- Page 1 TS1001 Touch Screen Arming Station User Manual P/N MAUSER-TS1001 • REV 02 • ISS 04MAR15...
- Page 2 Copyright © 2015 UTC Fire & Security Australia Pty Ltd. All rights reserved. Trademarks The TS1001 Touch Screen Arming Station and patents name and logo are trademarks of UTC Fire & Security Australia Pty Ltd. Other trade names used in this document may...
-
Page 3: Table Of Contents
Front LED indications 5 Using the RAS 6 Logging in 6 Selecting a menu option 7 Entering text 8 Arming and disarming 10 Selecting areas by searching 12 Logging in to classic mode 14 TS1001 Touch Screen Arming Station User Manual... -
Page 4: Important Information
While every precaution has been taken during the preparation of this manual to ensure the accuracy of its contents, UTCFS assumes no responsibility for errors or omissions. TS1001 Touch Screen Arming Station User Manual... -
Page 5: Advisory Messages
Related manuals This manual describes how to use the TS1001 Touch Screen Arming Station. Refer also to the TS1001 Touch Screen Arming Station Installation Manual for installation details. -
Page 6: Care And Cleaning Instructions
WARNING: Do not use alcohol near an open flame or other source of ignition. TS1001 Touch Screen Arming Station User Manual... -
Page 7: Product Overview
Product overview Refer to Figure 1 below for details of external features of the TS1001 Touch Screen Arming Station, and to Figure 2 on page 3 for details displayed on the touch screen (screen image varies). Figure 1: TS1001 Touch Screen Arming Station overview... -
Page 8: User Interface Details
“alarm” codes, and the ability to open a door may be limited to users with “door” codes. When idle (not in programming mode and in the absence of alarms or faults) the touch screen resembles Figure 2 on page 3. TS1001 Touch Screen Arming Station User Manual... - Page 9 (depending on alarm group programming). • The Disarm button (item 2) followed by an alarm code is used to disarm assigned areas, or to select and disarm areas (depending on alarm group programming). TS1001 Touch Screen Arming Station User Manual...
- Page 10 Automation quick control does not require user authentication via PIN. When you see one of the button images later in this manual, it means you begin at the Home screen and then press the button. TS1001 Touch Screen Arming Station User Manual...
-
Page 11: Front Led Indications
• The LED flashes slowly when a fault is detected, or when an alarm occurs, in disarm. • The LED flashes quickly when a fault is detected, or when an alarm occurs, in arm. TS1001 Touch Screen Arming Station User Manual... -
Page 12: Using The Ras
• “Logging in to classic mode” on page 14 Logging in From the Home screen, press the Menu button or the * Menu key (Figure 1 on page 1, item 2). Figure 3: Login screen TS1001 Touch Screen Arming Station User Manual... -
Page 13: Selecting A Menu Option
To access the Install menu, use the Up and Down arrows to display 19 – Install Menu. Touch the 19 – Install Menu list item to open the Install menu (Figure 5 on page 8). TS1001 Touch Screen Arming Station User Manual... -
Page 14: Entering Text
Note: The TS1001 Touch Screen RAS displays lists of menu items (as in Figure 4 on page 7) instead of displaying one item at a time. The list depends on the user’s alarm group and the RAS’s alarm group (stored in the Challenger panel) which results in a small delay. - Page 15 (3) Edit mode (black) Uppercase and lowercase keys are selected automatically. Use the Shift button to override the automated selection of case. The Clear button deletes any pre-existing characters and exits the option. TS1001 Touch Screen Arming Station User Manual...
-
Page 16: Arming And Disarming
(Figure 7 below). Figure 7: Arming login screen Press the buttons that correspond to your alarm code, and then press the Enter button (or the Arm button or the Enter # key). TS1001 Touch Screen Arming Station User Manual... - Page 17 Press either a displayed area or All to arm one area or all areas. In the example in Figure 8 above, if you press area 4, then it’s removed from the display and the next unarmed area is shown in the list. TS1001 Touch Screen Arming Station User Manual...
-
Page 18: Selecting Areas By Searching
For example to arm an area named “Main-office”: 1. On the area selection screen (Figure 8 on page 11) click the Search button to open the search screen. TS1001 Touch Screen Arming Station User Manual... - Page 19 Figure 11: Area search screen (edit mode) 3. Press one or more characters (for example, M) and then press the Search button to see the area names starting with the characters entered (Figure 12 on page 14). TS1001 Touch Screen Arming Station User Manual...
-
Page 20: Logging In To Classic Mode
5. Alternatively, press the Search button again to define a new search. Logging in to classic mode From the Home screen, press the Classic button to display the login screen (Figure 13 below). Figure 13: Classic mode home screen TS1001 Touch Screen Arming Station User Manual... - Page 21 Figure 14: Classic mode login screen Press the buttons that correspond to your alarm code, and then press the # button (or press the Enter # key). Figure 15: Classic mode menu screen TS1001 Touch Screen Arming Station User Manual...
- Page 22 Press the buttons that correspond to the menu option number, and then press the # button (or press the Enter # key) to access the menu. Some options have additional menus, such as the Install menu (Figure 16 on page 17). TS1001 Touch Screen Arming Station User Manual...
- Page 23 Figure 16: Classic mode Install menu screen Refer to the Challenger manuals for details about operating a Challenger system and entering text via a conventional LCD keypad. TS1001 Touch Screen Arming Station User Manual...
- Page 24 TS1001 Touch Screen Arming Station User Manual...
