THANK YOU for your purchase of the OMNI-624 Security System. The purpose of this manual is to give you a brief overview of the OMNI-624 control panels, and provides instructions for installing a basic system. FBII is always available to serve YOU.
Wiring Information for Keypads & Other Devices ................2-6 SECTION 3 – PC BOARD AND KEYPAD MOUNTING ..............3-1 Mounting the OMNI-624/OMNI-624EU PC Board ................3-1 Mounting the RF Expander Module ....................3-2 Mounting the Zone Expander Module ....................3-2 Keypad Mounting Instructions ......................
Page 4
Programming Submode 4: DESCRIPTOR PROGRAMMING ............6-51 SECTION 7 – SUMMARY OF KEYPAD FUNCTIONS............... 7-1 User Functions............................7-1 Installer Modes ............................. 7-2 SECTION 8 – CENTRAL STATION REPORTING FORMATS ............8-1 General Information ..........................8-1 Standard (3x1 or 4x1) ........................... 8-1 Extended (3x1 Ext.
Conventions Used in This Manual • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • Before you begin using this manual, it is important that you understand the meaning of the following symbols (icons) and text note.
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • System Features The OMNI-624 and OMNI-624EU are state-of-the-art microprocessor-based control/communicators that provide 2 partitions and support both hardwire and wireless zones. Programming can be performed through any of the compatible keypads, or the system can be uploaded and downloaded remotely using the Compass Downloader Software.
Underwriters Laboratories, Progress Department, 333 Pfingsten Road, Northbrook, IL 60062. UL Listings The OMNI-624 is the Residential (Household) version of the control panel, and has been Listed by Underwriters Laboratories for the following applications: • UL 1023 Household Burglary •...
3. 650 mA MAX, ALARM OUTPUT FOR UL XL4612TC DEFAULT JUMPERS INSTALLATIONS. 12V, 4-6AH +VBELL BATTERY 4. FOR CE COMPLIANCE, WIRE THE OMNI- MODEL 467 TRIGGER 1 EXP 8 HARDWIRE ZONE EXPANDER AS (4AH) DESCRIBED IN THE OMNI-EXP 8 INSTAL- TRIGGER 4 (OR DATA)
“PLEASE STAND BY” and “POWER UP DELAY” are displayed on the OMNI-LCD keypad. “PL” is displayed on the OMNI-KP keypad, and the Armed LEDs on both keypads are lit. All LEDs on the XK108 and XK108L keypad are lit.
Page 11
Section 2. System Wiring and Hookup 3 (+) MECHANICAL BELL OUTPUT BELL 4 (–) OMNI624-001-V0 SIREN SUPERVISION (Self-Contained Siren/Speaker) - (Not for use in UL installations.) To meet the NFPA 72 requirement program Question 12, Location 3, in Programming Submode 1 for bell supervision.
Page 12
RF RECEIVER — ZONE INFORMATION (WIRELESS ZONES): Up to 24 wireless zones can be used if the ZR-401, ZR-402EU, or OMNI-RF Wireless Expansion Module is installed. The maximum number of zones (24) includes the 6 basic wired zones, wired zones using the expansion module, and the wireless zones.
FOR EACH OF UNITS FOR ALL UNITS PIR's, smoke Control Panel 65mA 65mA detectors, etc., refer to the specifications for OMNI-LCD (Backlight Off/On) 35mA/81mA that particular device's OMNI-KP (Backlight Off/On) 28mA/45mA current draw. If the XK-108L 42mA total current draw for...
OMNI-624/OMNI-624EU Installation and Setup Guide Wiring Information for Keypads & Other Devices KEYPADS & OTHER DEVICES If single or multiple devices are connected on a single 4-wire or 2-wire run ("daisy chained") to the control terminals, do the following: Determine the current drawn by the unit(s) connected to the single-wire run, then refer to the Wiring Run Table below to determine the maximum wire length that can be safely used for each wire size.
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • Mounting the OMNI-624/OMNI-624EU PC Board NOTE: The door of the metal cabinet may be removed to make it easier to install the control panel.
