Instruction Manual for DISH
Users
®
www.winegard.com/mobile
For receivers and programming, call 1-866-609-9374
For up-to-date information on receiver compatibility and
programming, visit www.winegard.com/receivers
For help, email help@winegard.com or call 1-800-788-4417
Do not return antenna to place of purchase
2452276
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Winegard Carryout Anser
- Page 1 Instruction Manual for DISH Users ® www.winegard.com/mobile For receivers and programming, call 1-866-609-9374 For up-to-date information on receiver compatibility and programming, visit www.winegard.com/receivers For help, email help@winegard.com or call 1-800-788-4417 Do not return antenna to place of purchase 2452276...
- Page 2 Follow the instructions on this side of the manual if setting up the Anser antenna ® for use with DISH programming. If setting up the Anser for use with DIRECTV Programming, follow the instructions on the reverse side of the manual.
- Page 3 Antenna Parts of the Antenna in Deployed Position Reflector cover Protects inner components from environment Secondary port Connects to secondary receiver (or dual tuner) Elevation lock Main port Secures rotating housing at Connects to primary desired elevation receiver Quick disconnect socket Connects to power source Antenna in Stowed Position Rotating housing...
- Page 4 Do not install or operate the antenna in winds of 35 mph or greater. The Anser antenna will roll in winds ≥35 mph. Do not place the antenna in water >2 inches deep, or the water may damage the electronics.
- Page 5 DISH Receiver Setup DISH receivers will often not show when they are on signal if they have Check out online receiver incorrect “Check Switch” information. For this reason, DISH users must clear setup guides for your their current settings before pointing. To do this for most DISH receivers, antenna at www.winegard.com/ ®...
- Page 6 Coax cable connected to sec. port Power cable connected to quick disconnect socket NOTE Run the coaxial cable directly from the satellite receiver to the Anser The 12 VDC power source antenna when searching for signal. or 110 V to 12 VDC...
- Page 7 Anser antenna will move to the next If the power is not strongest satellite after 45 seconds of inactivity. If the Anser antenna cycles disconnected from the through all satellites but the desired satellite has not been found, disconnect source quickly enough, the antenna the power from the power source, set the elevation for 2–3 degrees higher or...
- Page 8 Transporting the Antenna When transporting the antenna, return the unit to the stowed position. The elevation arrow should align with “STOW.” Once in the stowed position, tighten the lock until fingertight. Using Outside Receptacle If your outside TV receptacle is wired for satellite, you’ll need to locate where that receptacle leads, and connect that directly to your satellite receiver.
- Page 9 Printed in U.S.A. ©2012 Winegard Company Rev7 10/14 2452276 Winegard, Carryout, and Anser are registered trademarks of Winegard Company. DISH and ViP are registered trademarks of DISH Network L.L.C. Bell TV is a registered trademark of Bell Canada, Inc. DIRECTV is a registered trademark of DIRECTV, LLC.
