  • Page 2 Index English Version 2-10 pages Japanese Version 11-19 pages 1...
  • Page 3: Product Illustration

    English Version 1. Introduction 1.1 Product illustration 1.2 Package contents The package should contain the following items: The Multi-function Panel x 1(including 1 power connector, 1 card reader connector and 2 sensor wires) Serial ATA cable x 2 USB transfer cable x 1 (2 ports) USB cable ×1 (for directly linking to M/B) IEEE1394 transfer cable x 1 IEEE1394 cable×1 (for directly linking to M/B)
  • Page 4: Specification

    Specification: Device space 5.25” drive bay DC input +5V / +12V, USB bus power DC output 4V – 12V DC Temperature display range 0~90 ° C / 0~194 °F Fan speed monitoring range 1000~9900 RPM Fan header (3 pin) Wire of sensors 4 pin Power connector Card reader connector...
  • Page 5: Product Features

    2.Product Features 2.1 7 in 1 card reader: 2.1.1 Compatible cards: Compact Flash Type I Compact Flash Type II IBM Micro Drive Memory Stick、Memory Stick Duo、Memory Stick PRO、Memory Stick Duo PRO Smart Media Secure Digital Multi Media Card...
  • Page 6 2.2 Thermal controller module: 2.2.1 Thermal controller setup a. Fan RPM (brightness control) setting: Clockwise: increase the RPM (brightness). Counterclockwise: decrease the RPM (brightness). b. Overheat temperature degree setting: H : 65 °C / 149 °F M : 55 °C / 131 °F L : 45 °C / 113 °F c.
  • Page 7 d. Hardware temperature and fan speed alarm display switch:push “MODE” button to shift the display for the first set “T1 F1” and the second set “T2 F2” Note: Please press “Reset” button after setting for completing the setting step. 2.2.2 LCD function description 1.
  • Page 8: Installation

    3.Installation 3.1 The PCB illustration 3.2 The PCB connectivity illustration Sensor SATA Card reader FAN Power IEEE1394 USB...
  • Page 9 3.3 The installation Steps 1. Insert the drive into 5.25” drive bay 2. Two connectivity options for USB & IEEE1394: 2-1 Directly linking to M/B 2-1-1 Attach the USB cable & IEEE1394 cables into USB & IEEE1394 pin header of the M/B. 2-1-2 Attach the USB &...
  • Page 10: Driver Installation

    4.Driver installation 4.1 Minimum System Requirements: a. Windows Pentium class PC with USB support Windows 98SE, 2000, ME, XP CD-ROM drive USB 2.0 port required from Hi-Speed transfer b. Macintosh Macintosh computer with USB support Mac OS 8.6+ CD-ROM drive USB 2.0 port required from Hi-Speed transfer 4.2 Installation for Windows 98/SE/2000 Insert the driver CD into the CD-ROM drive.
  • Page 11: Uninstall Driver

    4.3 Installation for Windows ME/XP. This card reader is a driver-free device for Windows ME/XP. You don't have to install any driver and can plug into USB port directly. Windows ME/XP will detect and install all the associated files automatically. 4.4 Uninstall Driver Please run the setup process again to uninstall the driver.
  • Page 12: Japanese Version

