PRODUCT MANUAL

Boste BK Series

(UDC102 Undersink Dispenser Model)

Table of Contents

Need help?

Do you have a question about the UDC102 and is the answer not in the manual?

Questions and answers

Summary of Contents for Boste UDC102

Page 1 PRODUCT MANUAL Boste BK Series (UDC102 Undersink Dispenser Model)
Page 2: Table Of Contents
Product Manual BK Series (UDC102 Models) Contents Introduction ..... . . Page 3 Specifications ..... . .
Page 3: Introduction
The Boste BK Series (UDC102 Model) is a range of undercounter water dispensers that are connected to the mains water supply and dispense water through a proprietary swan-neck faucet that is mounted on a worksurface.
Page 4: Specifications
Specifications COOLING SYSTEM High efficiency compression system with capillary control. Premium quality long life hermetic compressor. Compact internal condenser – fan assisted for greater efficiency. Environmentally friendly R134A refrigerant. 3.5 litre stainless steel chiller tank with level control containing stainless steel cold water direct chill coil. Stainless steel carbonator tank with independent level control fitted inside coil.
Page 5: Main Components
Boste BK Series Main Components Top Panel Undersink Unit Side Panel BK5 Cold & Ambient BK9 Cold, Sparkling & Ambient Indication Panel 1no UDC102A Undercounter Unit 1no UDC102AS Undercounter Unit Front Panel Complete with: Complete with: 1no 2.0m Power Cordset 1no 2.0m Power Cordset...
Page 6: Installation Guide
Boste BK Series Installation Guide 1. Unpack both the undersink unit and the swan-neck faucet, checking the main components are present as per the lists above. Dispose of the packaging in a responsible manner. Please note regarding any Mains Installation parts.
Page 7 Boste BK Series 11. Connect faucet pipework as follows: Cold & Ambient Model: Cold, Sparkling & Ambient Model: Insulated Faucet Pipe Adaptors Adaptors Cross Fitting Y Fitting 5no Stem 2no Stem Elbow CO2 Regulator & Elbow Cylinder Fit Stem Elbows directly to water outlets on back of unit.
Page 8: Operation Guide
Boste BK Series Operation Guide Operation of these models is very simple. According to the individual model, ambient and cold or ambient, cold and sparkling water can be freely dispensed. During normal operation the only LED indicators are those on the the front panel of the Undercounter Unit Cold &...
Page 9: Maintenance Guide
Boste BK Series Maintenance Guide Minimal routine maintenance is required. Every 6 months maximum a sanitisation procedure is recommended as follows: 1. Turn off incoming mains water, briefly press cold/ambient (not sparkling) dispense button(s) to release internal water pressure from the machine and remove filter.
Page 10: Fault Diagnosis Guide
Boste BK Series Fault Diagnosis No Water Dispenses Problem/ Possible Cause Suggested Action Report No Water Dispenses From Ambient Water Supply turned off Check all Taps/valves/ filters on incoming Valve supply are fitted and are turned on. No Electricity/Power Supply Check power cord connected and live and machine is switched on.
Page 11 Boste BK Series No Water Dispenses continued No Water Dispenses continued From Ambient Button not being pressed Press button firmly or Cold Valve enough Faulty c o n t r o l s P C B – n o Replace PCB – Check for 24 VDC outputs if necessary.
Page 12 Boste BK Series Water Dispenses but not correct Temperature Problem/ Possible Cause Suggested Action Report Water Dispenses But Not Correct Temperature Ambient Water Low usage and / or fed Advise user replacing external causes and too warm from water supply pipe in solutions.
Page 13 Boste BK Series Water Leaks Problem/ Possible Cause Suggested Action Report Water Leaks Water lying on Overflowing Waste Container. Empty Waste Container and check drain pipe is not blocked. top edge of lower door panel and / or bottom of Cabinet.
Page 14 Boste BK Series Miscellaneous Problem/ Possible Cause Suggested Action Report Miscellaneous Bleeping Noise Empty Was te Con tai n e r. Che c k an d Waste Container full/Internal r e s e t Le ak De te c tor .
Page 15 Boste BK Series Miscellaneous continued Problem/ Possible Cause Suggested Action Report Slow but Continuous Water Dispense From Ambient Low incoming Water Consider re-plumbing to alternative supply or Cold Water pressure. if possible or boosting the inlet supply Valve pressure. From Sparkling Low/no CO Pressure.
Page 16: Diagrams & Parts Guide
Boste BK Series Diagrams & Parts Lists...
Page 22 Boste BK (UDC102)
Page 28 PRODUCT GUIDE BOSTE BK SERIES (UDC102) MODELS Technical Support Available 0700-1700 Monday to Friday Telephone (+0044) 01362 695 006 (+0044) 01362 656 920 Email aftersales@azureuk.co.uk Synergy House Fakenham Road Morton-On-The-Hill Norfolk NR9 5SP sales@azureuk.co.uk www.azureuk.co.uk...
