User Manual
Repeater/Range Extender
Quick
Installation
Guide
Coredy E750
Dual Band Mini WiFi Range Extender/AP/Router
Two easy setup options:
ONE:
Setup by Web Browser
TWO:
Setup by WPS (WiFi Protected)
LED Indicator
POWER
WPS
LAN
WAN/LAN
WLAN Signal LED Indicator
Mode
AP/Router
Repeater
NOTE:
The Quick Installation Guide is ONLY for Repeater Mode's setting. For more
information about other modes' setting, please refer to User Manaul.
Option 1
Note: Please be sure your E750 is restored to factory default settings
before getting start. Put your Target Network's Router in an open space
area, and keep the E750 next to your Target Network's Router during the
installation process.
Power On
1
Switch the E750 to
your Target Network's Router with the Power Switch ON. Wait the Bar 1 of WiFi
LED Indicator flashes.
V3.02
ON:
The Device is power on.
OFF:
The Device is power off.
Flashing:
WPS signal of another device is expected.
ON:
The Ethernet port is connected.
OFF:
The Ethernet port is disconnected.
Flashing:
1
2
ON
ON
ON
ON
ON
ON
OFF
ON
Flashing
OFF
,
Setup by Web Browser
Repeater
WPS connection is established or
Data is Transferring.
Description
3
WiFi signal is strong
ON
Strong reception signal from Router
ON
Signal stength: 50% to 100%
Good reception signal from Router
OFF
Signal stength: 25% to 50%
Weak reception signal from Router
OFF
Signal stength is below 25%
OFF
Disconnect
Mode. Plug the E750 into a power socket
-01-
Coredy E750 WiFi Range
Extender Installation Guide
on Youtube:
https://goo.gl/d5hWKb
WiFi
WPS
WAN/LAN
LAN
POWER
WPS
next to
Advertisement
Table of Contents
Related Manuals for Coredy E750
Summary of Contents for Coredy E750
- Page 1 Note: Please be sure your E750 is restored to factory default settings before getting start. Put your Target Network’s Router in an open space area, and keep the E750 next to your Target Network’s Router during the installation process. Power On Repeater Mode.
-
Page 2: Lan Port
CHOOSE A NETWORK... Your Target Network 14:cf:92:f:c5:10 WPA2 -95 Method 2. Connect by Laptop Click the WiFi icon on the system tray, select and connect the E750 default wireless network name: Coredy E750_xxG. Make sure the computer’s Ethernet connection is disable status. - Page 3 Submit to login. Note: you could not login the setup page, please restore the E750 to factory default settings (turn to page 7 for Physical Reset), or refer to Troubleshooting Q2 on manual for more solution. http://ap.setup/ Username...
- Page 4 Plug the E750 into an electrical socket about halfway between your wireless Router and the WiFi dead zone. Try to place your E750 in an open space area where it can receive strong signal from your target router. The E750 would automatically reconnect your Router in approximately one minute after relocated.
- Page 5 LED Indicator flashes. WiFi Wi-Fi WAN/LAN POWER WAN/LAN Set the E750 into WPS Pairing Mode Press the button on your E750 about 2 seconds till the WPS LED Indicator flashes. WiFi WAN/LAN Wi-Fi WAN/LAN POWER POWER WPS LED Indicator would flash...
- Page 6 Plug the E750 into an electrical socket about halfway between your wireless Router and the WiFi dead zone. Try to place your E750 in an open space area where it can receive strong signal from your target router. The E750 would automatically reconnect your Router in approximately one minute after relocated.
- Page 7 Weak signal strength may be caused by obstruction from walls or objects. If you are receiving low signal strength, try to place your E750 in an open space area, keep it away from obstructed locations like under or behind a Desk.
- Page 8 Perhaps the E750 is too far away from your Target Router or other causes which is not in the proper location. Replace E750 as closer to your target Router as possible and make sure that it could receive strong wireless signal form the Target Router.