    Japanese Version 1. 製品紹介 1.1 製品図 1.2 パッケージリスト 製品梱包には、次の付属品が含まれています。 多機能パネル x 1(パワーコネクタ x 1 カードリーダ x 1 温度センサーx 2) 2. シリアル ATA ケーブル x 2 3. USB ケーブル x 2 (2 ポート) USB ケーブル x 1(直接 M/B へ接続) 1394 ケーブル x 1 1394 ケーブル...
  • Page 13 仕様: 取り付けの場所 5インチベイ用 DC 入力 +5V / +12V、USB バス電源 DC 出力 4V - 12V DC 温度表示範囲 0~90 °C / 0~194 °F ファン回転速度の範囲 1000~9900 RPM 3 ピンファンコネクタ 温度センサー パワーコネクタ 4 ピン カードリーダコネクタ 4 ピン 明るさとファン速度調整ノブ メモリカードタイプ CF I/II、SD 、MMC、MS、SM、MD カードリーダのインターフェイス USB 2.0 Windows98SE /2000/Me /XP、...
  • Page 14 2.機能 2.1 7ln1 カードリーダモジュール: 2.1.1 対応メモリカードード: コンパクトフラッシュタイプ I コンパクトフラッシュタイプ II IBM マイクロドライブ メモリスティック/メモリスティック Duo/メモリスティック PRO/メモリスティック Duo PRO スマートメディア SD カード マルチメディアカード(MMC) コンパクトフラッシュタイプ I/II マイクロドライブ メモリスティック PRO メモリスティック スマートメディア 裏返しにして挿入。 マルチメディアカード 裏返しにして挿入。...
  • Page 15 2.2 サーマルコントローラモジュール 2.2.1 サーマルコントローラのセットアップ a. ファン RPM (輝度コントロール)設定: 右回り: RPM (輝度)を増加。 左回り: RPM (輝度)を減少。 b. オーバーヒート温度設定: H : 65 C / 149 M : 55 C / 131 L : 45 C / 113 c. アラーム温度設定とアラームファン低速設定: パネルの表示 に従って、必要とする位置に切り替えてください。 c.1 温度単位用の JP1: オープン: ショート: c.2 アラームファン速度調整設定用の...
  • Page 16 2.2.2 LCD の機能 1. センサーの表示可能温度範囲: 0~90 °C / 0~194 °F 2. ファン回転速度の検出: 1000~9900 RPM 3. オーバーヒートアラーム: 温度が設定値より高いとき、LCD の数字が点滅し、ブザ ーが鳴ります。設定温度以下に下がると 30 秒後にブザ ーは鳴り止みますが、LCD 数字は原因が完全に除去さ れるまで点滅を続けます。 4. ファンの低速 / ファンエラーアラーム: ファン速度が設定値より低くなった場合、LCD の数字が 点滅を開始し、ブザーが鳴ります。設定値以上に回転 数が戻ると LCD の点滅とブザーは自動的に停止します。 原因を未解決のままにしておくと、ビープ音は 30 秒後に 自動的に停止します。しかし、LCD の数字は原因が完 全に除去されるまでは点滅を続けます。 5.
  • Page 17 3.インストール: 3.1 基板の説明 3.2 PCBの接続 センサー シリアルATA カードリーダファンパワー1394 USB...
  • Page 18 3.3 インストールの手順: 慎重にドライブを 5 インチベイへ挿入してからねじ止めます。 二つの USB&1394 用の接続ケーブルはオプション。 2-1 直接 M/B へ接続 2-1-1 USB&1394 ケーブルをマザーボードの USB&1394 ピンヘッ ダーへ差し込みます。 2-1-2 USB&1394 ケーブルを PCB のピンヘッダーへ差し込みま す。 注:“UP”ラベルを確認し、ケーブルの差し間違いに注意。 2-2 PC の背面にあるバックパネルから接続: USB&1394 ケーブルを付属のL型ブラケットソケット経由で PC 背面のポートへ接続します。 ファン拡張ワイヤを、監視及びコントロールが必要な PCB 及び ファンへ差し込みます。 4 ピンのカードリーダケーブルをマザーボードの USB ソケットへ 差し込みます。...
  • Page 19 4.ドライバーのインストール 4.1 最低のシステム要件: a. Windows Pentium クラスの PC(USB をサポート) Windows 98SE、2000、Me、XP CD-ROM ドライブ USB 2.0 ポート(高速転送に必要) b. Macintosh Macintosh コンピュータ(USB をサポート) Mac OS 8.6+ CD-ROM ドライブ USB 2.0 ポート(高速転送に必要) 4.2 Windows 98/SE/2000 の場合のインストール ドライバーCD を CD-ROM ドライブに挿入します。 CD-ROM ドライブアイコンをクリックします。 “インストールウィザード” のステップに従って、 “USB カ ードリーダドライバー”...
  • Page 20 4.3 Windows Me/XP のインストール このカードリーダは、Windows Me/XP の場合ドライバーは必要あり ません。ドライバーをインストールしなくても、USB ポートに直接差 し込むことができます。 Windows Me/XP は関連するすべてのファイルを自動的にインスト ールします。 4.4 ドライバーのアンインストール: セットアッププロセスをもう一度実行して、ドライバーをアンイ ンストールしてください。 画面の指示に従って、プロセスを完了します。 コンピュータを再起動するように求められます。“すぐにコン ピュータを再起動する” を選択して PC を再起動すると、ア ンインストールは完了です。 4.5 デバイスの削除: Windows 98SE ユーザーの場合 フラッシュカードやリーダを取り除く前に、データ喪失を防 ぐために、リーダの“アクセス LED”が点滅を停止するま でお待ちください。 Windows Me/2000/XP ユーザーの場合 システムトレイのアイコン をダブルクリックしてくだ さい。ダイアログボックスが表示されます。 データロスを防ぐため、Generic USB 記憶装置をダブルクリック...
