Summary of Contents for Wagan 2513
- Page 1 Item no. 2513 5A Solar Charge Controller User’s Manual ©2010 Wagan Corporation. All Rights Reserved Wagan and wagan.com are trademarks used by Wagan Corp. Revised June 2010...
- Page 2 Thank you for purchasing the 5A Solar Charge Controller by Wagan Tech. With normal care and proper treatment it will provide years of reliable service. Please read all operating instructions carefully before use. Important Safety Instructions • Working in the vicinity of a lead- acid battery is dangerous.
- Page 3 contacts your eyes, skin or clothing. If this happens, wash immediately with soap and water. Then get medical attention. • Avoid touching your eyes while working with a battery. Acid particles (corrosion) may get into your eyes. If this occurs, flush eyes immediately with running cold water for at least 10 minutes.
- Page 4 may cause an explosion. • Always operate the charge controller in an open, well-ventilated area. • Never smoke or allow sparks or flames in the vicinity of the battery. Batteries generate explosive gases. • Neutralize any acid spills thoroughly with baking soda before attempting to clean Front Panel Indicators Charging LED:...
- Page 5 Specifications Max Solar Panel Array Power Input Voltage 16.5V~22V Max Input Voltage Charging current Voltage for Gel Battery 14.2V Voltage for Flooded Battery 14.6V Over current protection Operating Temperature 0°~40° C Storage Temperature -10°~70° C Dimensions (mm) 68 × 58 × 20 Weight 46.5g...
- Page 6 Connection Diagram SOLAR Charging Full SOLAR PANEL Flooded BATTERY Red Wire Black Wire BATTERY When battery voltage reaches to about 14.6V (14.2 for Gel) the controller stops charging. When the battery voltage drops to about 13.5V the controller begins to charge again.