OMNI-624/OMNI-624EU Installation and Setup Guide Mounting the RF Expander Module 1. Mount the receiver board on top of the ZR-401/ZR-402EU/OMNI-RF RF RECEIVER control PC board as shown in the diagram at right. 2. Insert grounding lugs (supplied) into the left-hand terminals of the antenna blocks and secure them to the cabinet with the screws provided.
S E C T I O N System Configuration • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • Partitioning This system provides the ability to arm and disarm 2 different areas, known as partitions, each as if it had its own control.
Zone Expander Module. Wireless Transmitters Using the ZR-401, ZR-402EU, or OMNI-RF wireless Expander Module, up to 24 wireless zones plus up to 8 wireless keyfobs can be used. Each zone or keyfob must be programmed and its serial number entered in programming mode.
Section 4. System Configuration The following chart lists the most popular compatible wireless devices by market. Please consult your distributor for the availability of additional products. North America Western Europe Outside Western Europe Device (345MHz) (433.92MHz) Europe (433.92MHz) (868MHz) 2-Zone Transmitter 5816 5816EU ZR510...
OMNI-624/OMNI-624EU Installation and Setup Guide Connect the Relay Modules as shown: DIP SWITCHES XL4705 RELAY REFER TO “DIP SWITCH ADDRESSING” MODULE TABLE FOR SETTINGS 10 11 12 13 14 15 16 17 18 19 20 CONNECT TO EARTH GND DATA CLK + 12V NO NC...
Page 21
Section 4. System Configuration Paging Alarms, Troubles, Open, and Close: Alarms will take priority over troubles, troubles take priority over Open, and Open takes priority over Close. For pager opening or closing to occur, the following conditions must exist: • The system must not have an alarm or trouble condition. •...
Page 22
OMNI-624/OMNI-624EU Installation and Setup Guide Paging/Beeps Sequence: The paging will not begin until the dialer is off and dialer delay is not active. The system checks if any event needs to be dialed. The page/beeps are dialed 1, 2, or 3 times. If pager attempts are 0, paging is disabled.
5 seconds. If total system power is lost, upon power restoral the system will return to its previously armed state. Keypads The control panel supports the following keypads: OMNI-LCD Alpha Keypad STAY ARMED BYPASS...
Page 24
OMNI-624/OMNI-624EU Installation and Setup Guide AC / LB READY XK-108L/XK-108 LED Keypad STAY INSTANT (Displays the state of up to 8 zones via LEDs) BYPASS CODE STAY INST LO BATT SPRV. ZONE STATUS LEDS (XK-108L/XK-108) These LEDs display the current zone status including alarms, bypasses, and faults. Each condition will cause these LEDs to operate differently as follows: ALARMS Fast Blink (approx.
Page 25
KEYPAD AUXILIARY KEYS Pressing the auxiliary keys (XK-108L: two keys labeled P, A, or F at the same time; OMNI- LCD/OMNI-KP: 1/3, 7/9, /#) initiates a CS transmission, if programmed, of programmed functions (e.g., PANIC, AUXILIARY, or FIRE), and causes annunciation of the keypad sounder and turns on the bell output.
This address will identify the keypad number to the control panel. A maximum of 12 keypads (OMNI- KP, OMNI-LCD or XK-108L) can be identified, but the total of 12 cannot be comprised of more than 8 LCD keypads or a combination of 8 LED/fixed-word keypads.
Set the XK-108L keypad address by using its DIP switches. Refer to the instructions provided with the keypad for additional information on setting the keypad address. Arming the System The system can be armed only if all burglary zones are in ready state (not faulted): OMNI-LCD OMNI-KP XK-108L/XK-108 Indicator LED Lit...
Page 28
OMNI-624/OMNI-624EU Installation and Setup Guide STAY ARMING TO ARM: Press the [STAY] key followed by a four-digit user code. This will arm the system with all programmed interior zones bypassed. OMNI-LCD OMNI-KP XK-108L/XK-108 Indicator LED Lit Armed Armed Armed, Stay...
