Eclipse ECL-VIP200 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
2-Wire ECL-VIP200 User's Manual
V1.0.0
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ECL-VIP200 and is the answer not in the manual?

Questions and answers

Related Manuals for Eclipse ECL-VIP200

Summary of Contents for Eclipse ECL-VIP200

  • Page 1 2-Wire ECL-VIP200 User’s Manual V1.0.0...

  • Page 2: Table Of Contents

    Table of Contents Table of Contents ........................i Product Overview ....................... 1 List of Models ......................... 1 Structure ........................1 1.2.1 Dimension ......................1 1.2.2 Front Panel ......................2 1.2.3 Rear Panel ......................3 System Networking ......................3 1.3.1 One-to-One Scene ....................4 1.3.2 Group Call Scene ....................
  • Page 3 General Config ......................14 Web Config ....................... 16 System Config ....................... 16 4.1.1 Local Config ....................... 16 4.1.2 LAN Config ......................17 4.1.3 Indoor Manager ....................17 4.1.4 Network Config ....................19 4.1.5 Video Set ......................19 4.1.6 User Manage..................... 20 Info Search ........................
  • Page 4 Appendix 2.3 Embedded Box ....................31 Appendix 3 VTMS ........................32 Appendix 4 VTMS Client ......................34 Appendix 4.1 Config Network Address ..................34 Appendix 4.2 Create Organization ..................36...
  • Page 5 Important Safeguards and Warnings Please read the following safeguards and warnings carefully before using the product in order to avoid damages and losses. Note: Do not expose the device to lampblack, steam or dust. Otherwise it may cause fire or electric shock.

  • Page 6: Product Overview

    Model Chassis Color Unlock Button Type Lock Control Module Material IC card ECL-VIP200 Metal Silver Mechanical Built-in 1.2 Structure 1.2.1 Dimension Before you install the device, please make sure you know the dimension of device and select appropriate installation method. See Figure 1- 1.

  • Page 7: Front Panel

    1.2.2 Front Panel Figure 1- 2 Port Name Note Audio input. Camera It monitors corresponding door region. Light compensation will automatically turn on Compensation during monitoring, calling, or connecting status if Light there is no enough light in environment. Speaker Audio output.

  • Page 8: Rear Panel

    1.2.3 Rear Panel Figure 1- 3 Component Name Note Camera Angle Adjust camera angle. Adjustment Vandal-proof When VTO if forced to leave wall, it will alarm and Switch report to MGT center. Connect to lock, door sensor feedback and unlock User Port button.

  • Page 9: One-To-One Scene

    1.3.1 One-to-One Scene Visitor press Call button to call residence (as VTH) or Center. See Figure 1- 4. Figure 1- 4 1.3.2 Group Call Scene When visitor press Call button on VTO, multiple VTHs will ring at the same time. User can call, hang up, and unlock on any of these VTHs.

  • Page 10: Install Vto

    2 Install VTO 2.1 Direct Installation 2.1.1 Screw Before installing VTH, please check screws on accessory bag according to the following specifications and install by following this guide. Component Name Illustration Quantity M3×6 Hex slot pan head tail machine screws --- galvanizing white M3×8 Cross recessed countersunk head tail machine screws --- galvanizing white...

  • Page 11: Dimension

    2.1.2 Dimension Before you install the device, please make sure you know the dimension of device and select appropriate installation method. See Figure 2- 1. Figure 2- 1 2.1.3 Installation Step Step 1. Install metal bracket into the groove on wall. At spot 1 fasten screw (ST3×18 Cross recessed countersunk head tail tapping screws --- galvanizing white), and fix metal bracket on wall.
  • Page 12 Figure 2- 2 Figure 2- 3...

  • Page 13: Embedded In Wall

    2.2 Embedded in Wall 2.2.1 Screw Before installing VTH, please check screws on accessory bag according to the following specifications and install by following this guide. Component Illustration Quantity M3×6 Hex slot pan head tail machine screws--- galvanizing white M3×8 Cross recessed countersunk head tail machine screws --- galvanizing white Chart 2- 2 Note:...

  • Page 14: Installation Step

    2.2.3 Installation Step Step 1. Dig a hole on wall, its dimension is 117*128*80(mm).See Figure 2- 5. Step 2. Embed metal bracket into wall until its four peaks lean against the wall. See Figure 2- 6. Step 3. Align the device on metal bracket according to screw hole. At 2 spots fasten screws (M3×8 Cross recessed countersunk head tail machine screws --- galvanizing white), and fix device on metal bracket.
  • Page 15 Figure 2- 6 Figure 2- 7...

