HL5403, HL5404
32
See Warranty on page 10 for important information about commercial use of this product.
Operating Instructions and Parts List
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
Oil Lubricated Compressors
Description
This oil-lubricated compressor is
STOP!
designed for do-it-yourselfers with a
variety of home and automotive jobs.
These compressors power spray guns,
impact wrenches and other tools.
Compressed air from this unit will
contain moisture. Install a water filter or
air dryer if application requires dry air.

Safety Guidelines

This manual contains information that is
very important to know and understand.
This information is provided for SAFETY
and to PREVENT EQUIPMENT PROBLEMS. Record the Model No., Serial No. and
date of purchase located on the base
To help recognize this information,
below the pump in the space below.
observe the following symbols.
Danger Model No. ____________________
indicates
Serial No. ____________________
an imminently hazardous situation
which, if not avoided, WILL result in
Date of purchase _________________
death or serious injury.
Warning
Retain these numbers for future
indicates
reference.
a potentially hazardous situation
which, if not avoided, COULD result in
Have the serial number, model number,
death or serious injury.
and parts list (with missing parts circled
Caution
before calling.)
indicates
a potentially hazardous situation
General Safety
which, if not avoided, MAY result in
minor or moderate injury.
Information
Notice
indicates
important information, that if not
unit if damaged during shipping,
followed, MAY cause damage to
handling or use. Damage may result in
equipment.
bursting and cause injury or property
Unpacking
damage.
After unpacking the unit, inspect
carefully for any damage that may have
unattended. Leaving compressor in
occurred during transit. Make sure to
AUTO position may allow it to turn on
tighten fittings, bolts, etc., before
inadvertently. To prevent this and
putting unit into service. In case of
possible damage from power surge,
turn to OFF position after each use.
questions, damaged or missing parts,
please call 1-800-543-6400 for customer
assistance.
REMINDER: Keep your dated proof of purchase for warranty purposes! Attach it to this manual or file it for safekeeping.
© 2008
HL5403, HL5404
DO NOT RETURN THE
PRODUCT TO THE
RETAILER! Breathable Air Warning
This compressor/pump is not
equipped and should not be used
"as is" to supply breathing quality
air. For any application of air for
human consumption, the air
compressor/pump will need to be
fitted with suitable in-line safety
and alarm equipment. This
additional equipment is necessary
to properly filter and purify the air
to meet minimal specifications for
Grade D breathing as described in
Compressed Gas Association
Commodity Specification G 7.1 -
1966, OSHA 29 CFR 1910. 134,
and/or Canadian Standards
Associations (CSA).
DISCLAIMER OF WARRANTIES
In the event the compressor is used
for the purpose of breathing air
application and proper in-line
safety and alarm equipment is not
simultaneously used, existing
warranties shall be voided, and the
manufacturer disclaims any liability
whatsoever for any loss, personal
injury or damage.
CALIFORNIA PROPOSITION 65
Do not
operate
You can create dust when
you cut, sand, drill or grind
materials such as wood,
paint, metal, concrete, cement, or other
masonry. This dust often contains
Do not
chemicals known to cause cancer, birth
run
defects, or other reproductive harm.
Wear protective gear.
or its power cord contains lead, a
chemical known to the State of
California to cause cancer and birth
defects or other reproductive harm.
Wash hands after handling.
IN626400AV 6/08
