Pump Assembly - ARY VacMaster SVP-20 Operator's Manual

Photo # SVP-20
23 977596
24 977598
25A 977675
26 977593
27 977594
28 977605
28A 977671
29 977553
30 977641
31 977530
31A 977672
32 977558
33 977595
34 977561
ALL 977635
ALL 977636
Photo # SVP-20
35 977647
35 977658
36 977648
37 977669
38 977590
39 977507
40 977325
41 977390
42 977509
43 977381
44 977587¹
¹For 220V Models SVP-20 and 30, order part #977588.
²For 220V SVP-40 use #977694.
SEAL BAR
SVP-30 SVP-40
977583 977678
977598 977598
977675 977675
977593 977593
977594 977594
977605 977605
977671 977671
977553 977553
977641 977641
977584 977686
977695 977696
977558 977558
977595 977595
977561 977561
977663 977690
977692 977691

PUMP ASSEMBLY

SVP-30 SVP-40
977647 977647
977658 977658
977648 977648
977669 977669
977590 977590
977507 977507
977325
See Cabinet
977390 977390
977509 977509
977381 977381
977587¹ 977693²
10
Description
Top Bar
Silicone Seal Pad – Per Ft.
Tape – Qty Per Ft. Top Layer
Wire, Cut-Off – Qty Per Ft.
Wire, Seal (Toss Wire) – Qty Per Ft.
End, Seal Bar Brass
End, Seal Bars, Brass, Bag Cut-Off
Screw, Set 10-32 x ¼"
Contact, Brass .016 x ¼" 1 ½" L – Qty Per
Inch
Seal Bar
Seal Bar – Bag Cut-Off
Screw, Seal Bar Phenolic #4 x ⅜" PPH TSA
ZC
Plate, BTTM Seal Bar Brass
Screw, Seal Bar for Phenolic
Seal Bar Assembly
Seal Bar Cut-Off Assembly
Description
Air-Port
Fitting, Air Plastic ⅜" HB - ¼" NPT Straight
Inlet Port Seal O-Ring
Sheet Metal Screw #6 x ¾" Stainless Slot
Black
Hose, Vacuum 3/8" ID
Fitting, Plastic Tee
⅜" HB x ⅜" HB x ¼" HB Branch
Feet, Rubber
Fitting, Plastic Tee
¼" HB x ¼" HB x ¼" HB
Fitting, Plastic Tee ⅜" HB x ⅜" HB x ½" NPT
Branch
¼" ID Hose Poly-Spring – Qty Per Ft.
Pump 110V
