Polymer Battery Safety
7. SWITCH ON TRANSMITTER. temperature object or device. • Do not charge batteries whilst driving. • The Twister CP Gold is available with • Do not store batteries in a motor vehicle. either a Mode 1 or Mode 2 transmitter. •... -
Page 6: Range Check
Twister CP Gold CONTROL CHECK • Make sure that the ‘3D’ (idle up) switch and Aileron (roll cyclic) control the ‘throttle hold’ switch are pushed fully forward (towards the back of the • View the helicopter from behind and move transmitter) the aileron stick (roll cyclic) left and right. -
Page 7: Advanced Flying Features
Move the stick until the main rotor blades manoeuvres. begin to rotate slowly and then throttle back. WARNING! • Your Twister CP Gold is now ready for • Do not use the 3D/Idle Up switch unless flight. you are an experienced RC helicopter pilot. ADVANCED FLYING FEATURES... - Page 8 Your ‘hops’ will be- to take your Twister CP Gold ‘for a walk’. come larger and smoother and will know These first few flights should be made with...
-
Page 9: Troubleshooting
Twister CP Gold TROUBLESHOOTING VIBRATION MAIN ROTOR DOES NOT TURN Solution 1 - Out of balance main blades. Solution 1 - Check throttle stick and trim If vibration of tail boom or undercarriage is lever are both fully down when turning on the noticeable, the most likely problem will be out of helicopter. -
Page 10: Spare Parts & Option Parts
6600298 Li-Po Battery 6601367 Belt Guide Set 6600402 Main Rotor Blades 6601382 Belt Pulley Set 6601366 Main Frame 6601387 Twister CP Gold Canopy 6601369 Main Gear Set & Shaft Set 6601386 Canopy Mounting Rod Set 6600341 ESC 6601388 Main Shaft http://www.jperkinsdistribution.co.uk... - Page 11 Twister CP Gold 6601365 Ultra Cobalt Motor 6601363 Swashplate 6601368 Receiver & Battery Mount Set 6601362 Tail Blades 6601378 Tail Servo & Horizontal Fin Mount Set 6600381 Main Blade Grip Set 4460102 HL 400 Gyro 6601383 Tail Blades Control Arm...
- Page 12 Twister CP Gold 6601375 Tail Hardware Set 6601150 Centre Hub & Spindle Shaft 6601379 Tail Shaft Mount 6601330 Main Shaft Retaining Collar 6601374 Tail Servo Pushrod Set 6601377 Vertical Fin 6600320 Twister 3 Cell Li-Po Balance Charger 6601190 Flybar 6600330 Twister 240VAC Power Supply (3 pin) 6601230 Servo Pushrod &...
- Page 13 Twister CP Gold 6601320 Swash Plate to Flybar Links 6601200 Flybar Paddles 7710500 Twister Computerized Transmitter 6600750 Bearings 3 x 6 x 2.5 (2) 6600850 Allen Key, Cable Ties & Servo Tape Set 6601360 Washer 6601395 Bearing 3 x 6 x 2.5 6601396 Bearing 2 x 5 x 2.5...
-
Page 14: Twister Cp Gold Exploded View
Twister CP Gold Twister CP Gold Exploded View... - Page 15 Twister CP Gold...
