Summary of Contents for Kozumi air force one 2 lite

Page 1 User Manual V1.0...
Page 2 1. Check the parts in your box CPE SET PoE Injector Hose Clamps 12V DC Power Adapter CD user manual 2. Hot to fix the CPE on the Pole (1”- 1.5”) (For better water resistance please wrap the RJ45 connector)
Page 3 Software Installation There are no software drivers, patches or utilities installation needed, but only the configuration setting. Notice: It will take about 55 seconds to complete the boot up sequence after powered on the WLAN Access Point; Power LED will be active, and after that the WLAN Activity LED will be flashing to show the WLAN interface is enabled and working now.
Page 4 Open a WEB browser, i.e. Microsoft Internet Explore, then enter 192.168.1.254 on the URL to connect the WLAN Access Point. Prepare your PC to configure the WLAN Access Point For OS of Microsoft Windows 95/ 98/ Me: 1. Click the Start button and select Settings, then click Control Panel. The Control Panel window will appear.
Page 5 3. Check the installed list of Network Protocol window. If TCP/IP is not installed, click the Add button to install it; otherwise go to step 6. 4. Select Protocol in the Network Component Type dialog box and click Add button. 5.
Page 6 System [Uptime] It shows the duration since WLAN Access Point is powered on. [Firmware version] It shows the firmware version of WLAN Access Point. Wireless configuration [Mode] It shows wireless operation mode [Band] It shows the current wireless operating frequency. [SSID] It shows the SSID of this WLAN Access Point.
Page 7 It shows the BSSID address of the WLAN Access Point. BSSID is a six-byte address. [Associated Clients] It shows total numbers of WLAN clients connected, TCP/IP Configuration [Attain IP Protocol] It shows how the WLAN Access Point gets the IP address. The IP address can be set manually to a fixed one or set dynamically by DHCP server.
Page 8 2.Wireless Basic Settings This page is used to configure basic wireless parameters like Band, Mode, Network Type SSID, Channel Number, Enable Mac Clone(Single Ethernet Client) 3.Wireless Security Setup This page is used to configure wireless security Wireless - Basic Settings This page is used to configure the parameters for wireless LAN clients that may connect to your Access Point.
Page 9 Disable Wireless LAN Interface Click on to disable the wireless LAN data transmission. Band Click to select 2.4GHz(B) / 2.4GHz(G) / 2.4GHz(B+G) Mode Click to select the WLAN AP / Client / WDS / AP+WDS wireless mode. Site Survey The Site Survey button provides tool to scan the wireless network. If any Access Point or IBSS is found, you could choose to connect it manually when client mode is enabled.
Page 10 Click the Reset button to abort change and recover the previous configuration setting. Wireless - Advanced Settings These settings are only for more technically advanced users who have a sufficient knowledge about wireless LAN. These settings should not be changed unless you know what effect the changes will have on your WLAN Access Point.
Page 11 Click to select the Long Preamble or Short Preamble support on the wireless data packet transmission. Broadcast SSID Click to enable or disable the SSID broadcast function. IAPP Click to enable or disable the IAPP function. 802.11g Protection Protect 802.11b user. RF Output Power To adjust transmission power level.
Page 12 Encryption Select the encryption supported over wireless access. The encryption method can be None, WEP, WPA(TKIP), WPA2 or WPA2 Mixed Use 802.1x Authentication While Encryption is selected to be WEP. Click the check box to enable IEEE 802.1x authentication function. WPA Authentication Mode While Encryption is selected to be WPA.
Page 13 Key Length Select the WEP shared secret key length from pull-down menu. The length can be chose between 64-bit and 128-bit (known as “WEP2”) keys. The WEP key is composed of initialization vector (24 bits) and secret key (40-bit or 104-bit). Key Format Select the WEP shared secret key format from pull-down menu.
Page 14 10 hexadecimal codes 26 hexadecimal codes Wireless - Access Control If you enable wireless access control, only those clients whose wireless MAC addresses are in the access control list will be able to connect to your Access Point. When this option is enabled, no wireless clients will be able to connect if the list contains no entries.
Page 15 Click to delete all the registered clients from the access allowed list. Reset Click the Reset button to abort change and recover the previous configuration setting. WDS Settings Wireless Distribution System uses wireless media to communicate with other APs, like the Ethernet does.
Page 16 Click the Reset button to abort change and recover the previous configuration setting. Set Security Click button to configure wireless security like WEP(64bits), WEP(128bits), WPA(TKIP), WPA2(AES) or None Show Statistics It shows the TX, RX packets, rate statistics Delete Selected Click to delete the selected clients that will be removed from the wireless distribution system.
Page 17 MAC Address It shows the MAC Address within WDS. Tx Packets It shows the statistic count of sentpackets on the wireless LAN interface. Tx Errors It shows the statistic count of error sent packets on the Wireless LAN interface. Rx Packets It shows the statistic count of received packets on the wireless LAN interface.
