Users Manual

for LCD TV
MODEL : LEANTO board Analog TV tuner
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LEANTO and is the answer not in the manual?

Questions and answers

Related Manuals for Gericom LEANTO

Summary of Contents for Gericom LEANTO

  • Page 1: Users Manual

    Users Manual for LCD TV MODEL : LEANTO board Analog TV tuner - 1 -...

  • Page 2: Table Of Contents

    TABEL OF CONTENTS: SAFETY INSTRUCTIONS:....................5 ACCESSORIES: ........................11 MONITOR INSTALLATION:....................12 Installation: ............................. 12 BACK PANEL JACKS: ......................14 Jacks on the backside Analog Tuner Version:..............14 Jacks on the backside Analog + Digital Tuner Version:Fehler! Textmarke nicht definiert. JACKS on backside of PANEL ....................
  • Page 3 Manual Store ..........................30 Manual Store - Prog........................31 Manual Store – Colour System....................32 Manual Store - Sound System ....................33 Manual Store - Channel ....................... 34 Manual Store - Search ......................... 35 Manual Store - Store........................36 Add/Delete ............................
  • Page 4 PIP (Picture In Picture) ........................ 56 Input Source........................... 57 Size ..............................58 Position ............................59 Swap..............................60 Sound Select ..........................61 PICTURE (PC) ........................62 Picture.............................. 62 Custom ............................63 Color Tone ............................64 Color Tone ............................65 Size ..............................66 PC..............................

  • Page 5: Safety Instructions

    SAFETY INSTRUCTIONS: - 5 -...
  • Page 6 SAFETY INSTRUCTIONS: - 6 -...
  • Page 7 SAFETY INSTRUCTIONS: - 7 -...
  • Page 8 SAFETY INSTRUCTIONS: - 8 -...
  • Page 9 SAFETY INSTRUCTIONS: - 9 -...
  • Page 10 SAFETY INSTRUCTIONS: - 10 -...

  • Page 11: Accessories

    ACCESSORIES: 1 x Power Cord 1x User Manual 1 x Remote Control Handset 2 x Alkaline Batteries for Remote Control 1 x Stand 1 x Service Card - 11 -...

  • Page 12: Monitor Installation

    MONITOR INSTALLATION: Installation: Stand – Table User´s Guide Screw Insert Stand Bars into the Stand Base as show below 3. Insert a Stand – Table as below a-Screw Up (8x18) 4. b-Screw Up (4X30) Screw Stand Bar 5. c-Screw Up (4 x 16 Stand Bar Stand Hole INSERT...
  • Page 13 SCREW Insert Stand in Stand-Hole until it stopps. Fit the screw!!! - 13 -...

  • Page 14: Back Panel Jacks

    BACK PANEL JACKS: Jacks on the backside Analog Tuner Version: 7.(w/r) 5. 12. 12. (white/red) 6. 12. 3. (green/red/blue) JACKS on backside of PANEL Connects a digital Video signal from a DVI output jack of PC 1. DVI or Set Top Box Connects a video signal from a video output jack of PC.
  • Page 15 Connexts a SCART (eurocalbe) signal from a VCR or DVD player. Connects an AV composite video signal from a composite 5. COMPOSITE (RCA) Intput Jack output terminal of a VCR or DVD player. Unavailable when a S-Video cable is put into the S-Video input jack. Connects a S-Video singals from a S-Video output jack of a 6.

  • Page 16: Remote Control

    REMOTE CONTROL Remote Control Picture 15. 12. 40./3. Works only if the TV supports DVB-T Tuner < Remote Control Picture > - 16 -...

  • Page 17: Ir-Remote Controller Operations

    REMOTE CONTROL IR-Remote controller Operations Key Name Operation ► Power On/Off 1. Power ► Same as Menu key on keypad. 2. Menu ► Same as Up key on keypad 3. Up ► Same as Down key on keypad 4. Down ►...
  • Page 18 ► If current input source is PC, input source is changed to DVI. ► If current input source is not TV, changes to TV input source. 25. TV ► Enters digit value to change program directly. 26. 0~9 ► If main input source is TV that includes TTX information, enters TTX display mode. 27.

