Summary of Contents for Wisecomm cw3510tx
- Page 1 USER’S INSTRUCTIONS 2.4 GHz WIRELESS COLOR CAMERA SYSTEM PORTABLE WIRELESS COLOR CAMERA & RECEIVER MODEL CW3510 WISECOMM LOGO...
- Page 2 IMPORTANT SAFETY PRECAUTIONS ■ To prevent fire or shock hazard, do not expose this product to rain or moisture. ■ To avoid electrical shock, do not open the case of this product. ■ Operate this product using only the power supply included. ■...
- Page 3 However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ■...
- Page 4 WIRLESS CAMERA -------CW3510TX 1.CHARGE LED (RED) 10.IR LED Indicates that the built-in Help work at night and dark battery is being charged. Place. 2.POWER JACK (DC 5V) 11.Universal mounting bracket Plug the 5V adapter Make the camera to work at (supplied).
- Page 5 WIRELESS RECEIVER---CW3510RX 1.ANTENNA 7.CH 3 Receives the audio and video This light is lit when CH3 has been selected. signals. 8.CH 4 2. POWER INDICATOR This light is lit when CH4 has been selected. The red LED is lit when 9.
- Page 6 INSTALLATION WIRELESS CAMERA---CW3510TX POWER INDICATOR AUTO SWITCHING INDICATOR Change the picture above from RX to TX(camera) 1. Connect the supplied adaptor (DC 5V 700mA) to the DC IN jack on the rear of the camera and plug it into AC power outlet. The red LED (power indicator light) on the back of the camera will be lit and the battery (inside the camera) will be charging (green LED).
- Page 7 WIRELESS RECEIVER---CW3510RX POWER ON /O FF ANTENNA DC IN AV OU T Connect the supplied AC adaptor (DC 8V 200 mA to the DC IN jack of the receiver and plug it into AC outlet. Connect the supplied A/V cable to the jack. Plug the yellow colored RCA to the VIDEO IN on the monitor/TV and the white colored RCA to the AUDIO IN respectively.
- Page 8 OPERATION ■ MANUAL MODE Select the same channel with the SEL button on receiver as the channel of camera. ■ AUTOMATIC MODE Press SEL button on the receiver after CH 4 indicator is lit. It will be in the sequencing mode. Please check the explanation.
- Page 9 TO POWER VI DEO OUTLET AUDIO VI DEO AUDIO INPUT A/V CABLE ■ OPERATION WITH TV/MONITOR AND VCR 1.Connect the provided A/V (audio/video) cable to the A/V jack on the receiver and to the jacks on your VCR’s A/V jacks. Be sure to connect the white connector of the A/V cable to the AUDIO IN jack and the yellow connector of the A/V cable to the VIDEO IN jack on the VCR, if the VCR has only a single jack for...
- Page 10 REDRAW THE PICTURE RECEIVER SIDE PANEL TO POWER VIDEO OUTLET AUDIO VIDEO AUDIO INPUT COAXIAL CABLE A/V CABLE...
- Page 11 TROUBLE SHOOTING 1.CHARGE LED (RED) Indicates that the built-in battery is being charged. If the system does not function properly, check the following points before contacting the service center. Cause and remedies 2.POWER JACK (DC 5V) Problems Receiver Camera Plug the 5V adapter No power(no AC adaptor was not AC adaptor was not...
- Page 12 SPECIFICATIONS WIRELESS RECEIVER Receiving frequency 4CH 2,400 to 2,483MHz Demodulation Antenna 50 ohm SMA Receiving sensitivity -85dbm Video output 1VP-P @75 ohm Audio output 1VP-P @600 ohm Power supply DC 8V Current consumption 180 mA Lithium battery 500 mAH Dimensions ??????? Weight ????????
- Page 13 Number of pixels NTSC, 510 x 492 Resolution 380 TV lines Scanning system 525 lines, 60 fields/sec Sync system Internal sync Minimum illumination 1.5 Lux/F1.5 & IR LED on: 0 Lux S/N ratio More than 45db Gamma characteristics 0.45 Electronic shutter speed 1/60 to 1,500 sec Lens 78º...
- Page 14 1-A/V (audio/video) cable 1-User’s instruction 1-Warranty registration card 1-Camera bracket 1-Receiver bracket LIMITED 1YEAR WARRANTY This warranty gives the original purchaser specific legal rights and may also have other rights, which vary from state to state. If our products do not function because of any defect in material or workmanship, we will repair free of charges for 1 year on parts and labor from the date of original purchase.
- Page 15 Please include a check for $20.00 to cover the cost of return postage and handling. If the system is returned within the warranty period, please include a proof of purchase. If the system is out of warranty, you will receive an estimate of the repair cost for your approval before repair work will be started.
