Flylife Titanium 7 Service Manual CAUTIONS Please refer to the tablet’s user’s guide for instructions relating to operation, care, and maintenance, which include important safety information. Servicing and alignment must be undertaken by qualified personnel only. Ensure all work is carried out at an anti-static workstation and that an anti-static wrist strap is worn. Use only approved components as specified in the parts list.
Page 2
Product Hardware Definition RK3168 PMIC TPS659102/QFN48 WIFI RTL8188ETV Audio CODEC ES8323/QFN28 Base Chip Set Audio PA LPA2013MSF/MSOP8 FLASH MLC (8G) DDR3 (512M) TP IC GSL168X/QFN_5X5MM_40_0D4 165*100*2.8mm 1024*600 50PIN Backlight Peripheral LP3302SB6F/SOT23-6 driver Configuration CAMERA 30W GC0309 Antenna TLT2690-M739-3 L=180MM (Φ 1.13+Tin)
