PT Thermal Series Quick Start Guide
Document Number: 1018264, Revision A
Important Safety Instructions
1.
Read these instructions.
2.
Keep these instructions.
3.
Heed all warnings.
4.
Follow all instructions.
5.
Install in accordance with the manufacturer's instructions.
6.
Do not defeat the purpose of the polarized or grounding-type plug.
A polarized plug has two blades with one wider than the other. A
grounding type plug has two blades and a third grounding prong.
The wide blade or the third prong is provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
7.
Use only with the tripod or bracket specified by the manufacturer, or
sold with the apparatus.
8.
Installation of the equipment must comply with local and national
electrical codes.
9.
This product must be connected to a Power Over Ethernet IEEE
802.af compliant power source or a UL Listed "Class 2" power supply
rated 12-24 V DC or 24 V AC minimum 13 W or 0.54 A.
10. Operating the camera at voltage levels outside the specified range
may result in permanent damage to the unit and void the product
warranty.
11. Clean the camera lens only with Kodak lens cleaning paper.
12. Failure to follow the proper procedure may cause permanent
damage to the camera and void the product warranty.
©Copyright 2013, CBC AMERICA, Corp. - All rights reserved. The contents of this document may not be reproduced in whole or in part without the written
DEVICE SENSITIVE TO ELECTROSTATIC DISCHARGE
The camera electronics and electronic interfaces are sensitive to
electrostatic discharge. Please follow appropriate ESD procedures when
handling the camera and during installation.
AMERICA strongly recommends the use of STP cabling and an earth
grounded end point to ensure proper ESD immunity.
powered installations, a properly earth grounded power source is strongly
recommended.
To ensure a proper earth ground (between the GANZ THERMAL camera
and a PoE switch) CBC AMERICA strongly recommends the use of Shielded
Twisted Pair (STP) cabling. Installations of GANZ THERMAL cameras using
a STP cabling and a properly earth grounded PoE switch are tested to
comply with industry immunity standards for Electro Static Discharge.
Any other installation method may leave the camera at risk and void the
warranty.
consent of the copyright owner.
December 2013
WARNING
For PoE installations, CBC
CAUTION
For AC or DC

Advertisement

loading
Need help?

Need help?

Do you have a question about the PT Thermal Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Ganz Thermal PT Thermal Series

  • Page 1 This product must be connected to a Power Over Ethernet IEEE To ensure a proper earth ground (between the GANZ THERMAL camera and a PoE switch) CBC AMERICA strongly recommends the use of Shielded 802.af compliant power source or a UL Listed “Class 2” power supply Twisted Pair (STP) cabling.

  • Page 2: What's In The Box

    Important Legal and Regulatory Information Introducing Ganz PT Thermal Legal Consideration This document provides information about Ganz Thermal Series, a Pan & ALL STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN THIS Tilt, Fixed Focal Length Infrared Camera. You can download all required...
  • Page 3 PT Thermal Series Quick Start Guide December 2013 You will need the following items (not included) before you can install the IP Camera (recommended tool list) Power source: PoE Switch, 12-24V DC or 24V AC • IP Network • Ethernet Cable (STP Cat5 required) •...
  • Page 4 PT Thermal Series Quick Start Guide December 2013 Securing for IP66 (Analog & AC/DC Power) Measure approximately 5 inches of cable slack from the end of the cable to the rubber grommet of the sealing gland. Use a scale to Slide the Coax cable through the threaded end of the cable sealing measure the length.
  • Page 5 PT Thermal Series Quick Start Guide December 2013 Tighten the gland nut onto the gland housing. Leave about 5 inches of cable sticking out of the gland housing Push the gland housing over the cables Push the gland rubber into the gland housing...
  • Page 6 PT Thermal Series Quick Start Guide December 2013 Insert the cable and gland into the camera. Connect the Analog If powering the camera with an AC supply, connect AC+ to the cable and CAT5 cable to the camera. Slide the gland housing-to- 24VAC input and the AC- to the other 24VAC input chassis nut over the cables.
  • Page 7 PT Thermal Series Quick Start Guide December 2013 Mounting the Ganz PT Thermal Camera Attach the camera to the strain relief wire on the wall mount by placing the loop of the wire through the hook of the top hat. This will support the weight of the camera for the rest of the installation.
  • Page 8 Camera via its Web Page to make configuration changes and view live router, find the attached PT Thermal Camera and find its IP address. video using the GANZ THERMAL Web Interface. In order to make these Enter the IP address of the IP Camera on the Browser URL line.
  • Page 9 PT Thermal Series Quick Start Guide December 2013 For More Information Category Online Location Ganz Thermal PT Camera Series www.ganzsecurity.com/manuals Documentation Ganz Thermal PT Camera Support www.ganzsecurity.com/support VLC Media Player http://www.videolan.org/vlc/ www.ganzsecurity.com...