Page 29
Section 5. System Operation RESET Reset is accomplished through the entry of any valid user code. This can be used to reset the smoke detectors attached to the system, silence any bells or sounders, or clear the keypad display. BYPASS BY ZONE Bypassing is enabled to temporarily exclude zones or points that are faulty or otherwise not ready for operation, from activating the security system.
OMNI-624/OMNI-624EU Installation and Setup Guide MANUAL UNBYPASS UNBYPASS removes an existing bypass from a currently bypassed zone. The procedure is the same as four bypass. KEYPAD TAMPER: Upon entry of 21 keystrokes in succession without entry of a valid command, the system will initiate a keypad tamper. If programmed (Submode 1, Question 13, Location 2), the tamper condition initiates a keypad lockout, in which keypad commands will not be accepted for approximately 20 minutes.
Page 31
Section 5. System Operation Level Functions Allowed Primary Master can view log and set time, assign other user codes, all system functions Secondary Master, same as primary Master except cannot change the primary Master’s code User, can arm and disarm only Limited user, same as level 3, except can disarm the system only if it was armed by another user with level 4 authority (cannot disarm if armed with user of higher authority level).
OMNI-624/OMNI-624EU Installation and Setup Guide where: MASTER USER User with authority level 1 or 2. USER NO. The user that will be assigned access to other partitions. 1, 2, or 4 Select 1 or 2 to assign access to a partition to that user.
Section 5. System Operation Quick Command Modes The end user can perform the following commands (if programmed): COMMAND KEYSTROKES DESCRIPTION Changes mapping of current keypad to the partition Change partition # 0 [code] [0, 1, specified. This mode displays the current armed state of both 2, or 9] partitions.
Page 34
Quick commands are valid for 10 seconds of no activity, unless otherwise stated. CHANGE PARTITION: [#] [0] [#] [0] [CODE] [0], [1], [2], or [9] OMNI-KP keypads display “EC” (enter code) after pressing #0, then display “CP” (change partition) after entering the user code. QUICK ARMING: # 1 If programmed, Quick Arming will be permitted.
Page 35
Section 5. System Operation QUICK FORCED ARMING: # 2 If programmed, then Quick Forced Arming will be permitted. Quick Forced Arming allows arming the system without entry of a user code, and bypasses any bypassable zones that are not ready. It reports as user #01.
Page 36
OMNI-624/OMNI-624EU Installation and Setup Guide DISPLAY AUTO-ARM TIME: # 52 (LCD Keypads Only) If auto-arming is programmed, pressing [#] [5] [2] displays the current auto-arm time for the current area on the LCD keypads. NOTE: Auto-arming is enabled in programming Submode 1, Question 28, AUTO ARM TIME: L1 and the auto-arm time is set by using [#] [5] [4].
Page 37
Section 5. System Operation beeps every 15 seconds for 2 minutes prior to arming) warns the occupants that the system will auto- arm in two minutes. If a user code is entered within this warning period and the system is disarmed, the auto-arm time for that day will be canceled.
Page 38
OMNI-624/OMNI-624EU Installation and Setup Guide CHANGE/VIEW PAGER NUMBER: # 58 If enabled (Submode 1, Question 23, L4), the [#] [5] [8] command can be used to change the pager phone number. This mode times out in 10 seconds without saving the phone number if no key is pressed, or exists without saving if the [ ] key is pressed.
1. If there are no keypads connected to the system, keypad address 8 is automatically enabled. This allows an OMNI-LCD to be temporarily connected for programming the system. 2. If XK-108 keypads are the only keypads used in the system, but you want to program the system using an LCD keypad, you must power down the system, connect the LCD keypad, and then power up the system.
LCD keypad. If an LCD keypad is not available, programming may also be performed using an XK-108 or XK-108L LED or an OMNI-KP fixed-word keypad. When you are using an LED or fixed-word keypad, the displays are different and some programming procedures are different. Refer to the following “If an LED Keypad Is Used for Programming”...
Page 41
Section 6. System Programming Question Numbers = Zone LEDs: Zone LEDs 1 through 6 display the current question number (not the specific location within each question). In the above figure, the question number is the total you get when you add the values of all LEDs that are lit. Examples: Zone 1 lit, Zones 2-6 off = question 01 Zone 1 lit, Zone 2 lit, Zones 3-6 off = question 03 Zone 2 lit, Zone 3 lit, Zone 4 lit, Zones 1, 5, and 6 off = question 14...