  • Page 19: Key Control On The Case

    KEY CONTROL ON THE CASE Key Operations Key Name Operation ► Power on / off Power Key ► Activates main OSD when no main OSD activated ► Navigates parent menu when main OSD activated Menu Key ► Stops auto frequency search ►...

  • Page 20: Basic Operation

    Basic Operation Turning PDP/LCD TV On And Off Press on the remote control. The PDP/LCD will turn on and you will be ready to use its Power button features. You can also use the Power key on the front panel. Select Source Press on the remote control.

  • Page 21: Volume Control

    < DTT source list > Volume Control Press VOL+ VOL- button on the remote control to adjust the volume level. Press button on the remote control when you need to cut the sound temporarily. MUTE - 21 -...

  • Page 22: Osd Menu Structure

    OSD Menu Structure OSD (On Screen Display) allows users to control or adjust various features and settings in accordance with his/her preferences. Press the button on the remote control to see the main OSD menu. MENU/ENTER Example of OSD Menu Main Menu Press the button on the remote control to enter the main OSD menu.

  • Page 23: Picture

    PICTURE Picture Mode Press MENU/ENTER button display the main OSD menu. 2. Select the picture main menu. 3. Press MENU/ENTER to enter the sub menu. 4. Select Picture mode and press MENU/ENTER button to enter the sub menu. Then the picture popup window appears.

  • Page 24: Custom

    PICTURE Custom 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the picture main menu. 3. Press MENU/ENTER to enter the sub menu. Select Custom press MENU/ENTER button to enter the sub menu. Then the custom sub mode appears.
  • Page 25 - 25 -...

  • Page 26: Color Tone

    PICTURE Color Tone Your PDP/LCD screen temperatures (color settings). 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the picture main menu. 3. Press MENU/ENTER to enter the sub menu. 4. Select Colour Tone and press MENU/ENTER button to enter the sub menu. Then the picture popup window appears.

  • Page 27: Size

    PICTURE Size 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the picture main menu. 3. Press MENU/ENTER to enter the sub menu. 4. Select Size and press MENU/ENTER button to enter the sub menu. Then the picture popup window appears.

  • Page 28: Tv Channel

    TV CHANNEL Country 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the Channel main menu. 3. Press MENU/ENTER to enter the sub menu. Select Country press MENU/ENTER button to enter the sub menu. Then the picture popup window appears.

  • Page 29: Auto Store

    TV CHANNEL Auto Store 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the Channel main menu with CH+/CH- button on the remote control. 3. Press MENU/ENTER to enter the sub menu. 4. Select Auto Store with VOL+/VOL- button and press MENU/ENTER button. 5.

  • Page 30: Manual Store

    TV CHANNEL Manual Store Press MENU/ENTER button display the main OSD menu. 2. Select the Channel main menu with CH+/CH- button on the remote control. 3. Press MENU/ENTER to enter the sub menu. 4. Select Manual Store and Press MENU/ENTER to enter the sub menu. - 30 -...

  • Page 31: Manual Store - Prog

    TV CHANNEL Manual Store - Prog. Press MENU/ENTER button display the main OSD menu. 2. Select the Channel main menu with CH+/CH- button on the remote control. 3. Select the Manual Store menu with CH+/CH- button on the remote control. 4.

  • Page 32: Manual Store - Colour System

    TV CHANNEL Manual Store – Colour System Press MENU/ENTER button display the main OSD menu. 2. Select the Channel main menu with CH+/CH- button on the remote control. 3. Select the Manual Store menu with CH+/CH- button on the remote control. 4.

  • Page 33: Manual Store - Sound System

    TV CHANNEL Manual Store Sound System Press MENU/ENTER button display the main OSD menu. 2. Select the Channel main menu with CH+/CH- button on the remote control. 3. Select the Manual Store menu with CH+/CH- button on the remote control. 4.

  • Page 34: Manual Store - Channel

    TV CHANNEL Manual Store - Channel Press MENU/ENTER button display the main OSD menu. 2. Select the Channel main menu with CH+/CH- button on the remote control. 3. Select the Manual Store menu with CH+/CH- button on the remote control. 4.

  • Page 35: Manual Store - Search

    TV CHANNEL Manual Store - Search Press MENU/ENTER button display the main OSD menu. 2. Select the Channel main menu with CH+/CH- button on the remote control. 3. Select the Manual Store menu with CH+/CH- button on the remote control. 4.

