Page 2
* Do not internal disjointing and adjustment voluntarily because the indicator is composed of electron component and P.C.B circuit to sharp at the static electricity . DACELL is not liability for mistake to use that change a property voluntarily, change design, adjustment voluntarily, user carelessness cause defect.
Page 3
DACELL CO., LTD http://www.dacell.com TEL:+82-43-2602242, FAX : +82-43-2602245 2. Connection and wiring 1) AC input : 1 and 2 ports, 110/ 220V (50Hz/60Hz). Separate power cable from sensor cable. Refer to 5-1). 2) HOLD : 3 and 4 ports. short state : current display value holding open state : current value display(normal operation mode) 3) ANALOG OUTPUT : 4 →...
Page 4
DACELL CO., LTD http://www.dacell.com TEL:+82-43-2602242, FAX : +82-43-2602245 6 and 7 port : excitation voltage (power for sensor) * EXC+ : +2.5Vdc * EXC- : -2.5Vdc * Load current : Max 120mA ( EXC = 5Vdc ) Max 60mA ( EXC = 10Vdc ) 8 and 9 port : signal connection ports(output of sensor).
Page 5
DACELL CO., LTD http://www.dacell.com TEL:+82-43-2602242, FAX : +82-43-2602245 3. DISPLAY and KEY operation 1)DISPLAY : 4½ Digit LED * Key operation start : press to MODE key. Key operation exit : press to ENT key. * Display : setting mode and operation mode.
Page 6
DACELL CO., LTD http://www.dacell.com TEL:+82-43-2602242, FAX : +82-43-2602245 3) KEY operation result Description Mode 1. HI→LO→FS→DP→CAL→FS+CAL→FS+ DP→DP+CAL select 2. All FND of selected mode will blink. 3. Press key : 10000→1000→100→10→1 Position Selected digit position will blink select 4. DP(decimal point mode) : decimal point position movement key.
Page 7
DACELL CO., LTD http://www.dacell.com TEL:+82-43-2602242, FAX : +82-43-2602245 5) AUTO ZERO mode Initialize sensor and indicator. Execute this mode at unlock mode. Execution process (display : operation mode) (1) Sensor : no load. (2) Voluntary data display. (3) Press key and key at the same time.
Page 8
DACELL CO., LTD http://www.dacell.com TEL:+82-43-2602242, FAX : +82-43-2602245 4. Operating flow chart --Mount indicator to panel and make connection. (Check AC Install and connection POWER 110/220V) -- Press + key(data protection unlock) Unlock mode -- Set data(high, low, F.S, DP, CAL),refer to 6...
DACELL CO., LTD http://www.dacell.com TEL:+82-43-2602242, FAX : +82-43-2602245 3) Setting of DIP switch After connection, dip s/w must be set. voltage 1 mV/V 1Hz10Hz100Hz mV/V mV/V mV/Vcurrent 1~4 S/W :One of 1,2,3 or 4 turn on according to sensor output value (mV/V) 5 S/W : Turn on or off according to analog output 6,7,8 S/W : Analog input filter frequency 6,7,8 turn off : 4 ㎑...
Page 10
DACELL CO., LTD http://www.dacell.com TEL:+82-43-2602242, FAX : +82-43-2602245 3) PROGRAM (SOFTWARE) OPTION (1) Press mode key, DP+CAL LED turn on at the same time. mode display description peak hold on : display maximum measurement data 0 x x x peak hold off : display present measurement data..
DACELL CO., LTD http://www.dacell.com TEL:+82-43-2602242, FAX : +82-43-2602245 8. TECHNICAL DATA item data allowed time temperature ―40 ~ 80℃ operating temperature 0 ℃ ~ 50 ℃ power of sensor 5Vdc or 10Vdc input signal type 1 ~ 3mV/V max. load current 10Vdc/60 ㎃, 5Vdc/120 ㎃...
Page 12
DACELL CO., LTD http://www.dacell.com TEL:+82-43-2602242, FAX : +82-43-2602245 10. Trouble shooting and correction problem cause correction * Defective Sensor * Check sensor state and output * AC noise in power line * Check power line and connection Display * Defective connection...
