Creator CR-V1013 User Manual

Hd color video camera
Hide thumbs

Advertisement

Quick Links

Download this manual
HD Color Video Camera
User Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the CR-V1013 and is the answer not in the manual?

Questions and answers

Summary of Contents for Creator CR-V1013

  • Page 1 HD Color Video Camera User Manual...
  • Page 2 Preface: Thanks for using our HD color video conference camera. This manual introduces the function installation and operation of the HD camera. Prior to installation and usage, please read the manual thoroughly. Warning This product can be only used in specified range in order to avoid any damage or danger.

  • Page 3: Table Of Contents

    【Contents】 Notes ………………………………………… ……………….. Accessories ……………………………………………………. Fast Installation………………………………………………… Camera Highlights……………………………………………… Camera specifications…………………………………………. Camera interface explanation………………………………… Remote Controller explanation………………………………… Usage of IR remote controller ………………………………… VISCA RS-232 pin specs………………………………………. Series COM Control ……………………………………………. Menu Setting……………………………………………………... Maintenance and Trouble Shooting……………………………. ２...
  • Page 4 Notes Electric Safety Installation and operation must accord with electric safety standard Caution to transport Avoid stress, vibration and soakage in transport, storage and installation. Polarity of power supply The power supply of the product is +12V, the max electrical current is 2.5A .polarity of the power supply drawing.

  • Page 5: Fast Installation

    Supplied Accessories When you unpack, check that all the supplied accessories are included: Camera …………………………1 Power adaptor …………………1 Power cable…………………….1 RS232 cable……………………1 Remote controller………………1 User manual ……………………1 Double-side glue shim ………..4 Fast Installation 1. Please check the connection before turn on. 2.
  • Page 6 3. The Rotary Switch Setting The video format setting selections Switch Setting 1080P60 1080P50 1080I60 1080I50 720P60 720P50 1080P30 1080P25 -------- -------- -------- -------- -------- -------- -------- Display as the video format set by the menu Note: Please restart the camera after shift the video format 4.

  • Page 7: Camera Highlights

    6. Restore default setting: enter into the OSD menu by press the menu key of remote controller, select 【Restore Default】, moving the left/right key to press 【Yes】 ，then confirm by 【HOME】key . 7. Camera Standby: Press the 【Standby】 key on the remoter, camera pan tilt will rotate to the down limit, and then rotate to the right limit to be standby.

  • Page 8: Camera Interface Explanation

    Camera Interface Explanation 1 - Camera lens 2 - Camera base 3 - Working status indicator light (red) 4 - Bottom dial Switch 5 - Tripod screw hole 6 - Installation Orientation Hole 7 - Rotary Switch: video format optional 8 - RS232 controller serial interface (input) 9 - RS232 controller serial interface (output) 10 - CVBS interface (optional)

  • Page 9: Remote Controller Explanation

    Remote Controller: Definition of IR controller 0、Standby key After press the standby key, the camera will step into standby mode. Press again, the camera will open again. (Note: Standby mode power consumption is about half of the normal mode) 1、Number key Setting or Running presets 2、* key Key combination use...
  • Page 10 9、Menu setting Open or close the OSD menu 10、Zoom Control key zoom＋：lens near zoom－：lens far 11、Controlling camera address selection 【*】+【＃】+【F1】 ：the 1st camera address 【*】+【＃】+【F2】 ：the 2nd camera address 【*】+【＃】+【F3】 ：the 3rd camera address 【*】+【＃】+【F4】 ：the 4th camera address IR Remote Control When the camera is working, users can control the pan/tilt/zoom, setting and taking preset positions via remote controller.
  • Page 11 2. Zoom Operation ZOOM OUT: press “ZOOM “key ZOOM IN: press “ZOOM ” key Press and hold the key, the camera will keep zooming in or zooming out and stops as soon as the key is released. 3、Focus Control Focus (far)： Press”focus+” key (only work in manual focus mode) Focus (near)：...
  • Page 12 1、 Preset setting : To set a preset position, the users should press the “SET PRESET” key first and then press the number key 0-9 to set a relative preset, 10 preset positions in total are available. 2、Preset clearing : to clear a preset position, the user can press the “CLEAR PRESET” key first and then press the number key 0-9 to clear the relative preset;...
  • Page 13 RS-232C Interface (Pin Specs) Camera Windows DB-9 1.DTR 1.CD 2.DSR 2.RXD 3.TXD1 3.TXD 4.GND 4.DTR 5.RXD1 5.GND 6.RS485-A 6.DSR 7.IR OUT 7.RTS 8.RS485-B 8.CTS 9.RI Camera Mini DIN 1.DTR 1.DTR 2.DSR 2.DSR 3.TXD 3.TXD Function 4.GND 4.GND 5.RXD 5.RXD 6.RS485-A 6.GND TXD1 7.IR OUT...
  • Page 14 VISCA OUT Function COM Control In default working mode, the camera is able to be control via RS232C/RS485 interface (VISCA IN). The parameters of the RS232C/RS485 COM as following: Baud Rate ：2400/4800/9600/115200 Bit/S Start bit： 1bit; Data bit: 8bit; Stop bit: 1bit;...
  • Page 15 VISCA Protocol Pat1 . Camera Return Command Ack/Completion Message Command Packet Note z0 41 FF Returned when the command is accepted. Completion z0 51 FF Returned when the command has been executed. z = Camera Address + 8 Error Messages Command Packet Note Returned when the command format is different or when a...
  • Page 16 Reset 8x 01 04 03 00 FF 8x 01 04 03 02 FF Manual Control of R Gain CAM_RGain Down 8x 01 04 03 03 FF Direct 8x 01 04 43 00 00 0p 0q FF pq: R Gain Reset 8x 01 04 04 00 FF 8x 01 04 04 02 FF Manual Control of B Gain...
  • Page 17 8x 01 04 66 03 FF P: 0~7 Video format 0:1080P60 1:1080P50 2:1080i60 VideoSystem Set 8x 01 06 35 00 0p FF 3:1080i50 4:720P60 5:720P50 6:1080P30 7:1080P25 CAM_IDWrite 8x 01 04 22 0p 0q 0r 0s FF pqrs: Camera ID (=0000 to FFFF) SYS_Menu 8x 01 06 06 03 FF Turn off the menu...
  • Page 18 Part3 Command Checking Command Command packet Return packet Note y0 50 02 FF CAM_PowerInq 8x 09 04 00 FF y0 50 03 FF Off(Standby) CAM_ZoomPosInq 8x 09 04 47 FF y0 50 0p 0q 0r 0s FF pqrs: Zoom Position y0 50 02 FF Auto Focus CAM_FocusModeInq...
  • Page 19 Command Command packet Return packet Note P: 0~7 Video format 0:1080P60 1:1080P50 2:1080i60 VideoSystemInq 8x 09 06 23 FF y0 50 0p FF 3:1080i50 4:720P60 5:720P50 6:1080P30 7:1080P25 y0 50 02 FF IR_Receive 8x 09 06 08 FF y0 50 03 FF y0 07 7D 01 04 00 FF Power ON/OFF y0 07 7D 01 04 07 FF...
  • Page 20 Function Byte1 Byte2 Byte3 Byte4 Byte5 Byte6 Byte7 Query Tilt Position 0xFF Address 0x00 0x53 0x00 0x00 Value High Value Low Query Tilt Position Response 0xFF Address 0x00 0x5B Byte Byte Query Zoom Position 0xFF Address 0x00 0x55 0x00 0x00 Query Zoom Position Value High Value Low...

