HOW TO USE
使用說明書
Are the doors leveled? (
• Use the adjustable legs to keep the door level.
Internal cleaning
• Clean with a wet soft cloth.
After the operation
• It may take more than 4 ~ 24 hours to fully cool.
• You may hear a loud operation sound but it is not a malfunction.
When using auto ice making (
• It may take 24 hours to make the ice for the first time.
■ 箱門的兩側是否調整至水平狀態 ?（
‧ 請使用調整腳將箱門至水平狀態。
■ 清理冰箱內
‧ 用沾濕的軟布擦拭乾淨。
■ 開始運轉後
‧ 當冰箱內尚未充分冷卻時，有時需要花上4 ~ 24小時。
‧ 有巨大的運轉聲，並非異常現象。
■ 使用自動製冰機時（
‧ 初次使用時可能需要24小時才能製作冰塊。
Please read this operation manual carefully and ensure
you use the appliance correctly. In particular, be sure
to read the "Safety Suggestions" section of this
operation manual before use.
Please keep this operation manual along with your guarantee card.
Six doors
型號
Model
Notice Before Use
Pg. 11)
Pg. 24)
24頁）
REFRIGERATOR-FREEZER
六門形式
R-SF42XMH
R-SF42XMS
使用前須知
11頁）
請詳閱本使用說明書，以達正確使用。
使用前，請務必詳閱「安全上之注意事項」。
請妥善保管本使用說明書與保証書。
HITACHI
日立無霜全自動式
多門電冰箱
Advertisement
Table of Contents
Related Manuals for Hitachi R-SF42XMH
Summary of Contents for Hitachi R-SF42XMH
-
Page 1: How To Use
HOW TO USE HITACHI 使用說明書 REFRIGERATOR-FREEZER 日立無霜全自動式 多門電冰箱 六門形式 Six doors R-SF42XMH 型號 Model R-SF42XMS 使用前須知 Notice Before Use Are the doors leveled? ( Pg. 11) • Use the adjustable legs to keep the door level. Internal cleaning • Clean with a wet soft cloth. - Page 2 NAME AND FUNCTION OF EACH PART 各部分的名稱與功能 Pg. 16/16 頁) Fresh Food MINUS-ZERO Cooling compartment The effect of cool air and the cool panel on the back 冷藏室 surface keeps every corner of the refrigerator cooled. -0°C低溫冷藏 冷風和背面冷卻面板的功能使冰箱 的所有角落保持冷卻。 Dew condensation may occur on the surface of the cool panel when the door frequently opens.
-
