TCO iF281 User Manual

28 inch wide screen tft lcd monitor

Advertisement

Quick Links

28 inch Wide Screen
TFT LCD Monitor
iF281
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iF281 and is the answer not in the manual?

Questions and answers

Summary of Contents for TCO iF281

  • Page 1 28 inch Wide Screen TFT LCD Monitor iF281 USER’S MANUAL...
  • Page 2 User’s Manual Before operating the monitor, please read this manual thoroughly. This manual should be retained for future reference. FCC Class B Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 3 All TCO labelled products are verified and certified by TCO Development, an independent third party labelling organization. For over 20 years, TCO Development has been at the forefront of moving the design of IT equipment in a more user-friendly direction. Our criteria are developed in collaboration with an international group of researchers, experts, users and manufacturers.
  • Page 4: Table Of Contents

    User’s Manual TABLE OF CONTENTS SAFETY NOTICE ................... 5 PRECAUTIONS ..................5 SPECIAL NOTES ON LCD MONITORS ........... 6 BEFORE YOU OPERATE THE MONITOR ............ 7 FEATURES ....................7 CHECKING THE CONTENTS OF THE PACKAGE ........7 POWER...................... 8 MAKING CONNECTIONS ................. 8 ADJUSTING THE VIEWING ANGLE ............
  • Page 5: Safety Notice

    User’s Manual SAFETY NOTICE 1. The changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 2. Shielded interface cables and AC power cord, if any, must be used in order to comply with the emission limits.
  • Page 6: Special Notes On Lcd Monitors

    User’s Manual SPECIAL NOTES ON LCD MONITORS The following symptoms are normal with LCD monitor and do not indicate a problem. Due to the nature of the fluorescent light, the screen may flicker during initial use. Turn • off the Power Switch and then turn it on again to make sure the flicker disappears. You may find slightly uneven brightness on the screen depending on the desktop pattern •...
  • Page 7: Before You Operate The Monitor

    User’s Manual BEFORE YOU OPERATE THE MONITOR FEATURES 28” Wide screen TFT Color LCD Monitor • Crisp, Clear Display for Windows • Recommended Resolutions: 1920 X 1200 @60Hz • ® EPA ENERGY STAR • Ergonomic Design • Space Saving, Compact Case Design •...
  • Page 8: Power

    User’s Manual POWER POWER SOURCE 1. Make sure that the power cord is the correct type required in your area. 2. This LCD monitor has an Internal universal power supply that allows operation in either 100/120V AC or 220/240V AC voltage area (No user adjustment is required.) 3.
  • Page 9 User’s Manual CONNECTING TO A A/V DEVICE: Connect A/V devices via the D-sub and Audio Line in connectors at the back of the monitor. 1. Connect one end of the D-Sub cable to the back of the monitor and connect the other end to the D-sub to YPbPr adapter cable.
  • Page 10: Adjusting The Viewing Angle

    User’s Manual ADJUSTING THE VIEWING ANGLE 1. For optimal viewing it is recommended to look at the full face of the monitor, then adjust the monitor’s angle to your own preference. 2. Hold the stand so you do not topple the monitor when you change the monitor’s angle. 3.
  • Page 11: Operating Instructions

    User’s Manual OPERATING INSTRUCTIONS GENERAL INSTRUCTIONS Press the power button to turn the monitor on or off. The other control buttons are located on the right side of the monitor (See Figure 5). By changing these settings, the picture can be adjusted to your personal preferences.
  • Page 12: Control Panel Button Functions

    User’s Manual CONTROL PANEL BUTTON FUNCTIONS Power Button: • Press this button to switch ON/OFF of monitor’s power. Power Indicator: • Blue — Power On mode. Orange — Power Saving mode. MENU / ENTER: • Activates the OSD menu or confirms adjustments to settings. Exit OSD volume display when in volume OSD status.
  • Page 13: How To Adjust A Setting

    User’s Manual HOW TO ADJUST A SETTING FUNCTION DESCRIPTION Select the 「Brightness」 option on the 「Main Menu」 . Enter the option by Brightness pressing the 「Menu」 button again, and adjust the level. Select the「Contrast」option on the「Main Menu」. Enter the option by Contrast pressing the 「Menu」...
  • Page 14 User’s Manual Select the「Phase Adjustment」option to reduce the horizontal flicker of Phase Adjustment characters on the screen. Enter the option and adjust the level. Exit Exit the OSD menu function. FUNCTION DESCRIPTION 5500K/6500K/ Move the cursor to one of the preset options and select it. 9300K Move the cursor to the User option and select it 1.
  • Page 15 User’s Manual Select the 「Language」 option to change the language of the OSD. Language Enter the option and select a language. (Reference only, the OSD Language is depended on selected model) Exit Exit the OSD menu function. FUNCTION DESCRIPTION Select the「DDC/CI」option to switch the function On or Off. (optional) DDC/CI Select the「Volume」option to set the volume level from 0 to 100.
  • Page 16: Plug And Play

    User’s Manual PLUG AND PLAY Plug & Play DDC2B Feature This monitor is equipped with VESA DDC2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities. The DDC2B is a bidirectional data channel based on the I²C protocol.
  • Page 17: Technical Support (Faq)

    User’s Manual TECHNICAL SUPPORT (FAQ) Q & A FOR GENERAL PROBLEMS PROBLEM & QUESTION POSSIBLE SOLUTION *Check if the Power Switch is in the ON position Power LED is not on *Power Cord should be connected *Check if the PC system is Plug & Play compatible *Check if the Video Card is Plug &...
  • Page 18: Error Message & Possible Solutions

    User’s Manual ERROR MESSAGE & POSSIBLE SOLUTIONS CABLE NOT CONNECTED : 1. Check that the signal-cable is properly connected, If the connector is loose, tighten the connector’s screws. 2. Check the signal-cable’s connection pins for damage. INPUT NOT SUPPORT : Your computer has been set to unsuitable display mode, set the computer to display mode given in the following table.
  • Page 19: Appendix

    User’s Manual APPENDIX SPECIFICATIONS Driving system TFT Color LCD LCD Panel Size 28” (27.5" viewable) Pixel pitch 0.309mm(H) x 0.309mm(V) H-Frequency 24KHz – 80KHz Video V-Frequency 56Hz– 75Hz Display Colors 16.7M Colors Hor. :593.28mm; Maximum Screen Size Ver. :370.8mm Max. Resolution WUXGA 1920 x 1200 @60Hz VESA DDC2B Plug &...