  • Page 21: Menu Setting

    Menu Setting Main Menu In normal image condition, press “MENU” key to display the menu, using scroll arrow to point at or highlight the selected items. MAIN ＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝ Language Setting （SYSTEM OPTION） （CAMERA OPTION） （PT OPTION） （V. FORMAT） （RESET） （HELP） VGA-OUT EXIT／ＭＥＮＵ...
  • Page 22 SYSTEM SET ＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝ PROTOCOL VISCA ADDR B. RATE 9600 RＳ４８５ ＡＲＭ. VER ＦＰＧＡ .VER CAM. VER 010404 MODEL BACK／ＭＥＮＵ Protocol: reset state: VISCA Protocol types: VISCA/Pelco-P/Pelco-D Protocol Address: reset state: 01 VISCA=1~7 Pelco-P/Pelco-D = 1~63 Baud Rate: reset state: 9600 2400/4800/9600/115200 RS485: reset state: off (if you want to use it, turn it on)
  • Page 23 3.1 EXPOSURE Move the scroll arrow to EXPOSURE, enter【HOME】 key to the setting page. As shown below EXPOSURE ＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝ ＝ EXP. MODE Auto SHUTTER IRIS GAIN BRIGHT EV. MODE LEVEL LEVEL Exposure Mode: reset state: Auto Available Settings: Auto, Manual, Shutter, Iris Shutter: reset state: Default Available Settings: 1/60, 1/90, 1/100, 1/125, 1/180, 1/250, 1/350, 1/500, 1/725, 1/1000, 1/1500,1/2000, 1/3000, 1/4000, 1/6000, 1/10000（only available in the mode of Manual and...
  • Page 24 COLOR ＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝ WB.MODE R.GAIN B.GAIN GAMMA SATURATION APERTURE FLICK NR LEVEL CONTRAST BACK／ＭＥＮＵ WB Mode: reset state: ATW Available Settings: Auto, Indoor, Outdoor, OnePush, ATW, Manual Red Gain: reset state: Default Available Settings:0 ~ 50（only available in the mode of Manual） Blue Gain: reset state: Default Available Settings: 0 ~ 50（only available in the mode of Manual）...
  • Page 25 4. PT OPTION Move the scroll arrow to PT OPTION, enter【HOME】 key to the setting page. As shown below PT SET ＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝ POWER. ACT SPEEDBYZ MOUNT. MODE IR M.SPEED IR Z.SPEED MIN.SPEED SCAN. SPEED BACK／ＭＥＮＵ Power on mode: reset state: Off 0/1 (After power on 12 seconds, if you don’t operate the camera, it will automatically go to the preset 0/1), Off SPEEDBYZ: the depth of field proportion: reset state: On...
  • Page 26 SYSTEM RESET: Protocol＝VISCA, Protocol Address＝1, Baud Rate＝9600, RS485＝Off Camera Reset: Except MOUNT. MODE and Language reset all camera parameters. PT Reset: POWER. ACT =Off, SPEEDBYZ =On, MOUNT. MODE =Up, IR M.SPEED =16, IR Z.SPEED =7, Serial port MIN.SPEED =0, SCAN. SPEED =10 ALL RESET: reset the above three parameters 6.

  • Page 27: Maintenance And Troubleshooting

    Maintenance and Troubleshooting Camera Maintains If camera is not used for long time, please turn off power switch, adapter switch and AC plug. Use soft cloth or tissue to clean the camera cover. Use soft cloth to clean the lens; Use neuter cleanser if bad smeared. No use strong or corrosive cleanser or corrosive cleanser avoiding scuffing.
