- Page 1 796-2015 GIPDC/B User Guide • Single gang PIR switch • Replaces a standard light switch or dimmer • Turns off automatically • Turns on automatically • Security mode • Switches all lighting, heating and ventilation loads up to 10A...
-
Page 2: Installation
installation This product should be installed in accordance with the current IEE wiring regulations. If in doubt consult a qualified electrician. Use the extender if there is less than 25mm free space. Compatible with all BS4662 dimensions back boxes. REMEMBER – put the wires through the extender before connecting. - Page 3 wiring 1 way switching If the lights are controlled from one location only, wire as in the diagram. May have red May have red or or brown sleeve brown sleeve Neutral Black or Blue Com L1 Live Red or Brown Earth Yellow Green Strapper...
-
Page 4: Controls And Basic Operation
controls and basic operation Remove front cover Use a flathead screwdriver or similar to gently prise off the cover and replace with new one by snapping on to switch. time setting daylight setting battery indicator PIR lens battery toggle switches Short press –... -
Page 5: Quick Start Guide
Remove top and bottom Remove top Lamps lugs if fitted and bottom lugs if fitted setup and suggested settings May have red or brown GIPDT sleeve GIPDC GIPDT Com L rt Guide Time setting 1min – 30min Toggle switch settings Quick Start Guide The lights will turn off after the set time period. -
Page 6: Security Mode
activate • Before using, the unit needs to be activated • Press and hold the top button for more than 5 seconds. The red LED will flash to indicate that it has activated and the unit will now operate • If the unit is going to be out of use for prolonged periods (more than 6 months) it should be deactivated by repeating the procedure above with the bottom button. -
Page 7: Battery Replacement
battery replacement 1. Remove front 2. Remove switch 3. Lever out battery cover cover 4. Replace battery 5. Push into holder 6. Replace switch cover 7. Replace front cover 8. Activate... -
Page 8: Troubleshooting
troubleshooting Lights turn off even though room is occupied • Check location of sensor – see detection diagram • Increase timing, typically 15 minutes for a living area. Lights never turn off • The lights will only turn off after no movement is detected for the time period. Is the time period set too long? ratings EMS 534520...
