Page 1: Table Of Contents
2.4 G z WIRELESS SURVEILLANCE SYSTEM USER'S MANUAL 1. INTRODUCTION 2. PACKAGE CONTENTS 3. CONTROLS 4. SYSTEM INSTALLATION 5. OPERATION 6. TROUBLE SHOOTING...
Page 2: Important Safety Instructions
GENERAL SAFETY SUMMARY CAUTION RISK OF ELECTRONIC SHOCK DO NOT OPEN CAUTION: DO NOT REMOVE THE COVER FOR REDUCING THE RISK OF ELECTRIC SHOCK. NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. WARNING To prevent fire or shock hazard , do not expose the unit to rain or moisture. IMPORTANT SAFETY INSTRUCTIONS All the safety and operating instructions should be read before the product is operated.
Page 3: Introduction
1. INTRODUCTION Overview The Wireless Surveillance System with CMOS/CCD Images and four channels available is just as your baby sitter, home/camp guard and company monitoring. Easy to install, unequalled quality and reliability make you have delighted and secure life. Features High Resolution Color CMOS/CCD Camera( Optional ) High Performance Audio/Video Receiver Built-In Microphone for Audio Monitoring...
Page 4 Wireless Camera-CMOS Model Specification Characteristic Scanning System 2:1 Interlace 2:1 Interlace NTSC Image Sensor 1/3" CMOS Image Sensor 510 (H) X 492 (V) 628 (H) X 582 (V) Efficiency Pixels Horizontal Scan Frequency 15750 Hz 15625 Hz Vertical Scan Frequency 50 Hz 60 Hz Synchronize...
Page 5: Package Contents
2. PACKAGE CONTENTS One unit of Wireless Camera The Wireless Camera emits Audio and Video signals over 2.4G z radio frequency carrier. One unit of Receiver The Receiver receives 2.4G z wireless Audio and Video signals from the Wireless Camera. One unit of Wall Mounting Bracket The wall mounting bracket is used to bolster up the Wireless Camera on the wall.
Page 6: Controls
3. CONTROLS Wireless Camera Front 1. Lens 2. Microphone Bottom 3. Channel Rubber 4. Tripod Screw Nut ( Ceiling Mounting Screw Nut) 5. Power Cable 6. Power Indication LED 7. Wall Mounting Slide 8. Ceiling Mounting Screw Nut Receiver Front & Side 1.
Page 7: System Installation
4. SYSTEM INSTALLATION W i r e l e s s C a m e r a Fasten the Mounting Bracket on the wall or ceiling (must under the roof). Slide the Wireless Camera into the Wall Mounting Bracket. Connect Wireless Camera with the attached adaptor;...
Page 8: Operation
Re c e i v e r Phone plug to 2RCA/SCART connecting with TV Connect Receiver by phone plug to TV with RCA Cable. Plug Receiver into the power outlet with attached adaptor. Phone plug to 2RCA connecting with PC Connect Receiver by phone plug to PCI PCI Capture Card Capture Card of PC with RCA Cable.
Page 9: Trouble Shooting
6. TROUBLE SHOOTING Please read this user's manual carefully before using the Wireless Surveillance System. If you still have difficulties to use the Wireless Surveillance System consult the following syndrome, which will guide you to solve most common problems. Interference in the Image and Sound Move your Wireless Camera or Receiver slowly to find a best reception position.
Page 10: Wireless Camera
How to adjust the Channel Selector of Wireless Camera Use a tool to open the channel rubber. Switch inside selector by the tool to adjust the channel you want to set. C H1 C H2 C H3 C H4 Warning : Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user authority to operate the equipment.
Page 11 Version 1.2...
