M E A D O W B R O O K - F 2 4 9 2 0
INSTALLATION AND OPERATING INSTRUCTIONS
10-14 Hrs
Two person
assembly
9404920
WARNING
Manufacturer contact information provided below.
OBSTACLE FREE SAFETY ZONE - 27'5" x 27' area requires Protective Surfacing. See page 3.
MAXIMUM VERTICAL FALL HEIGHT - 6'9"
CAPACITY - 13 Users Maximum, Ages 3 to 10; Weight Limit 110 lbs. (49.9 kg) per child.
RESIDENTIAL HOME USE ONLY. Not intended for public areas such as schools, churches, nurseries, day cares
or parks.
375 Sligo Rd. West, PO Box 10
Solowave Design
Mount Forest, ON Canada N0G 2L0
8:00am - 4:30pm EST
General Inquiries:
Toll Free: 1-877-966-3738
support@solowavedesign.com
To reduce the risk of serious injury or death, you must read and
follow these instructions. Keep and refer to these instructions
often and give them to any future owner of this play system.

Table of Contents

Warnings and Safe Play Instructions. . . . . . . . . . pg. 2
Protective Surfacing Guidelines . . . . . . . . . . . . . . . pg. 3
Instructions for Proper Maintenance . . . . . . . . . pg. 4
About Our Wood - Limited Warranty . . . . . . . . . pg. 5
Keys to Assembly Success . . . . . . . . . . . . . . . . . . . . pg. 6
Metric Conversion Sheets . . . . . . . . . . . . . . . . . . pg. 7,8
Part ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pg. 9
Step by Step Instruction . . . . . . . . . . . . . . .. . . pg. 17-77
Installation of I.D./Warning Plaque . . .. . . .Final Step
Rev 09/28/2015
