- Page 1 Ultra high brightness mirror monitor User manual AK-035LA AK-043LA BK-043LA DK-043LA EK-035LA EK-043LA HK-043LA ksize.ru...
-
Page 2: Table Of Contents
Table of contents ..... . . Chapter One: Product introduction 1.1 Package ......... 2 1.2 Features . -
Page 3: Chapter One: Product Introduction
Chapter one: Product Introduction User's Manual 1.1 Package Welcome to use our ultra high brightness Rearview mirror monitor. The packing box contains the following accessories, please confirm: ●We reserve the final explana on right on this User's Manual. ● Rearview mirror monitor ●Specifica ons are subject to change without no ce. -
Page 4: Chapter Two: Installation And Wire
Video input: short press to turn on/off auto-dimming long press to turn on/off the screen. camera input: adjust brightness of the screen image AK-035LA / EK-035LA AK-043LA / EK-043LA Mirror without auto-dimming func on: When the screen turns off or doesn't have video signal, the indicator light will light up, conversely, it turns off... -
Page 5: How To Install High Brightness Mirror Monitor
2.2 How to install high brightness mirror monitor 2.3 Special bracket 2.2.1 Remove the original mirror Different cars have different brackets. It depends on your vehicle maker and manufacturer. There are many methods to remove the original rear-view mirror, however ,please don’t force the mirror off the bracket. -
Page 6: How To Wire
2.5 How to wire After the mirror is mounted, you need to run the cable along the roof lining and down the pillar so you can connect to Power and the rear view camera rearview mirror monitor mirror monitor cable Car camera extension cable Video in camera (not included) -
Page 7: Chapter Three: Basic Functions
Weak light Strong light Chapter Three: Basic functions 3.1 High reflectance mirror Clear back up view displayed on high-reflectance mirror. Top grede Mirror Weak light Strong light high-reflectance mirror normal-reflectance mirror 3.2 Back up camera dispaly When the car is in reverse, the monitor will automa cally display backup camera. in reverse not in reverse Budget grade Mirrors... -
Page 8: Chapter Four: Optional Function
Chapter Four: Optional functions 4.1.3 How to adjust the guide line According to the site of standard reference line, we can put reference objects 4.1 Adjustable guide line such as desks in the back area of car. Compared with the marked reference objects, we can adjust the sites and angle of two guide lines displayed on the 4.1.1 About guide line monitor. -
Page 9: Compass
4.2 Compass 3. Drive your vehicle in at least 2 circles' counterclockwise, allowing 45 seconds to complete one circle 4.2.1 Digital Compass Calibration(BK-043LA / DK-043LA) This compass can be calibrated by driving your vehicle in several complete 4. For best calibration, keep your circle radius close to 5 meters and circles. - Page 10 4.2 Compass 3. Drive your vehicle in at least 2 circles' counterclockwise, allowing 45 seconds to complete one circle 4.2.2 Digital Compass Calibration(AK-035LA AK-043LA EK-035LA EK-043LA) 4. For best calibration, keep your circle radius close to 5 meters and This compass can be calibrated by driving your vehicle in several complete speed less than 10km/h.4-2-2-3...
-
Page 11: Temperature
4.3 Temperature 4.3.3 Temperature sensor installation Locate the temperature sensor between the front of the radiator and the 4.3.1 How to set (BK / DK SERIALS) front bumper MENU Press the enter into “TEMP UNIT”, press , you can Locate edge of sheet metal or plastic shield, and slide metal clip over edge switch F to C 4-3-1 until secure. -
Page 12: Parking Sensor
4.4 Parking sensor 4.4.1 How to wire PUSH OUT OPEN Green to back Video in rearview mirror monitor mirror monitor cable extension cable Mirror without auto-dimming func on: Video input: turn on/off the screen Camera input: short press adjust the brightness of the screen image long press to turn on/off... - Page 13 4.5 Special for GM Onstar system and HYUNDAI Bluelink system 4.5.1 The buttons Note: Onstar system and Bluelink system are the patent and trade mark from GM and HYUNDAI car factories respec vely. rearview mirror monitor mirror monitor cable car camera extension cable camera (not included) Special for GM On Star system Camera(Not Included)
-
Page 14: Dimming Functions
4.6 Dimming Functions manual-dimming bleaching state manual-dimming working state 4.6.1 Why need dimming function ● To protect drivers from night glare of headlight. ● It is a function that can improve the car safety level. ● It may cause a series of legal disputes once removed by car dealers or sellers 4.6.3 Auto dimming The auto-dimming of our mirror works automatically when you start the engine, then the indicator light also lights.