  • Page 16: Wiring

    2.3 Wiring See Figure 2- 8. Figure 2- 8 Component Note Name Power supply, connect to lock, door sensor and User Port unlock button. Project Port Reserved for project staff use. 2.4 Electric Control Lock and Electromagnetic Lock 2.4.1 Electric Control Lock When VTO connects to electric control lock, it means that the positive end of electronic control lock connects to NO of VTO (user port 10) while its negative end connects to COM of VTO (user port 12).

  • Page 17: Electromagnetic Lock

    Figure 2- 9 2.4.2 Electromagnetic Lock When VTO connects to electromagnetic lock, it means that the positive end of electromagnetic lock connects to NC of VTO (user port 11) while its negative end connects to COM of VTO (user port 12). When VTO connects to door sensor in electromagnetic lock, one end of door sensor connects to FEEDBACK of VTO (user port 8) while the other end connects to GND of VTO (user port 9).

  • Page 18: Installation Debugging

    3 Installation Debugging Warning: Before debugging, the staff shall be familiar with device’s installation, wiring and usage. Before debugging, check wiring for short or open circuit. When staff find each circuit is normal, plug the device to power. After debugging, clear the site. 3.1 WEB Setup If you first use VTO, you may need to operate according to the following steps: Step 1.

  • Page 19: General Config

    3.2 General Config If you first use VTO, you may need to operate according to the following steps: Step 1. In Internet Explorer, input IP address of the VTO, and press Enter. Note: Default IP address of VTO is 192.168.1.110. Default username and password is admin/admin.
  • Page 20 Step 5. (Optional) If VTO connects to VTMS platform, System Config>LAN Config, set Area No. Section No. Building No. and etc. These parameters must match settings on VTMS Client. Please refer to Appendix 2 and 3. See Figure 3- 4. Figure 3- 4 Figure 3- 5 Note:...

  • Page 21: Web Config

    4 Web Config This chapter introduces VTO WEB interface and its parameters, and hot to configure them. 4.1 System Config 4.1.1 Local Config 4.1.1.1 Local Config In Local Config interface, you can view VTO model, version info and etc. Figure 4- 1 Parameter Note Video Format...

  • Page 22: Lan Config

    4.1.1.2 A&C Manager Figure 4- 2 Parameter Note Unlock Responding The interval between current unlock and next one, Interval unit is second. Unlock Period Period door remains unlocked, unit is second. Door Sensor Check When only use door sensor, check”Check Door Time Sensor Signal Before Lock”, Set “Door Sensor Check Time”...
  • Page 23 Add VTH In Indoor Manager interface, click on Add. The system pops up a window as in Figure 4- 4. Figure 4- 4 Fill in VTH info as user’s name, VTH short no. and IP address. Note: VTH short no. consists of four digits, the first two digits can be within 01~99, the last two digits can be within 01~16.

  • Page 24: Network Config

    4.1.4 Network Config Here you can set VTO IP address, Subnet Mask and Default Gateway. After you have modified IP address, Web page will reboot and go to the new IP address web page. See Figure 4- 5. Figure 4- 5 4.1.5 Video Set You can set video effect and volume in Video Set interface.

  • Page 25: User Manage

    Parameter Note Gain Gain limit of video basic parameter. Scene Mode Select mode: automatic, sunny, night and etc. Day/Night Mode Color mode. Back Light Mode Back light for special environment. Mirror Make image displayed in mirror. Flip Display image in flip. VTO Mic Volume Set VTO MIC volume size.

  • Page 26: Info Search

    Modify User In User Manage interface, click on , system pops up Modify User interface. Check Change Password, and change password and remark, see Figure 4- 8. Figure 4- 8 Delete User In User Manage interface, click on to delete user. 4.2 Info Search 4.2.1 Call History Here you can view call history of VTO in Call History interface.

  • Page 27: Alarm Record

    4.2.2 Alarm Record You can search VTO alarm record on Alarm Record interface with storage up to 1024 items. See Figure 4- 10. Figure 4- 10 4.3 Status Statistics 4.3.1 VTH Status Here you can view connection status of VTH. Status Offline: VTO and VTH are not connected, you cannot call, monitor, talk or etc.

  • Page 28: Basic Function Introduction

    5 Basic Function Introduction 5.1 Call Function 5.1.1 Call Manager Center Check Register to the MGT Center, you can touch the Call button to call manager center. Now VTO can only call MGT Center, cannot call VTH. Manager center’s time can be set on management platform or villa VTO’s web-end.

