Summary of Contents for Poolspa Klio rectangular 160x70
- Page 1 Bathtub with the SX hydro-massage system Klio rectangular: 160 x 170 x Klio asymmetric: 140 x 150 x 100 163 x 103 Klio symmetric: 133 x 133 140 x 140 Instruction manual Warranty...
-
Page 2: Table Of Contents
TABLE OF CONTENTS MANUAL OVERVIEW ....................... 3 WATER MASSAGE ......................3 AIR MASSAGE (Pearl bath) ....................3 DISINFECTION ......................... 3 TRANSPORT ........................3 PREPARING THE ROOM ....................3 PRELIMINARY BATHTUB PLACEMENT ................. 3 CLEANING THE BATHTUB ....................4 CONNECTING TO THE SEWAGE SYSTEM ..............4 10. -
Page 3: Manual Overview
1. MANUAL OVERVIEW Follow the instruction manual for hydro-massage systems closely to ensure the best use of massage capabilities and to avoid problems or failure caused by inappropriate operation. We recommend hiring a qualifi ed ROCA POOL-SPA installer to install the bathtub. The system to which the bathtub is connected must be equipped with a residual current device. -
Page 4: Cleaning The Bathtub
The installation set includes:: - plastic legs, - M10 threaded pins, - M10 nuts, - plastic top handles, - handle plugs. Screw the legs and locking nuts onto the pins, and then screw the pins inside profi le sockets (see the illustration). Turn the bathtub, place it on the legs, set the height, and then level it in its future place of installation 8. -
Page 5: Installing Panel Enclosure
- lock bathtub legs with locking nuts - enclose the bathtub, ensuring access of fresh air to bathtub devices (area equal to 2 standard ventilation grates) and space for removing drain tap when it needs to be cleaned - seal the gap between the bathtub and surrounding walls using masking strip or sanitary silicone. 1 / 3 2 / 3 2 / 3... -
Page 6: Systems And Their Control Panels
15. SYSTEMS AND THEIR CONTROL PANELS 15.1. SX1 SYSTEM - water system • Water massage - 4 back nozzles - 2 foot nozzles - 4 side nozzles - control of water massage intensity through aeration - water level sensor that prevents the pump from running dry. •... -
Page 7: Sx2 System - Water And Air Massage
15.2. SX2 SYSTEM - water and air system • Water massage - 4 fi xed back nozzles, - 2 fi xed foot nozzles (excluding Klio Asymmetric 140 x 80), - 4 fl at side nozzles with the option to direct water stream, - independent control of back/side/foot massage intensity through aeration, - water level sensor that prevents the pump from running dry, - drain for removing water from the water massage system after bath. -
Page 8: Place Of Faucet Installation
Chromotherapy: The LED light with color changer is switched on automatically after activating the hydro-massage system. Touch the symbol once to deactivate the multi-color light. Touch the symbol again to activate or deactivate this feature. The light switches off automatically after 30 minutes. NOTE! After approximately 3 min of the whirlpool system operation (water massage or the light function active), the control panel will be automatically locked. -
Page 9: Bathtub Maintenance
Klio asymmetric 163 x 103 17. BATHTUB MAINTENANCE Clean the bathtub using delicate liquids only (not containing acetone, abrasives or caustic substances). Thanks to the structure and low adhesion of acryl it is easy to keep the bathtub clean. Disinfect the bathtub at least once a month and remember to activate bathtub massage systems every time. Rinse the bathtub thoroughly after disinfection. -
Page 10: Important Information
19. IMPORTANT INFORMATION Remember that it is easy to slip on the wet surface of most bathtubs, especially when using soaps, shampoos, bath oils, etc. The designers, installers and users alike should always keep this in mind. The bathtub may be positioned and repaired only by qualifi ed installers with appropriate offi cially recognized certifi cates that confi... - Page 11 KLIO 140x80 bathtub KLIO 150x100 bathtub...
- Page 12 KLIO 163x103 bathtub KLIO 133x133 bathtub...
- Page 13 KLIO 140x140 bathtub...
-
Page 14: Warranty Terms
WARRANTY TERMS 1. Roca Pool-Spa Sp. z o.o. grants a 60-month warranty for the acrylic surface and a 24-month warranty for other parts of the product. 2. This warranty is valid only if the bathtub is installed by an installer with electrical qualifi cations. 3. -
Page 15: Warranty Card
WARRANTY CARD MODEL, ACCESSORIES SERIAL NUMBER PRODUCTION DATE QUALITY CONTROL ROCA POOL-SPA QUALITY CONTROL ..../..../....RATED POWER CONSUMPTION REQUIRED CURRENT PROTECTION THERMAL PROTECTION CLASS DEALER: (date of sale, dealer's signature and stamp) ELECTRICIAN'S/INSTALLER'S STAMP... - Page 16 ROCA POOL-SPA Sp. z o.o. ul. Wyczółkowskiego 20, 44-109 Gliwice, Poland phone: +48 32 339 41 00 www.roca.pl, e-mail: infolinia@roca.pl ROCA POOL-SPA is committed to constant improvement of its products and reserves the right to introduce changes to the specifi cation and colors without prior notifi cation. However, ROCA POOL-SPA makes every effort to ensure that the specifi...