  • Page 36: Manual Store - Store

    TV CHANNEL Manual Store - Store Press MENU/ENTER button display the main OSD menu. 2. Select the Channel main menu with CH+/CH- button on the remote control. 3. Select the Manual Store menu with CH+/CH- button on the remote control. 4.

  • Page 37: Add/Delete

    TV CHANNEL Add/Delete Press MENU/ENTER button display the main OSD menu. 2. Select the Channel main menu with CH+/CH- button on the remote control. 3. Select the Add/Delete menu with CH+/CH- button on the remote control. 4. Press MENU/ENTER to enter the sub menu. Then you can see the favorite program list. 6.

  • Page 38: Sort

    TV CHANNEL Sort Press MENU/ENTER button display the main OSD menu. 2. Select the Channel main menu with CH+/CH- button on the remote control. 3. Select the Sort menu with CH+/CH- button on the remote control. 4. Press MENU/ENTER to enter the sub menu. Then you can see the sort program list. (notice: You can’t see the sort program list on this picture since this picture isn’t a real operating mode but a design mode.) 6.

  • Page 39: Name

    TV CHANNEL Name Press MENU/ENTER button display the main OSD menu. 2. Select the Channel main menu with CH+/CH- button on the remote control. 3. Select the Name menu with CH+/CH- button on the remote control. 4. Press MENU/ENTER to enter the sub menu. Then you can see the sort program list. 6.

  • Page 40: Fine Tune

    TV CHANNEL Fine Tune The Fine Tuning function lets you manually adjust the PDP’s tuner if you are difficult tuning analog Channels. 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the Channel main menu with CH+/CH- button on the remote control. 3.

  • Page 41: Tv Sound

    TV SOUND Mode Your PDP/LCD has four automatic sound settings (“Standard”, “Music”,“Movie”,”Speech”)that are preset at the factory. You can active either Standard, Movie, Music or News by pressing “SSM” button on the remote control(or by making a selection from the menu) or you can select “Custom” which automatically recalls your personalized sound settings.

  • Page 42: Volume

    TV SOUND Volume 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the Sound main menu with CH+/CH- button on the remote control. 3. Press MENU/ENTER to enter the sub menu. 4. Select Volume and press MENU/ENTER button to enter the sub menu. Then you can see the Volume bar.

  • Page 43: Balance

    TV SOUND Balance This control allows you to adjust the balance of the left and right apeaker output. 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the Sound main menu with CH+/CH- button on the remote control. 3.

  • Page 44: Equalizer

    TV SOUND Equalizer You can use the OSD menu to change the Treble, Bass and Balance according to your preference. 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the Sound main menu with CH+/CH- button on the remote control. 3.

  • Page 45: Auto Volume

    TV SOUND Auto Volume 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the Sound main menu with CH+/CH- button on the remote control. 3. Press MENU/ENTER to enter the sub menu. 4. Select Auto Volume and press MENU/ENTER button to enter the sub menu. Then you will see the popup menu.

  • Page 46: Sound Mode

    TV SOUND Sound Mode 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the Sound main menu with CH+/CH- button on the remote control. 3. Press MENU/ENTER to enter the sub menu. 4. Select Sound mode and press MENU/ENTER button to enter the sub menu. Then you will see the popup menu.

  • Page 47: Setup

    SETUP Reset 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the Setup main menu with CH+/CH- button on the remote control. 3. Press MENU/ENTER to enter the sub menu. 4. Select Reset and press MENU/ENTER button to enter the sub menu. 5.

  • Page 48: Time - Clock

    SETUP Time - Clock Set the current time. 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the Setup main menu with CH+/CH- button on the remote control. 3. Press MENU/ENTER to enter the sub menu. 4. Select Time and press MENU/ENTER button to enter the sub menu. Then you will see the time menu.

  • Page 49: Time - On Timer

    SETUP Time - On Timer This PDP/LCD can be set to turn on automatically at specific time that you chose. Before using timer, you must set the PDP/LCD’s Time as described previously. 1. Press MENU/ENTER button to display the main OSD menu. 2.

  • Page 50: Time - Off Timer

    SETUP Time - Off Timer This PDP/LCD can be set to turn off automatically at specific time that you chose. Before using timer, you must set the PDP/LCD’s Time as described previously. 1. Press MENU/ENTER button to display the main OSD menu. 2.

