Summary of Contents for GS Engineering B.V. GS 0850
-
Page 1: Operating Instructions
Operating instructions GS 0850 Operating Instructions GS 0850 GS Engineering B.V. manufacturer hydraulic sweepers... - Page 2 Operating instructions GS 0850 Manufacturer: GS Engineering B.V. manufacturer hydraulic sweepers Tel: 0031 (0)486-415370 Fax: 0031 (0)486-411325 E-mail: info@gsengineering.nl Machine: GS 0850 GS Engineering B.V. manufacturer hydraulic sweepers...
-
Page 3: Table Of Contents
Operating instructions GS 0850 Table of Contents General User Liability Guarantees offered Documentation Technical data Safety Safety symbols Safety aspects Safety devices Emergencies Non-advisable use The Sweeping Process Recommended application Engine 3.2.1 Starting the engine 3.2.2 Turning off the engine 3.2.3 Refuelling... -
Page 4: General
GS 0850 1. General These operating instructions intend to set forth the correct use of the GS 0850. It addresses all aspects that are of relevance to the operation and daily maintenance of the GS Twister. It also pays attention to important aspects in respect of technical maintenance. -
Page 5: User
In these operating instructions, ‘user’ means: Anyone who is put into contact with the GS 0850 or parts thereof under normal operating conditions. The company or user has to see to it that each user is sufficiently qualified to handle this kind of machines and is able to comply with relevant provisions and safety aspects. -
Page 6: Guarantees Offered
The machine is used for other purposes than those it was designed and built for. 1.4 Documentation Each machine comes with: - the operating instructions for the GS 0850 - the operating instructions for the engine - warranty certificate GS Engineering B.V. -
Page 7: Technical Data
Operating instructions GS 0850 1.5 Technical Data Technical data of the GS 0850 Illustration 1 Sweeping width 85 cm Honda GCV160 4,2 kW (5,5hp) or Engine power Honda GX200 4,8 kW (6,5hp) Transmission Hydro-differential Speed 1 forward/backward Brush drive Hydro... -
Page 8: Safety
Operating instructions GS 0850 2. Safety The GS 0850 has been manufactured in accordance with regulations that are currently applicable. Nevertheless, this machine could cause dangers to man and machine if: it is not operated in accordance with the operating instructions. -
Page 9: Safety Symbols
Operating instructions GS 0850 2.1 Safety symbols The safety symbols on the machine must be kept complete and legible. Damaged and illegible safety symbols must be replaced by new ones. 1. Applied to the case of the machine, on the side, "hearing protection must be worn"... -
Page 10: Safety Aspects
Operating instructions GS 0850 2.2 Safety Aspects Safety aspects and pictograms included in these operating instructions as well as the safety symbols on the machine must always be observed by the operator. The procedures laid down in the operating manual must always be executed in the correct order. -
Page 11: Emergencies
2.5 Non-advisable use It is not allowed to sweep materials that are dangerous to human health in any way whatsoever. It is advised not to drive the GS 0850 without tools. Do not use the sweeper in closed spaces. GS Engineering B.V. -
Page 12: The Sweeping Process
Operating instructions GS 0850 3. The Sweeping Process 3.1 Recommended application The sweeper is mainly used for cleaning straight surfaces. The material to be swept will largely consist of leaves, rubbish, snow, sand, gravel or a combination hereof. When sweeping certain materials, (large) clouds of dust may be raised. -
Page 13: Engine
ATTENTION: GS 0850 is available with two different engines: Honda GX 200 Honda GCV 160 Check the engine's oil level each time before using the GS 0850. Type of engine oil: SAE 5W40 Capacity of the Honda GX 200 engine: 0.5 litre Capacity of the Honda GCV 160 engine: 0.45 litre... - Page 14 Operating instructions GS 0850 The next steps are necessary to start the Honda GX 200: 1. Check if the brush drive is turned off. Place the sweeper switch in the neutral position. 2. Put the accelerator lever in its top position indicated by the hare.
- Page 15 Operating instructions GS 0850 4. Take hold of the starter handle (see Illustration 3) and slowly pull until you feel resistance. Firmly pull the cord to get through the compression, avoid backfire and start the engine. Turn off the choke when the engine is running.
- Page 16 Operating instructions GS 0850 2. Push the adjusting handle towards the CHOKE position. Indicated by the choke symbol ( ) on the adjusting handle. (see Illustration 2) ATTENTION: Do not use the choke when the engine is hot or when the air temperature is high.