Page 42
OMNI-624/OMNI-624EU Installation and Setup Guide FIXED SUBMODE DIGITS DISPLAY INDICATORS STAY TAMPER NO AC PHONE TEST INSTANT QUESTION NOT READY BYPASS NUMBER ALARM CHIME INDICATOR FIRE TRBL PAGE SUPRVSN CANCELED OMNI624-008-V0 Submode Indicators = STAY, INSTANT, and BYPASS indicators: The STAY, INSTANT, and BYPASS indicators provide the current submode number.
Section 6. System Programming KEY ENTRY FUNCTION Advance to the next location within the current question; or advance to the next question if already displaying the last location in the current question. Go to a specific question selected by 00 to 99. [ ] + 00–99 [CODE] + 1–6 Enter A through F as data where:...
Page 44
OMNI-624/OMNI-624EU Installation and Setup Guide INSTALLER MODE 1 (INSTALLER KEYPAD PROGRAMMING) Enters the installer into keypad programming mode, which has 4 submodes (see below). To exit, simply press the [STAY] key and return to the prior panel status. To change between these submodes, press [ ] + [BYPASS] + Submode No.
Page 45
Section 6. System Programming To exit, simply press the [ ] key and return to the prior panel status. INSTALLER MODE 4 (SYSTEM LOG VIEW) The system retains history of the past 128 events (alarms, troubles, openings, closings, bypasses, etc.). Upon entry to the system log view, LCD-based keypads show the events for the entire system, based on the options programmed in Question 17, Locations 1–3.
Page 46
OMNI-624/OMNI-624EU Installation and Setup Guide INSTALLER MODE 6 (CLEAR TAMPER FAULTS) This mode clears all tamper displays in all partitions for double balanced and RF zones that have restored, and is an Installer reset function. INSTALLER MODE 8 (INSTALLER UNATTENDED DOWNLOAD) For UL installations, Installer Unattended Download may NOT be used.
Section 6. System Programming INSTALLER MODE 9 (ON-LINE DOWNLOAD) In this mode, the installer can initiate a remote communications session with the CS Downloading computer at the control panel location. Typically, the CS initiates a remote communications session. On-line Downloading allows the installer to call the office (from the same telephone line as the panel), discuss the action required, and allow the CS operator to complete the request while on-line;...
Page 48
OMNI-624/OMNI-624EU Installation and Setup Guide Installer Mode 1 Submodes: 1 = System Options 2 = Zone and All Central Station Report Code Programming 3 = Wireless Zone/Keyfob Programming 4 = Zone Descriptor Programming What You See on the LCD Keypad...
Section 6. System Programming Exit System Program Mode After all programming has been completed, press the [STAY] button to exit the system program mode. Question Acknowledgment The keypad will beep between keystrokes. In addition, a beep will be generated confirming advancement between question numbers.
Page 50
OMNI-624/OMNI-624EU Installation and Setup Guide 4-digit code of 1234 – enter 6-digit code of 123456 – enter Note that if the system is set for 4-digit codes and you enter a 6-digit code, the first two digits of the code (L5 and L6) are stored into memory but will not become active until the system is set for 6-digit codes (Submode 1, Question 12, L3) and the programming mode ends.
Page 51
Section 6. System Programming Q 01 PRIMARY TELEPHONE NUMBER Q 02 SECONDARY TELEPHONE NUMBER Q 03 CALLBACK TELEPHONE NUMBER Enter the telephone number (including area code or dialing prefix, if necessary) for this control panel to reach the callback number location. The callback number is the optional location of the Downloading Software where the control panel will call during a remote communications (upload/download etc.) session.
Page 52
OMNI-624/OMNI-624EU Installation and Setup Guide Q 06 PRIMARY ACCOUNT NUMBER PARTITION 1 Q 07 SECONDARY ACCOUNT NUMBER PARTITION 1 Q 08 PRIMARY ACCOUNT NUMBER PARTITION 2 Q 09 SECONDARY ACCOUNT NUMBER PARTITION 2 QUESTION 10 CS DIALER FORMAT AND RECEIVER TYPE This question defines the dialer format and receiver type for primary (CS1) and secondary (CS2) reporting.
