Summary of Contents for FireBird CHDMI38C
- Page 1 3-in/8-out HDMI Switcher/ Distributor Operation Manual CHDMI38C...
- Page 2 Table of Contents Introduction ……………………..……………………...…..….……. Features …………………………………………..……..…...…… Operation Controls and Functions ……………...……....…… Front Panel ................Rear Panel .…………………………………..……..…...….… Remote Control .......…..……………..…..…..…... Specifications ………………………………...……..………..…. CHDMI38C RS-232 Remote Control Protocol ........ Connection and Installation ….…………………..…..…..…..Acronyms …..................
- Page 3 1. Introduction CHDMI38C is a high performance 3-in 8-out HDMI Switcher with remote con- trol. It allows you to connect up to 3 HDMI sources and 8 HDMI displays. The eight HDMI outputs are identical and each supports up to 1080p. Simply pressing one button you can select your desired HDMI source for display on eight HDMI TV simultaneously.
-
Page 4: Operation Controls And Functions
DVD player or set-top-box. ③ HDMI outputs 1 to 8: Connect each of these output ports to the HDMI input of a HDMI display. ④ Power: Plug the 5V DC power supply into the CHDMI38C and connect the adaptor to AC wall outlet. -
Page 5: Remote Control
Operating temperature range 0˚C ~ 40˚C Dimensions (mm) 436(W) x 116(D) x 44(H) Weight(g) 1600 6. CHDMI38C RS-232 Remote Control Protocol * The connection between CHDMI-38C and remote controller with RS-232 modem cable. Pins definition of modem cable CHDMI-38C Remote Controller Definition... -
Page 6: Connection And Installation
Command Code Comment W 01 01 PORT 1 ON W 01 02 PORT 2 ON W 01 03 PORT 3 ON 7. Connection and Installation DVI to HDMI HDMI HDMI Cable Cable Cable HDMI HDMI HDMI HDMI HDMI HDMI HDMI HDMI Cable Cable...