  • Page 29: Call User

    5.1.2 Call User Press Call button under standby status, and the VTO will call user. User may monitor VTO from VTH. On VTH, press Unlock button to unlock door. When VTH picks up, you can start talk with the VTH. If no one answers the call, then the call will end automatically and device returns to standby status.
  • Page 30 Figure 5- 2 Note: Paramete with * are mandantory to be set. Step 4. In LAN Config interface, check Group Call, and click on OK. See Figure 5- 3. Step 5. After config is complete, enter Logout interface to reboot VTO. Figure 5- 3...
  • Page 31 Set Main VTH Step 1. On VTH screen, press System Settings>Project Settings, input password (default is 002236) to enter Project Settings interface. Step 2. Press Product Info, input Room No., Local IP and etc as in Figure 5- 4. Note: Room No.

  • Page 32: Monitor

    Set Extension Step 1. On VTH screen, press System Settings>Project Settings, input password (default is 002236) to enter Project Settings interface. Step 2. Press Product Info. Press Master, Master icon becomes Extention icon. Step 3. Set Room No. (i.e. 1101-1), input IP Address, Subnet Mask and Gateway. Step 4.

  • Page 33: Compensation Of Light

    5.4 Compensation of Light In dark environment or at night, the VTO adopts auto photoreception technology which achieves light compensation in connecting status. 5.5 Vandal Proof There is one channel of vandal proof which will generate alarm sound and report to the manager center once VTO is forced to leave the wall.

  • Page 34: Faq

    6 FAQ Q: I pressed Call button, and the indicator turned on, but the VTO did not start a call? A: Please check your operation process. Q: How to end a call when I am calling? A: Please press button on VTO and there will be sound from the device. Q: The device could not boot up and there was no sound or light.

  • Page 35: Appendix 1 Technical Specifications

    Appendix 1 Technical Specifications Model ECL-VIP200 Main Process Embedded micro controller System Embedded Linux os Video Compression H.264 Standard Video Input/Sensor 1.3 Megapixel CMOS HD camera Night Vision Support Input Omnidirectional Mic Audio Output Built-in speaker Talk Support bidirectional talk...

  • Page 36: Appendix 2 Technical Specifications

    ≤30m 30<L ≤100m 20AWG Optional Not optional 18AWG Optional Optional 17AWG Optional Optional Note: Before plugging extension line to power, make sure its positive and negative end are correctly wired. Appendix 2.3 Embedded Box VTO Model Embedded Box ECL-VIP200 Case 126*115...

  • Page 37: Appendix 3 Vtms

    Appendix 3 VTMS Check Installation Environment This manual makes Window XP as example to introduce how to modify IP of PC inorder to connect VTMS and monitoirng system. Step 1. Select Start>Control Panel>Network Connection>Local Area Connection, right click on Local Area Connection icem, select Properties, see Appendix 3- 1. Appendix 3- 1 Step 2.
  • Page 38 Step 3. After complete modification, select Start>Run, input “cmd”, click on OK. Enter command interface, input “ping” + IP of the VTO. If it obtains communication data, then VTO and the PC are connected. See Appendix 3- 3. Appendix 3- 3 Enable VTMS The following mainly introduces how to config VTMS for you to login VTO and use VTMS.

  • Page 39: Appendix 4 Vtms Client

    Appendix 4 VTMS Client This following mainly introducts how to config VTMS Client. Appendix 4.1 Config Network Address Step 1. Install VTMS Client on PC. Step 2. Double click on , in pop-up box input username, password, IP address, port and etc. Click on Login. See Appendix 4- 1. Note: Default username and password is admin and 123, respectively.
  • Page 40 Step 4. Double click on VTS parameter collumn, sustem pops up Edit device box, input PC’s IP address. See Appendix 4- 3. Appendix 4- 3 Step 5. Click on Save. Input project password (default project password is 123). Step 6. Re-login VTMS, you can see VTMS is successfully configured as in Appendix 4- Appendix 4- 4...

  • Page 41: Appendix 4.2 Create Organization

    Appendix 4.2 Create Organization First you must build up environmrnt and set VTMS server, please refer to Appendix 3. This chapter takes example of a residence with 10 buildings and 2 units. Create Residence Organization Step 1. In VTMS main interface, select Organization, click on Batch Add. System pops up Batch Add box, see Appendix 4- 5.
  • Page 42 Add VTO Step 1. In VTMS main interface, select Device MGR, click on Add, system pops up Batch Add box. Step 2. Fill in info according to your actual condition, and click on Save. See Appendix 4- Appendix 4- 7...
  • Page 43 Add VTH Step 1. In VTMS main interface, select Device MGR, click on Batch Add, system pops up Batch Add box. Step 2. Fill in info according to your actual condition, and click on Save. See Appendix 4- Appendix 4- 8 Note: This manual is for reference only.
