- Page 1 Donut Depositor Type N Operator’s Manual Technical Supplement Belshaw Bros., Inc. 814 44th Street NW, Suite 103 Auburn, WA 98001 USA Tel: (206) 322-5474 Fax: (206) 322-5425 Toll Free (US): 1-800-578-2547 E-mail: service@belshaw.com www.belshaw.com...
- Page 2 Donut Cutter Type N Operator’s Manual Belshaw Bros., Inc. 814 44 Street NW, Suite 103 Auburn, WA 98001 USA Phone: (206) 322-5474 ● Fax: (206) 322-5425 Email: service@belshaw.com ● http://www.belshaw.com...
- Page 4 If you accept the machine from the shipping company, you are, in effect, saying that the machine is in good condition, and you must IMPORTANT pay for the machine. The freight company has accepted responsibility for the safe delivery of Keep this manual for reference purposes.
-
Page 6: Table Of Contents
Contents Operating Cleaning Care, Maintenance, and Cleaning for Plungers and Hoppers Care and Cleaning of Cutters and Dispensers Maintenance Donut Making Helps Tips on Making Quality Cake Donuts Tables & Formulas used in Donut Making Belshaw Bros., Inc. • www.belshaw.com • Phone 206-322-5474 • Fax 206-322-5425 Donut Cutter Type N OM MN-1542EN... - Page 7 Preface The Type N Variety Cutter is designed to cut WARNING cake donut products and deposit them in a variety of smaller fryers. It is designed to be Never put your hand in the hopper or mounted on a wall or on a fryer mount. between trip arms while machine is being During production, the operator must move the operated.
- Page 8 Operation Operation of this machine is very simple, but 6. When the required number of donuts has there are some details to which we would call been dropped, turn the crank again to your attention in order to get the best results, and lowest position and swing machine free keep your machine in perfect running condition.
-
Page 9: Cleaning
Cleaning To facilitate packaging, the Variety Cutter has soda ash, and tri-sodium phosphate, will discolor been partially disassembled and before use it or even corrode aluminum even in weak should be cleaned and properly assembled. solutions. 1. Wash plunger unit in hot water and DO NOT Handle roughly or drop on hard detergent, rinse and wipe dry. -
Page 10: Care And Cleaning Of Cutters And Dispensers
Care and Cleaning of Cutters and Dispensers The most important thing when cleaning aluminum is the selection of the right type of cleaner. Strong alkali cleaners such as lye, soda ash, and tri-sodium phosphate discolor and corrode aluminum, even in weak solutions. A detergent which contains an inhibitor to prevent the attack on metals, such as those listed below, does a good job of cleaning and does not attack... -
Page 11: Maintenance
Maintenance Following are some maintenance and operating hints: • DO NOT at any time use force to assemble or operate the machine. • If machine sticks, disassemble to remove obstruction or check to determine cause and correct same. • Once each week lubricate the operating cams by putting several drops of oil between trip arms when crank case is held with trip arms pointing up. - Page 12 Belshaw Bros., Inc. • www.belshaw.com • Phone 206-322-5474 • Fax 206-322-5425 Donut Cutter Type N OM MN-1542EN...
-
Page 13: Donut Making Helps
Donut Making Helps • Maintain the proper shortening level. We Tips on Making Quality recommend a distance of 1 1/4” between the Cake Donuts cutter and the shortening. • Use the correct batter temperature. If the shortening is too deep, the donuts may not turn over when they reach the turner, In general, the correct batter temperature is causing them to cook unevenly. - Page 14 ABLES AND ORMULAS SED IN ONUT AKING Calculating Correct Water Temperature The following is an example of how to calculate temperature, desired batter temperature, and, if the correct water temperature to use. You must you are making yeast-raised donuts, estimated use your own room temperature, dry mix temperature increase during mixing.
- Page 15 Batter Temperature Chart (Fahrenheit) Flour Temperature Water Temperature 55°F 89°F 56°F 88°F 57°F 87°F 58°F 86°F 59°F 85°F 60°F 84°F 61°F 83°F 62°F 82°F 63°F 81°F 64°F 80°F 65°F 79°F 66°F 78°F 67°F 77°F 68°F 76°F 69°F 75°F 70°F 74°F 71°F 73°F 72°F...
- Page 16 Donut Cutter Type N Technical Supplement Belshaw Bros., Inc. 814 44 Street NW, Suite 103 Auburn, WA 98001 USA Phone: (206) 322-5474 ● Fax: (206) 322-5425 Email: service@belshaw.com ● http://www.belshaw.com...
- Page 18 If you accept the machine from the shipping company, you are, in effect, saying that the machine is in good condition, and you must IMPORTANT pay for the machine. The freight company has accepted responsibility for the safe delivery of Keep this manual for reference purposes.
- Page 20 Contents Installation Wall Mount Fryer Mount Assembly Maintenance Factory Parts & Repair Service Appendix Parts List Drawing Insert Page Insert Belshaw Bros., Inc. • www.belshaw.com • Phone 206-322-5474 • Fax 206-322-5425 Donut Cutter Type N TS MN-1543EN...
- Page 21 Preface The Type N Variety Cutter is designed to cut WARNING cake donut products and deposit them in a variety of smaller fryers. It is designed to be Never put your hand in the hopper or mounted on a wall or on a fryer mount. between trip arms while machine is being During production, the operator must move the operated.
-
Page 22: Installation
Installation This machine is designed to be used on either a wall. The Variety Cutter can be mounted wall mount or a fryer mount. This should be from either side of the kettle or between 2 specified when the machine is ordered from the kettles. - Page 23 fryer. (B) The bottom of the cutter 6. The donut cutter should be mounted on should be 1” to 1 ¼” from the surface of the pin of the outer arm. Adjust the set the shortening. collar under the inner arm to give the proper clearance.
-
Page 24: Maintenance
Maintenance Following are some maintenance and operating number, and the name of the contact person hints: when a cost estimate has been determined. In most cases, the machine can be shipped back, • DO NOT at any time use force to freight collect, within five days. -
Page 25: Appendix
Appendix See Parts List Drawing Insert Page. Belshaw Bros., Inc. • www.belshaw.com • Phone 206-322-5474 • Fax 206-322-5425 MN-1543EN Donut Cutter Type N TS...
