- Page 1 Installation Manual SDS-1001-101-x Serial Digital Splitter 1 In/4 Out Document # 540306 7300 Industry Drive, North Little Rock, AR 72117 Phone: 501-955-2929 Fax: 501-955-2988 www.audiointl.com...
- Page 2 Audio International, Inc. Neither this document nor the data contained herein shall be reproduced, used, or disclosed to anyone without the written authorization of Audio International, Inc. Document #540306, Rev IR, 04/2005...
-
Page 3: Table Of Contents
Audio International, Inc. SDS-1001-101-x Installation Manual Table of Contents Section Description Page General Information ....... . -
Page 4: General Information
General Information Introduction This manual contains information for the proper application, installation, and operation of the Audio International, Inc. (AI), Serial Digital A/V Splitter, Model # SDS-1001-101-x. The “-x” in the model number designates the type of connector utilized in installation; “-1” = Positronic and “-2”... -
Page 5: Application
Outputs may interface to sink equipment such as DES-100x deserializers, monitors, switches and EL panels equipped with deserializer circuitry, etc. Outputs may also be routed to crosspoint switch modules or other SDS-1001-101-x modules. Typical System Block Diagram Installation Prior to Installation The Serial Digital A/V Splitter is a simple module to install. -
Page 6: Unpacking And Inspection
Inspect the unit for shipping damage. 3.2.2 If damage has occurred during shipping, a claim should be filed with Audio International WITHIN 24 hours and a Return Request Authorization Number shall be obtained from AI by contacting the Repair Department at 501.801.0640. -
Page 7: Wiring Requirements
Audio International, Inc. SDS-1001-101-x Installation Manual Wiring Requirements 3.4.1 Introduction The installing agency shall supply and fabricate all external cables and connectors. The length and routing of external cables should be carefully studied and planned before attempting installation of the equipment. Allow adequate space for installation of cable and connectors. -
Page 8: Physical Characteristics
(6) inches between the lines. Physical Characteristics 3.5.1 Locate the SDS-1001-101-x away from heat sources, magnetic fields, direct sunlight, and areas with excessive dust and/or moisture. The unit shall NOT be mounted to the skin of the aircraft. -
Page 9: Electrical Characteristics
J1. Chassis ground is referenced to pin three (3) of connector J1. Chassis ground connection shall be bonded to airframe ground with less than 0.010 Ω resistance using less than 50 Ω impedance cable. 3.6.3 SDS-1001-101-x Mating Connectors J1 Connector Description RD25F10JVL0 or equivalent SDS-1001-101-1 (Positronic Industries) -
Page 10: Pinout Assignments And Descriptions
3.8.2 Repeat the above tests using all Serial Digital A/V Splitter units in the aircraft. 3.8.3 Note that the SDS-1001-101-x has an LED to indicate whether the unit has operational power. Document #540306, Rev IR, 04/2005... -
Page 11: Troubleshooting
Recheck all pin outs for application accuracy. Instructions for Continued Airworthiness No periodic scheduled maintenance or calibration is required for continued airworthiness of the SDS-1001-101-x. If the unit fails to perform to specifications, it must be removed and serviced by a qualified service facility. Specifications... -
Page 12: Reference Drawings
Audio International, Inc. SDS-1001-101-x Installation Manual Reference Drawings The following diagrams show the unit dimensions, mounting locations, and connector locations for the SDS-1001-101-x. Document #540306, Rev IR, 04/2005 Page 11 of 12... - Page 13 Audio International, Inc. SDS-1001-101-x Installation Manual Document #540306, Rev IR, 04/2005 Page 12 of 12...
