- Page 1 Nietzsche Enterprise CO,LTD. WZB-02485 WZB-02485 ZigBee WIRELESS TRANSMITTER User Manual...
-
Page 2: Safety Notice
Content Introduction 01-02 Specification Applications Network Overview Hardware Overview WZB-02485 ZigBee Transmitter WZB-01USBC ZigBee-Dongle Getting start 04-07 Install USB dongle driver 04-05 WZB-02485 Address Settings Make Network Link & LED indication Accessories User Manual Safety notice Please read and follow the instructions before use of this product. -
Page 3: Specification
Introduction 01 Introduction WZB-02485 ZigBee transceiver is the transceiver that build in with new generation of TI CC2530 high performance and low power consumption SoC chip.User can easily build up the IEEE 802.15.4 compatible Mesh type smart ZigBee wireless network. - Page 4 Introduction 02 Applications ● Industrial and Domestic Applications ● Service-based monitoring, security and awareness systems ● Home Area Networks (HAN) ● Home/ Building automation Network Overview ZigBee Network Topology Models Network topology Star Mesh ZigBee coordinator(ZC) Full Funcation Device(FFD,Router) Reduced Function Device(RFD) Zigbee wireless network Application RS-485 TheHost PC...
-
Page 5: Hardware Overview
Hardware Overview 03 WZB-02485 ZigBee Transmitter Address switch Link button LED indicator The DIP SW to set the The tack switch To indicate ZigBee sensor ID for ZigBee to control Reset transmitting status network /join/ Remove to the ZigBee network... -
Page 6: Getting Start
Getting start 04 Install USB dongle driver To install the PL-2303 USB Driver from the CD enclosed. - Page 7 Content, choose Hardware, click Device Manager, then set COM port. (Prolific USB-to-Serial Comm Port) as below. COM port setting items Setting Baud rate 9600 bps Data bits Parity None Stop bits Flow control None Wire connection of WZB-02485 RS 485...
-
Page 8: Wzb-02485 Address Settings
Getting start 06 WZB-02485 Address Settings Set from the DIP Switch, ON =” 0 “ OFF =”1 “ Bit 123 were reserved as” 1”, Bit 45678 to set the address. ID # COM Port setting Bit 45678 00001 00010 00011... - Page 9 Getting start 07 Copyright Copyright 2011 Nietzsche Enterprise Co., Ltd. All rights reserved. Nietzsche Enterprise reserves the right to make changes and improvements to its product without notice. Technical Support E-Mail : service@nhr.com.tw Website: www.nhr.com.tw...