-
Page 17: Turning Off The Engine
Operating instructions GS 0850 4. Push the adjusting handle on the push bar towards the "turtle" (slow position) or the "hare" (fast position). (see Illustration 5) Illustration 5 3.2.2. Turning off the engine The following action must be performed to turn off the Honda GX 200 engine: The engine can easily be turned off by turning the switch on the engine to OFF. -
Page 18: Refuelling
Operating instructions GS 0850 Follow the procedure below to turn off the Honda GVC 160 engine: Push the adjusting handle on the push bar until it reaches the STOP sign. (see Illustration 2) Illustration 2 Do not stop the engine by choking. This could cause backfire and could damage the engine. -
Page 19: Brush
A control handle has been mounted bottom left next to the push bar to switch the brush on and off. The GS 0850 has 3 brush positions: 1. To activate the brush, put the handle on "forward" (see Illustration 1) The brush will now start to rotate in a forward direction. - Page 20 Operating instructions GS 0850 2. Put the handle on "neutral" for the neutral position, which also switches the brush off (see Illustration 2). Indicated by the horizontal line on the sticker (see Illustration 3) Illustration 2 Illustration 3 3. For backward position, put handle on "backward" (see Illustration 4). The brush will now start to rotate in a backward direction.
-
Page 21: Configurations
Operating instructions GS 0850 3.3.2 Configurations The GS 0850 has two different settings. The right setting will result in an optimum sweeping result. First of all, the distance between the brush and the surface to be swept can be adjusted: the brush height-setting. -
Page 22: Slantwise Adjustment Of Brush
Operating instructions GS 0850 When the height of the brush is adjusted in such a way that it sweeps the sweeping surface extending over a bigger length, it could result in increased brush wear. This shortens the brush's life. 3.3.4 Angle adjustment of the brush The brush can be placed in an angled position in relation to the direction of movement. - Page 23 Operating instructions GS 0850 The GS 0850 has three different movement positions: 1. Pull the handle towards you for the forward movement. The machine will now move forward. (see Illustration 1) Illustration 1 2. When the handle is left in the middle, the machine is in neutral. The machine will not move.
- Page 24 Operating instructions GS 0850 3. For backward position, push the handle away from you. The machine will now move backward. (see Illustration 4) Illustration 4 It is not allowed to install devices to lock the control that controls the machine's movements in a certain position. The installation of such device or any other device of the same purport will result in cancellation of the guarantee.
-
Page 25: Maintenance And Control
4.2 Maintenance after sweeping After sweeping, the machine can be cleaned with water. The use of a high-pressure spraying device is allowed. During cleaning, the engine of the GS 0850 must be turned off. During cleaning, the engine of the sweeper must be turned off. -
Page 26: Maintenance And Repairs
If injuries do occur however in case of a leaking line, do not use the machine and seek medical advice immediately. Check the engine's hydraulic oil level each time before using the GS 0850. Type of hydraulic oil HLP.46 (available capacity of 4.5 litres) Change the hydraulic oil after the first 50 hours. - Page 27 Operating instructions GS 0850 Check the engine's oil level each time before using the GS 0850. Type of engine oil: SAE 5W40 Capacity of the Honda GX 200 engine: 0.5 litre Capacity of the Honda GCV 160 engine: 0.45 litre For more detailed information about the engines of the GS 0850, please refer to the enclosed manuals of these engines.
-
Page 28: Accessories
Operating instructions GS 0850 5 Accessories 5.1 GS Collector Box The most commonly used accessory is the GS Collector Box. It is 85 cm wide. (see Illustration 1) The GS collector box is not included in the machine; however, you can choose to order it. - Page 29 Operating instructions GS 0850 2. Now you can lift the collector box and slide it on the mounting supports. (see Illustration 3) Illustration 3 Illustration 4 (Final result) The distance between the lower side of the collector box and the sweeping surface (ground clearance) can be adjusted by means of the turning handles.
- Page 30 Operating instructions GS 0850 To empty the collector box, follow this simple procedure: take hold of the handle of the collector box (the handle that points towards the push bar) and pull towards you. (see Illustration 7) The machine must be turned off when emptying the collector box.
-
Page 31: Other Optional Accessories
Operating instructions GS 0850 5.2 Other optional accessories 1. GS hydraulic side brush (see illustration 1) (Illustration 1) 2. GS snow plow 90 cm. (see Illustration 2) (Illustration 2) 3.GS manure scraper or GS manure scraper 105 cm (see Illustration 3) (Illustration 3) GS Engineering B.V. - Page 32 Operating instructions GS 0850 4.GS skid chain (see Illustration 4) (Illustration 4) 5.GS sulky (see Illustration 5) (Illustration 5) 6.GS wide caster wheels (see Illustration 6) (Illustration 6) GS Engineering B.V. manufacturer hydraulic sweepers...
- Page 33 Operating instructions GS 0850 7.GS set of broad tyres 16x6.50x8 or GS exchange set tyres 16x6.50x8 (see Illustration 7) (Illustration 7) GS Engineering B.V. manufacturer hydraulic sweepers...
-
Page 34: Maintenance Dates
Operating instructions GS 0850 Maintenance Dates GS Engineering B.V. manufacturer hydraulic sweepers... -
Page 35: Ec Declaration
Operating instructions GS 0850 EC DECLARATION OF CONFORMITY FOR MACHINES (Directive 89/392/CEE, Annex II, paragraph A) Wilser Constructions Ravenstein Hereby declares that sweeper GS 0850 - conforms to the provisions of the Directive relating to machinery (directive 89/392/CEE, as amended lately) and the national legislation implementing this directive;...