Page 53
Section 6. System Programming Q 10: L2/L4 CS Receiver Type – Enter the L2 and L4 digits for the desired receiver type from the table below (checkmark indicates the option is selected). L2/L4 Entry FORMAT PULSE SPEED HANDSHAKE FREQUENCY Digit* 10 PPS 20 PPS 40 PPS 1400 HZ 2300 HZ PARITY TYPICAL CS RECEIVER FBII, ADEMCO, SILENT KNIGHT FBII, ADEMCO, RADIONICS FBII...
Page 54
OMNI-624/OMNI-624EU Installation and Setup Guide 1 and central station 2 until contact is established or the maximum number of dialing attempts (see Question 11, Location 3) expires. Dual: Events will be sent to both central station phone numbers. Split Reporting: If split reporting is enabled, then all reports other than openings and closings will be sent to CS#1.
Page 55
Section 6. System Programming Q 11, L4 Restore Reporting – Enter the digit for the type of Restore reports to be sent. Program the actual trouble Restore report code in Submode 2, Question 47, Location 4. Send AC Send Low Send Zone Restore Entry...
Page 56
OMNI-624/OMNI-624EU Installation and Setup Guide Q 12, L2 – Enter the digit for the desired options from the table below. 4705 Relay Enable: Enables the Relay AC Freq. XL4705 Relay RF Receiver Module. If used, the system’s built-in triggers 3...
Page 57
Section 6. System Programming Bell/Siren Supervision – Select this option to comply with NFPA 72 requirements. If selected, the bell/siren will be supervised for an open circuit across the alarm sounder output terminals. If a fault is detected, the keypad will display a bell supervision condition. Q 12, L4 –...
Page 58
OMNI-624/OMNI-624EU Installation and Setup Guide Q 13, L1 – Enter the L1 digit for the desired user options from the table below. User Users 31, No Code for Door Users User On-line: Allows Quick Command Entry On-line 32 Duress Door Strike 20–30...
Page 59
Section 6. System Programming Q 13, L3 – Enter the L3 digit from the table below. Supervision Pager Attempts Time (Hours) Entry disabled Pager attempts: This sets the number of times the system will send a report to a pager. disabled Supervision Time: This sets the time interval within which the RF Receiver must hear from transmitters,...
Page 60
OMNI-624/OMNI-624EU Installation and Setup Guide Q 14, L1 – Enter the L1 digit from the table below. Stay Arms Stay: If enabled, the system will arm in the Stay- No FOB Instant STAY mode by simply pressing the [STAY] key (user code...
Page 61
Section 6. System Programming Q 14, L3 – Enter the L3 digit from the table below. Disable Arm Disable Arm Exit Entry Partition 1 Partition 2 Extends Disable Arming: If selected, the respective partition cannot be armed. See Submode 2, Question 48, L1/L2 for entering the report code (must be “DD”) that is sent if a user attempts to arm the system after this option has been set.
Page 62
OMNI-624/OMNI-624EU Installation and Setup Guide QUESTION 15 SOUND OPTIONS This question defines sounder and bell options. Enter the digits as follows: Q 15, L1 – Enter the L1 digit from the table below. Fob/Key Arm Bell Disarm Fast Entry Ding...
Page 63
Section 6. System Programming Q 15, L3 – Enter the L3 digit from the table below. Phone Fail Enable: If selected, the phone Phone Fail Phone Fail Phone Fail Bell Ring Entry Enable Sounder Bell Cancel line is monitored. If the phone line is not detected for approximately 4 minutes, a phone fail message will be displayed, and, if the phone fail sounder and/or phone fail bell...
Page 64
OMNI-624/OMNI-624EU Installation and Setup Guide QUESTION 16 DISPLAY OPTIONS This question defines display options. Enter the digits as follows: Q 16, L1 – Enter the L1 digit from the table below. Armed Bypass Display Fault No AC Loss Manual Entry...
