Summary of Contents for Mec NANO HIPPO 50WH

  • Page 1 NANO HIPPO 50WH Air Purifier FIMACO SDN. BHD.

  • Page 3: Table Of Contents

    Contents Contents Important Safeguards Introduction First installation Using method Maintenance and cleaning Replacing air filter Trouble shooting...

  • Page 4: Important Safeguards

    Important Safeguards Please read this user manual carefully before using the appliance and save it for future reference. Danger Do not let water or any other liquid or flammable detergent enter the unit to avoid electric shock and / or a fire hazard. Do not clean the appliance with water or any other liquid or (flammable) detergent to avoid electric shock and/ or a fire hazard.
  • Page 5 Do not place anything on top of the appliance and do not sit on the appliance. Do not place the appliance directly below an air conditioner to prevent condensation from dripping onto the appliance. Make sure all filters are properly installed before you switch on the appliance.

  • Page 6: Introduction

    Introduction Congratulations on your purchase and welcome to MEC ! With this new Clean Air System you breathe cleaner air. For the best results, place the Clean Air System in a room where you spend most of your time, e.g.
  • Page 7 Stage 5: Plasma generator makes use of the ionized plasma to form the plasma field, where can produces streamer discharge and partial ionization. During the gas ionization, it will produce large amount of oxygen, OH, active factor and radicals. Harmful substances in the gas will be decomposed and oxidized during the ionization discharge and streamer procedure.
  • Page 8 Introduction...
  • Page 9 Picture 1 (For NANO HIPPO 50WH) ( For NANO HIPPO 50WH) Picture 2...
  • Page 10 General description 1. Control panel 2. Air quality sensor outlet 3. Air quality sensorpanel 4. Air quality sensor inlet 5. Remote control receiver 6. Air quality display 7. Four-side air inlet 8. Controller 9. Handle 10. Plasma generator 11. Air outlet 12.

  • Page 11: First Installation

    General description Placing the filters The appliance comes with all filters fitted inside, but you have to remove the packaging of the filters before you can use the appliance. Remove all filters, unpack them and place them back into the appliance. Note: Make sure you insert the filters in correct position.
  • Page 12 Plastic Hook Picture 3 Picture 4 Picture 5 Plastic Plastic catalysis activated carbon filter Hook Hook ilter Picture 6 Picture 8 Picture 7 Plastic Hook Picture 9 Picture 10 Picture 11...

  • Page 13: Using Method

    Take out / put into the power plug Press the arrowhead direction to open the power plug department. Picture 12 Open the power plug compartment to get the power cord from it. Picture 13 Loose the band to use it. Keep the power cord in the compartment while long time disuse.
  • Page 14 Controlpanel operation method A---ON / OFF Put the plug in the wall socket, then you hear a beep, the appliance is in ready mode, the power indicator lights red, press “POWER” to start the appliance, then the power indicator lights blue. When the appliance is on, press the “POWER”, the appliance is back to the ready mode again.
  • Page 15 Remote control operation methods I---POWER POWER Same as “A” in control panel K---HIGH-SPEED Same as “B” in control panel POWER J---MID-SPEED Same as “C” in control panel Q---LOW-SPEED Same as “D” in control panel L---SILENT MODE Same as “E” in control panel P---AIR QUALITY Same as “F”...
  • Page 16 Operating mode When the appliance is plugged in, you can hear a beep , the appliance is operating normally. Memory store when power off, when the power is back, it will continue to work. 1.Normal operating mode： When the appliance is on, it will enter into the normal operating mode by default.
  • Page 17 According to the air quality, the motor will adjust the fan speed automatically: when the air quality is bad, the appliance is high speed; fair, mid speed; good, low speed. In night mode, you can find the operating status as follows: The PLASMA is on by default, press “PLASMA”...
  • Page 18 Under the standby, press AIR-QUALITY+MID-SPEED buttons. After the buzzer sounds twice, the air quality sensor sensitivity has been set to sensitive level. Confirm it after five times flashing of the corresponding composite key indicator or confirm it immediately after pressing the power button to turn on the product.

  • Page 19: Maintenance And Cleaning

    Maintenance Maintenance regularly clean the inside and outside of the body to prevent the dust from collecting on the inside and outside. Wipe away dust with a soft dry cloth from the body of the appliance. Clean the air inlet and the air outlet with a soft dry cloth. Never immerse the appliance in water or any other liquid.
  • Page 20 Air quality sensor Clean the air quality sensor every 2 months for optimal functioning of the appliance. Clean it more frequently if you use the appliance in a dusty environment. Note: When the humidity level in the room is every high, it is possible that condensation develops on the air quality sensor.

  • Page 21: Replacing Air Filter

    Filter replacement This air cleaner is equipped with the Smart Lock feature to ensure that the filters are in optimal condition when the appliance is operating. When one of the filters is almost full and has to be cleaned or replaced, the appropriate filter replacement light starts to flash.
  • Page 22 Reset the appliance POWER HIGH-SPEED MID-SPEED LOW-SPEED After the filter replacement, put the plug into power socket and there will be the on music. The appliance reaches standby status. SILENT AUTO AIR-QUALITY Press the button “ ” on the controller for 2 seconds or the reset RESET PLASMA button at the air quality sensor inlet for 2 seconds to make the reset.

  • Page 23: Trouble Shooting

    TROUBLE SHOOTING This chapter summarizes the most common problems you could encounter with the appliance. If you are unable to solve the problem with the information below, contact the Consumer Care Center in your country. Problem Possible solution You ignored the filter replacement alerts.
  • Page 24 Problem Possible solution 1. The pre-filter is dirty. Clean the pre-filter (see chapter maintenance and cleaning). The airflow that comes out of 2. You haven’t removed all packing the air outlet is significantly material from the filters. Make sure weaker than before that you have removed all packing material.
  • Page 25 Problem Possible solution You can change the air quality sensor I need cleaner air because I sensitivity (see chapter “using the have an allergy. appliance”) to make the air cleaner clean the air even better. You haven’t removed all packing material from the filters.
  • Page 27 8-2, Wisma Fiamma, No. 20, Jalan 7A/62A， Website www.mec.com.my...
