Instruction manual

Refrigerator

Table of Contents

Need help?

Do you have a question about the NRC6191FX and is the answer not in the manual?

Questions and answers

Summary of Contents for ARISTOS NRC6191FX

Page 1 Instruction manual Refrigerator...
Page 2: Table Of Contents
We thank you for the conﬁ dence you have shown by purchasing our appliance. We wish you ﬁ nd a lot of pleasure in its use. The appliance is intended solely for household use. The refrigerator is intended for storing fresh food at temperatures above 0°C. Important notes and warnings ........
Page 3: Important Notes And Warnings
Important notes and warnings • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or metal capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
Page 4 • If LED lighting does not work, call a service technician. Do not attempt a repair of the LED lighting yourself, as there is danger of contact with high voltage! • To protect the environment, take the obsolete appliance to an authorized home appliance collection center.
Page 5: Advice For Saving Power With Refrigeration Appliances
Advice for saving power with refrigeration appliances • Install the appliance as speciﬁ ed in the instruction manual. • Do not open the door more often than necessary. • Occasionally make sure air circulation underneath the appliance is unobstructed. • Condenser unit on the rear wall should be kept clean (see chapter Cleaning the appliance). •...
Page 6: Appliance Description
Appliance description Control unit Led lighting of refrigerator interior Fan with air ionizer (+ on/off switch)* Bottle rack* Pull-out glass shelf (height adjustable) FreshZone drawer* CrispZone fruit and vegetables drawer with humidity control Fruit and vegetables drawer SimpleSlide height-adjustable door bin 10 Multibox storage bin* 11 Bottle bin 12 Foot...
Page 7: Installation And Connection
Installation and connection Selecting the room • Install the appliance in a dry and well ventilated room. The appliance will operate correctly if the environment temperature is in the interval speciﬁ ed in the table. The appliance class is indicated on the rating plate / label with the basic information on the appliance.
Page 8 • The appliance may stand alone or it may be placed ext to a cupboard or a wall. Consider the clearance required to fully open the door in order to allow pulling out the drawers and shelves (see installation diagram). 600 mm 644 mm Note: When placing the appliances side by side, the anti-dew...
Page 9: Changing The Direction Of Door Opening
Changing the direction of door opening Version I – controls in the appliance interior Tools required: socket wrench No. 8, Phillips screwdriver, torx 25, ﬂ at screwdriver The procedure to change the direction of door opening should be carried out by at least two persons.
Page 11 Version II – Controls on the door Tools required: socket wrench No. 8, Phillips screwdriver, torx 25, ﬂ at screwdriver The procedure to change the direction of door opening should be carried out by at least two persons. 1. Remove the upper hinge cover (A), the connector cover (B1) and the covering cap (M). 2.
Page 13: Operating The Appliance With Mechanic Controls
Operating the appliance with mechanic controls CONTROL UNIT 1 A Temperature setting and on/off knob B Lighting on/off key Switching the appliance To switch on: rotate the A dial clockwise. on/off Switching off: Rotate the A knob back to the position in which the arrow is aligned with the symbol (caution: appliance will remain powered, i.e.
Page 14: Operating The Appliance With Electronic Controls
Operating the appliance with electronic controls CONTROL UNIT 2 A On/off switch B Temperature adjustment and cooling boost key C Refrigerator temperature display D Cooling boost function display Switching the appliance The appliance can be switched on and off with the on/off key A. on/off Adjusting the •...
Page 15 • Recommended setting is 5°C. Refrigerator boost • Use this setting after switching on the appliance for the ﬁ rst time, before cleaning, or before inserting a large amount of food. To activate the cooling boost function, press the B key until the symbol D lights up.
Page 16 CONTROL UNIT 3 Controls on the door A On/off key B Acoustic alarm off key C Cooling boost on/off key D Refrigerator temperature keys C Refrigerator temperature display G ECO function on/off key...
Page 17 Switching the appliance Switching the appliance on: Switch on the appliance by brieﬂ y on/off pressing the A key. Switching off the appliance: To switch off the appliance, press the A key and hold it for 3 seconds. Adjusting the •...
Page 18 High temperature alarm If the temperature inside the appliance is too high, acoustic alarm will be activated (intermittent tone) and the B key will ﬂ ash. • Acknowledge and turn off the acoustic alarm by pressing the B key. • The acoustic alarm will be activated every 24 hours if the temperature in the appliance is not low enough and there is danger of food spoilage.
Page 19: Appliance Interior Equipment
Appliance interior equipment (* Equipment depends on the model) Shelf • For easier access to food and clarity, the shelves can be partly pulled out. • The shelves may be adjusted tu suit your preferences using the guides in the refrigerator interior. To remove a shelf from the refrigerator, pull it out tot he point when it is stopped by the guide.
Page 20 Smaller amounts of food - push the control slider to the right; Larger amounts of food - push the control slider to the left; • Removing the fruit and vegetable bin: - Pull out the bin as far as it will go. Then, lift the front part and pull it out completely.
Page 21 Fan* • The fan placed under the refrigerator compartment ceiling or hidden in the freezer unit will make sure the temperature is distributed more evenly and reduce condensation (dew) on the storage surfaces. Ionizer (IonAir)* • Air ionizer placed in the refrigerator compartment removes most bacteria, viruses, gases, and unpleasant odours to make sure the air in the refrigerator is always fresh.
Page 22 Control unit 2 and 3 Switching the ionizer on/off ON = OFF = When the ionizer is switched on, a red dot will be visible on the switch. Adaptive Intelligent (only with control units 2 and 3) Technology Innovative sensor technology allows adjusting appliance operation to the user's habits or behaviour.
Page 23: Recommended Distribution Of Food In The Appliance
Recommended distribution of food in the appliance Recommended Sections of the refrigerator: distribution of food in - upper part: canned food, bread, wine, pastry etc. the appliance - middle part: dairy products, ready-made meals, desserts, soft drinks, beer, cooked food, etc. - Fresh bin: - meat, meat produce, delicatessen;...
Page 24: Storing Food In The Refrigerator
Storing food in the refrigerator Important warnings Correct use of the appliance, appropriate packaging, regarding food storage maintaining the right temperature, and observing the food hygiene standards has a decisive impact on the quality of food storage. Observe the expiry dates for the food, speciﬁ ed on the packaging.
Page 25: Storing Food In The Freshzone Drawer
Storing food in the FreshZone drawer In the FreshZone compartment, food stays fresh longer than in a conventional refrigerator, retaining more ﬂ avour and nutrients. Decay and loss of mass are slowed down; therefore, fruit and vegetables remain fresh and natural longer. For optimum performance, the drawer should be fully closed.
Page 26: Defrosting The Appliance
Defrosting the appliance Refrigerator does not need defrosting because the ice on the back Automatic refrigerator interior wall is thawed automatically. defrosting Any accumulated ice will melt when the compressor unit is inactive. Drops will ﬂ ow through an opening in the refrigerator rear wall into a tray ﬁ...
Page 27: Troubleshooting
• Also clean the tray above the refrigerator compressor. If you remove it, replace it after cleaning. Make sure it is placed horizontally. • After cleaning, switch the appliance back on and insert the food. Troubleshooting Problem: Cause or remedy: Appliance is connected to the •...
Page 28: Information About Appliance Noise
Problem: Cause or remedy: Door is difﬁ cult to open: • If you are trying to open the appliance door after just having closed it, this could be difﬁ cult to do. As you open the door, some cool air escapes from the appliance and it is replaced by warm air from the environment.