Page 65
Section 6. System Programming Q 16, L3 – This location selects the type of clock displays. Enter the L3 digit from the table below. Clock Day/Month Display Display Clock: Shows time in 24-hour format, AM/PM 24hr mm/dd dd/mm Entry Time Clock Fail 00–23 hours.
Page 66
OMNI-624/OMNI-624EU Installation and Setup Guide Q 17, L1 – Enter the L1 digit from the table below. Event Log Enable #53 Log Log Zone Log Zone Entry by Part. / All Command Alarms Troubles By Part. / All: If selected, only the...
Page 67
Section 6. System Programming Q17, L3 – Enter the L3 digit for the desired events to be recorded in event log L3 Entry Log RF Battery Log RF Supervision Log Tamper Log Bypass QUESTION 18 BELL TIMEOUT/AC DELAY/RING COUNT Burg bell Fire bell AC dial Ring timeout timeout delay...
Page 68
OMNI-624/OMNI-624EU Installation and Setup Guide Q 18, L3 – AC Dial Delay AC loss reporting time may be delayed in 15-minute increments for values 1–F. Zero selects random delay, which can be anywhere between 10 and 225 minutes. Enter AC loss dial delay from the table below.
Page 69
Section 6. System Programming Q 19, L1, L2 – Exit Delay This question defines exit delay and dialer delay values. Enter the digit for the desired exit delay for partition 1 in location 1 and partition 2 in location 2 as follows. L1-L2 Exit L1-L2...
Page 70
OMNI-624/OMNI-624EU Installation and Setup Guide Q 22 TEST REPORT TIME Hours (00-23) Minutes (00- This question sets the central station test time. L1/L2: Enter hour 00–23 by entering the first digit of the hour (0–2) in L1 and the second digit (0–3) of the hour in L2.
Page 71
This question defines if the system should detect a jam signal from the RF receiver, and if detected, determines the type of jamming to be recognized and the action to be performed (sounder or bell). NOTE: RF Jamming detection will only function if the system uses a ZR-402EU or OMNI-RF Receiver that has jam output capability.
Page 72
OMNI-624/OMNI-624EU Installation and Setup Guide Jam Detection Action: The actions that can be taken by the system when a valid jam signal is detected is to report the jam, report the jam and sound the keypad sounder or alarm sounder, or report the jam and sound both the keypad sounder and alarm sounder.
Page 73
Section 6. System Programming QUESTION 27 SOFT KEY FUNCTIONS FOR & # & # Keys For L1, make selections from the table below. Sounder Options Relay Options L1/L3 Burg. Mom. Mom. Entry Silent Keypad Bell Temporal Relay Seconds Minutes Toggle For L2, make a selection from the table below.
Page 74
OMNI-624/OMNI-624EU Installation and Setup Guide QUESTION 28 AUTO-ARM ENABLES Q 28, L1–L2 Part 1 Part. 2 Up/About This question enables auto-arming. See Question 29 (partition 1) and 30 (partition 2) for setting the auto-arm times for each partition. Enter the L1–L2 digits as follows:...
Page 75
Section 6. System Programming QUESTION 30 AUTO-ARM TIME PARTITION 2 Hours (00-23) Minutes (00-59) QUESTION 31 NOT USED QUESTIONS 32–43 TRIGGER/RELAY TYPES These questions set relay and trigger types. Momentary trigger times in seconds or minutes for each partition are set in Questions 65 and 66. Each trigger definition requires 2 locations to define its operation.
Page 76
OMNI-624/OMNI-624EU Installation and Setup Guide P2 Relay Type Description Interior Zone Faulted On if any interior zone is faulted in the selected partition. Zone Tamper On if any Tamper has occurred on a zone. Includes RF and hardwired (if double balanced).
Page 77
Once a keypad’s partition assignment has been changed (using the #0 command), the following questions can be used to enable/disable keypad addresses. NOTE: LCD = OMNI-LCD*; Non-LCD = OMNI-KP* or XK-108L** * addressable via keypad programming; ** addressable via DIP switches...