  • Page 51: Time - On Time Channel

    SETUP Time - On Time Channel Set the channel when PDP/LCD power turns on automatically. - Available only when the Time is set and On Time is ON. 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the TIME main menu with CH+/CH- button on the remote control.

  • Page 52: Time - On Time Volume

    SETUP Time - On Time Volume Set the sound volume level when PDP/LCD power on automatically. - Available only when the Time is set and On Time is ON. 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the TIME main menu with CH+/CH- button on the remote control.

  • Page 53: Language

    SETUP Language Set the language to use in OSD. Supported languages are English, French, German, Italian, Spanish, Portuguese, Netherlandish. 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the Setup main menu with CH+/CH- button on the remote control. 3.

  • Page 54: Osd Tone

    SETUP OSD Tone 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the Setup main menu with CH+/CH- button on the remote control. 3. Press MENU/ENTER to enter the sub menu. 4. Select OSD Tone and press MENU/ENTER button to enter the sub menu. Then you will see the popup menu.

  • Page 55: Blue Screen

    SETUP Blue Screen 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the Setup main menu with CH+/CH- button on the remote control. 3. Press MENU/ENTER to enter the sub menu. 4. Select Blue Screen and press MENU/ENTER button to enter the sub menu. Then you will see the popup menu.

  • Page 56: Pip

    PIP (Picture In Picture) You can watch two programs or sources at the same time. And set up PIP size and position. 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the PIP main menu with CH+/CH- button on the remote control.

  • Page 57: Input Source

    Input Source You can watch two programs or sources at the same time. And set up PIP size and position. 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the PIP main menu with CH+/CH- button on the remote control.

  • Page 58: Size

    Size 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the PIP main menu with CH+/CH- button on the remote control. 3. Press MENU/ENTER to enter the sub menu. Select Size press MENU/ENTER button to enter the sub menu.

  • Page 59: Position

    Position 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the PIP main menu with CH+/CH- button on the remote control. 3. Press MENU/ENTER to enter the sub menu. Select Position press MENU/ENTER button to enter the sub menu.

  • Page 60: Swap

    Swap Using swap fuction, you can exchange two programs or sources at the same time. 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the PIP main menu with CH+/CH- button on the remote control. 3. Press MENU/ENTER to enter the sub menu.

  • Page 61: Sound Select

    Sound Select Using Sound Select fuction, you can exchange the sound of two programs or sources at the same time. 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the PIP main menu with CH+/CH- button on the remote control.

  • Page 62: Picture (Pc)

    PICTURE (PC) Picture Press MENU/ENTER button display the main OSD menu. 2. Select the picture main menu. 3. Press MENU/ENTER to enter the sub menu. 4. Select Picture mode and press MENU/ENTER button to enter the sub menu. Then the picture popup window appears.

  • Page 63: Custom

    PICTURE (PC) Custom 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the picture main menu. 3. Press MENU/ENTER to enter the sub menu. Select Custom press MENU/ENTER button to enter the sub menu. Then the custom sub mode appears.

  • Page 64: Color Tone

    PICTURE (PC) Color Tone 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the picture main menu. 3. Press MENU/ENTER to enter the sub menu. 4. Select Colour Tone and press MENU/ENTER button to enter the sub menu. Then the picture popup window appears.

  • Page 65: Color Tone

    PICTURE (PC) If you select Custom in the Colour Tone popup window on PC, you can select sub modes like as Red, Green, and Blue.. Color Tone 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the picture main menu. 3.

  • Page 66: Size

    PICTURE (PC) Size 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the picture main menu. 3. Press MENU/ENTER to enter the sub menu. 4. Select Size and press MENU/ENTER button to enter the sub menu. Then the picture popup window appears.
  • Page 67 PICTURE (PC) 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the picture main menu. 3. Press MENU/ENTER to enter the sub menu. 4. Select PC and press MENU/ENTER button to enter the sub menu. Then you will see the sub menu of PC.
  • Page 68 PICTURE (PC) 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the picture main menu. 3. Press MENU/ENTER to enter the sub menu. 4. Select Phase and press MENU/ENTER button to enter the sub menu. Then the setting bar appears. 5.
  • Page 69 - 69 -...