Page 18 SSID It shows the SSID of AP. BSSID It shows BSSID of AP. Channel It show the current channel of AP occupied. Type It show which type AP acts. Encrypt It shows the encryption status. Signal It shows the power level of current AP. Select Click to select AP or client you’d like to connect.
Page 19 IP Address Fill in the IP address of LAN interfaces of this WLAN Access Point. Subnet Mask Fill in the subnet mask of LAN interfaces of this WLAN Access Point. Default Gateway Fill in the default gateway for LAN interfaces out going data packets. DHCP Click to select Disabled, Client or Server in different operation mode of wireless Access Point.
Page 20 This page is used to configure the remote log server and shown the current log. Enable Log System all Wireless only Click the checkbox to enable log. Show all log of wireless Access Point. Only show wireless log. Enable Remote Log Click the checkbox to enable remote log service.
Page 21 Statistics This page shows the packet counters for transmission and reception regarding to wireless and Ethernet LAN networks. Wireless LAN Sent Packets It shows the statistic count of sent packets on the wireless LAN interface. Wireless LAN Received Packets It shows the statistic count of received packets on the wireless LAN interface. Ethernet LAN Sent Packets It shows the statistic count of sent packets on the Ethernet LAN interface.
Page 22 Click the Upload button to update the selected web firmware image to the WLAN Access Point. Reset Click the Reset button to abort change and recover the previous configuration setting. Save / Reload Settings This page allows you save current settings to a file or reload the settings from the file that was saved previously.
Page 23 Password Setup This page is used to set the account to access the web server of Access Point. Empty user name and password will disable the protection. User Name Fill in the user name for web management login control. New Password Fill in the password for web management login control.
Page 24 Type admin for the username and type the password click ok to login. Logout This page is used to logout web management page. This item will be activated next time you login after you define user account and password. Apply Change Click the Apply Change button, Then click OK button to logout.
Page 25 1.The computer used to configure the Access Point can not access the configuration menu. Check that the LAN LED on the Access Point is ON. If the LED is not ON, check that the cable for the Ethernet connection is securely inserted. Check that the Ethernet adapter is working properly.
Page 26 2. The wireless client cannot access the Internet in the Infrastructure mode. Make sure the wireless client is associated and joined with the correct access point (Access Point). To check this connection: Right-click on the Local Area Connection icon in the taskbar> select View Available Wireless Networks.
Page 27 the taskbar > select the Support tab and the IP address will be displayed. (Please refer to Checking the IP Address in the Networking Basics section of this manual.) If it is necessary to assign a static IP address to the wireless adapter, please refer to the appropriate section in Networking Basics.
Page 28 Click Device Manager Double-click on Network Adapters Right-click on Realtek RTL8187 Wireless Adapter (or whatever network adapter you are using) Select Properties to check that the drivers are installed properly...
Page 29 Look under Device Status to check that the device is working properly. Click OK...
Page 30 Frequently Asked Questions (FAQ) What and how to find my PC’s IP and MAC address? IP address is the identifier for a computer or device on a TCP/IP network. Networks using the TCP/IP protocol route messages based on the IP address of the destination. The format of an IP address is a 32-bit numeric address written as four numbers separated by periods.
Page 31 What are ISM bands? ISM stands for Industrial, Scientific and Medical; radio frequency bands that the Federal Communications Commission (FCC) authorized for wireless LANs. The ISM bands are located at 915 +/- 13 MHz, 2450 +/- 50 MHz and 5800 +/- 75 MHz. How does wireless networking work? The 802.11 standard define two modes: infrastructure mode and ad hoc mode.
Page 32 What is BSSID? A six-byte address that distinguishes a particular a particular access point from others. Also know as just SSID. Serves as a network ID or name. What is ESSID? The Extended Service Set ID (ESSID) is the name of the network you want to access. It is used to identify different wireless networks.
Page 33 contrast, with a large fragment threshold, the overlap is small and the spatial reuse ratio is low. However high fragment threshold leads to low fragment overhead. Hence there is a trade-off between spatial re-use and fragment overhead. Fragment threshold is the maximum packet size used for fragmentation. Packets larger than the size programmed in this field will be fragmented.
Page 34 Some wireless devices don't work properly if SSID isn't broadcast (for example the D-link DWL-120 USB 802.11b adapter). Generally if your client hardware supports operation with SSID disabled, it's not a bad idea to run that way to enhance network security. However it's no replacement for WEP, MAC filtering or other protections.
Page 35 inter-Access Point communication and UDP for RADIUS request/response exchanges. It also uses Layer 2 frames to update the forwarding tables of Layer 2 devices. What is Wireless Distribution System (WDS)? The Wireless Distribution System feature allows WLAN AP to talk directly to other APs via wireless channel, like the wireless bridge or repeater service.