Page 79
Section 6. System Programming Q44 KEYPAD MAPPING for PARTITION 1 Q45 KEYPAD MAPPING for PARTITION 2 LCD Keypads Non-LCD keypads LCD Keypad Non-LCD keypad This question assigns keypads to ptn. 1. This question assigns keypads to ptn. 2. Enter the digits from the tables above. Enter the digits from the tables above.
Page 80
OMNI-624/OMNI-624EU Installation and Setup Guide Q 55 KEYFOB 4 FUNCTIONS Q 56 KEYFOB 4 USER Button 1 Button2 Button 3 Button 4 Arm Part. User number Q 57 KEYFOB 5 FUNCTIONS Q 58 KEYFOB 5 USER Button 1 Button2 Button 3 Button 4 Arm Part.
Page 81
Section 6. System Programming QUESTIONS 67–68 OPEN/CLOSE CENTRAL STATION REPORT DISABLES These questions set the open/close report to central station option for each user. Users are normally enabled for open/close reporting. Selecting the option for a user disables the open/close central station report for that user.
OMNI-624/OMNI-624EU Installation and Setup Guide Q 68 OPEN/CLOSE REPORT DISABLES FOR USERS 17–32 17-20 21-24 25-28 29-32 Q 68, L1 Users 17–20 Open/Close Report Disable Q 68, L2 Users 21–24 Open/Close Report Disable User User User User User User User...
Page 83
Section 6. System Programming QUESTIONS 01–24 ZONE TYPES AND ATTRIBUTES Zone Part./ silent/ stay/chime Type config swing dial delay These questions are used to program zone information. Use the separate Programming Form to enter the actual values for each zone. For each of the following questions, enter the digits as follows: L1: –...
Page 84
OMNI-624/OMNI-624EU Installation and Setup Guide L2: – Partition, zone configuration, supervision options Partition: Select the partition in which Partition Hardwire Loop Type Wireless Supervision the zone is located. Entry Supervise Tamper Hardwire Loop Type – If this is a hardwire zone, select the type of loop.
Page 85
Section 6. System Programming Typical Question 01–24 Layout Zone Part./ silent/ stay/chime Type config swing dial delay Q 01 ZONE 1 (type/attributes) Q 13 ZONE 13 (type/attributes) Q 02 ZONE 2 (type/attributes) Q 14 ZONE 14 (type/attributes) Q 03 ZONE 3 (type/attributes) Q 15 ZONE 15 (type/attributes) Q 04 ZONE 4 (type/attributes) Q 16 ZONE 16 (type/attributes)
Page 86
OMNI-624/OMNI-624EU Installation and Setup Guide QUESTIONS 37–49 SYSTEM REPORT CODES digit 2 digit 1 digit 2 digit event “a” event “b” These questions enable the reporting of the event indicated on the EEPROM map if the value is not “A”...
Page 87
Section 6. System Programming QUESTION 50 FIRST RF ZONE/FIRST DOUBLED ZONE First RF Zone First Doubled Zone This question sets the first RF zone and the first hardwire doubled zone. Enter digits as follows: L1: Enter the first digit of first RF zone number (wireless zone numbers must start after the last hardwire zone).
OMNI-624/OMNI-624EU Installation and Setup Guide L1/L2: First and second digit, respectively, of first zone of crossed zone group 1 L3/L4: First and second digit, respectively, of second zone of crossed zone group 1 Example: Locations 1, 2 = 11; Locations 3, 4 = 23. This results in a cross between zones 11 and 23.
Section 6. System Programming L2: Should always be “1,” unless you want to swap the order of zone numbering for the transmitter’s loops 1 and 2, in which case enter “9.” For example, if you are using a 2-loop transmitter such as the ZR510 or 5816 and only want to use the magnetic reed switch (loop 2) you would enter 9 so that loop 2 would be treated as loop 1.
Page 90
OMNI-624/OMNI-624EU Installation and Setup Guide 2. Press the INSTANT key to move the cursor to the desired location within that Question. 3. Press one of the character display keys (see table below) to display the character set. 4. When the desired character appears, press INSTANT. The character is accepted and the cursor moves to the next location.
S E C T I O N Central Station Reporting Formats • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • General Information This security system is designed to transmit data to a central station receiver when an alarm, system trouble, or an opening/closing occurs.
Section 8. Central Station Reporting Formats The Partial Extended format is a combination of both the Standard and Extended formats. It transmits in Pulse a standard message for alarm conditions and an extended message for restores and other system conditions. To report a standard message, enter a numerical digit (0 - 9) in the first of the 2- digit reporting code;...
OMNI-624/OMNI-624EU Installation and Setup Guide the conventional pulse formats, since it uses DTMF (touch-tones) instead of pulses to transmit the data and it always sends a parity digit. For alarms, openings and closings, the Alarm Type digit will be the same as the Signal Type. This indicates the type of activity or condition that has occurred.
Section 8. Central Station Reporting Formats ADEMCO Point ID The Point ID Reporting Format: AAA 18 QXYZ GG ZZZ, where: AAAA = Four-digit account number (Submode 1, Questions 06–09) 18 = Uniquely identifies this format to the receiver and to an automation system but is not displayed or printed Q = Event qualifier, which gives specific event information 1 = New Event or Opening...
Page 98
OMNI-624/OMNI-624EU Installation and Setup Guide FIRE ZONE TYPES EVENT ENGLISH OUTPUT AT EVENT ENGLISH OUTPUT AT DIGIT CODE CS RECEIVER DIGIT CODE CS RECEIVER Fire Alarm General Alarm Smoke 24-Hour Non-Burg Combustion High Temperature Water Flow Low Temperature Heat Fire Supervisory...
Page 99
Section 8. Central Station Reporting Formats KEYPAD ZONES (Fire*, Panic*, Aux.*, Ambush) EVENT ENGLISH OUTPUT AT EVENT ENGLISH OUTPUT AT DIGIT CODE CS RECEIVER DIGIT CODE CS RECEIVER Medical Silent Panic Pendant Transmitter Audible Panic Fire Alarm Burglary Smoke 24-Hour Alarm Combustion General Alarm Flame...
Page 100
OMNI-624/OMNI-624EU Installation and Setup Guide...
S E C T I O N Regulatory/Limitations Statements • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • RADIO FREQUENCY EMISSIONS STATEMENTS FEDERAL COMMUNICATIONS COMMISSION (FCC) Part 15 This device complies with part 15 of the FCC rules.
Page 104
OMNI-624/OMNI-624EU Installation and Setup Guide TELEPHONE/MODEM INTERFACE STATEMENTS (continued) INDUSTRY CANADA (continued) Users should ensure for their own protection that the electrical ground connections of the power utility, telephone lines and internal metallic water pipe system, if present, are connected together, This precaution may be particularly important in rural areas.
Page 105
Maintenance is best performed by your installing company with trained service personnel. O560 DECLARATION OF CONFORMITY OMNI-624 and OMNI-624EU are in conformity with the essential requirements as described in Directive 1999/5/EC and satisfy all the technical regulations applicable to the product within this directive...
OMNI-624/OMNI-624EU Installation and Setup Guide LIMITATIONS OF THIS SYSTEM While this system is an advanced design security system, it does not offer guaranteed protection against burglary, fire, or other emergency. Any alarm system, whether commercial or residential, is subject to compromise or failure to warn for a variety of reasons.
Page 107
Section 10. Regulatory/Limitations Statements is muffled by noise from a stereo, radio, air conditioner or other appliances, or by passing traffic. Finally, alarm warning devices, however loud, may not warn hearing-impaired people or waken deep sleepers. • Telephone lines needed to transmit alarm signals from a premises to a central monitoring station may be out of service or temporarily out of service.
LIMITED WARRANTY Fire Burglary Instruments Inc., a Subsidiary of Pittway Corporation, and Pittway Corporation, its divisions, subsidiaries, and affiliates ("Seller") 180 Michael Drive, Syosset, New York 11791, warrants its products to be in conformance with its own plans and specifications and to be free from defects in materials and workmanship under normal use and service for five years from the date stamp control on the product, or for products not having a date stamp, for twelve months from the date of original purchase unless the installation instructions or catalog sets forth a shorter period, in which case the...
